MAREDO GT 414- 072 Manual

Vibe-seeder for fescue
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Manual Maredo® GT 414- 072
Vibe- Seeder for Fescue.
The required (hydraulic) power depends on the working depth, soil conditions,
working speed etc. The condition of the triplex greensmower and the ambient
temperature determine the available capacity. Everybody should check the
greensmower during work if it isn't overloaded by checking the heat built up
and take the correct measurements . MAREDO DOES NOT TAKE ANY
LIABILITY FOR GREENSMOWER DAMAGES.
For a safe operation it is essential, that the operator reads
and understands the manual of the Maredo machine.
MAREDO BV, RIJKSSTRAATWEG 16, 3956 CR LEERSUM, HOLLAND.
SERIAL:
IMPORTANT:
Note:
WWW.MAREDO-BV.COM.
1
EN 1309

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GT 414- 072 and is the answer not in the manual?

Questions and answers

Related Manuals for MAREDO GT 414- 072

Summary of Contents for MAREDO GT 414- 072

  • Page 1 The condition of the triplex greensmower and the ambient temperature determine the available capacity. Everybody should check the greensmower during work if it isn’t overloaded by checking the heat built up and take the correct measurements . MAREDO DOES NOT TAKE ANY LIABILITY FOR GREENSMOWER DAMAGES. Note: For a safe operation it is essential, that the operator reads and understands the manual of the Maredo machine.

  • Page 2: Safety Instructions

    7. Never overload the Maredo. 8. Check the MAREDO minimal once a week, to ensure there are no loose bolts and nuts. Check for damages too and repair it. 9. The MAREDO may never be used without protection covers and safety decals.

  • Page 3: Technical Specifications

    We, MAREDO, Rijksstraatweg16, 3956CR. Leersum, Holland, hereby declare fully on our authority, that the product: MAREDO GT410 , with serial number as indicated on the machine and in this manual, to which this declaration applies, has been manufactured in line with NEN-EN –ISO 14121-1:2007, according to the stipulations of The Machine Directive 2006/42/EG.

  • Page 4: First Setup

    Right to Left This point should always face towards the front side Next, we need a parts kit to mount the head to your triplex greensmower. Maredo has several kits available. Each kit comes with its own mounting instructions and partslist.
  • Page 5 GENERAL TIPS/ REMARKS. 1. Do not use the seeder unit in wet conditions. The funnels may clog. 2. You can check the dosing yourself. 10.3 revs of the front roller matches equals 1m² ( or 9.4 revs matches 10 sq ft). Measure the seed amount and you know the dosing per m²...

  • Page 6: User Notes

    USER NOTES. Pick-up cam for Toro Motor mount plate Cleaning shoe strips Contra weight (can be removed) Depth adjustment rear wheels (adjust evenly at both sides) Side support wheel (2x) Front seal strip Rear guide strip. Seed goes through this gap, which can be adjusted. Unscrew all 5 bolts 1 turn, use feeler gauge and set at the right distance.
  • Page 7 CHANGING THE DOSING SHAFT. Several dosing shafts are available. For the standard dosing rates, see the attached dosing table. To change the shaft, remove the seed box first by removing 4 bolts ( see the figure below). When the secure washer is removed, the dosing shaft can be removed.
