Warning: To prevent permanent damage to the instrument, this switch must
be set for the appropriate input voltage before powering up.
When you can see the 230V label, the instrument is set for 230V input. If you plug the
instrument into a 115V power supply while 230V is selected, the instrument will have
insufficient operating power.
To select 115V input, insert a straight screwdriver blade (or similar instrument) into the
slot on the switch, and slide it into its alternate position. Upon sliding the switch, you will
see the 115V label appear.
Warning: If the instrument is configured to accept 115V and you plug it into a
230V power supply, the fuses will blow and permanent damage to the electronics
may result.
Assure Clean Power Availability
The circuit used should be substantially free of large voltage transients (Kilovolt amp
loads) such as large pumps, large centrifuges, refrigerators and freezers, air conditioners,
large autoclaves, ovens, and dryers. The instrument may fail to operate normally if the
power supply is interrupted. If this occurs, turn the instrument off for a moment. When
you turn the instrument back on, it will resume normal operation, but a standard curve
which was not stored in non-volatile memory will be lost.
Fuse Requirements
The fuses are located internally in the instrument; there are two fuses, fusing both sides
of the main power supply. Fuse failure is a very rare occurrence and should indicate
malfunction of the equipment requiring service by qualified personnel.
The fuses used within this instrument are 6/10 Amp T rated (slow blow), 250 V. Cartridge
size is 3AG or size "0", dimensions 1/4 x 1-1/4" (6.3 x 32 mm). For continued protection
against risk of fire, use the same fuse for either 115 or 230 V line voltage selection.
Disconnect power cord from mains supply before replacing fuses.

1.4.2 Paper Installation

Remove the optional paper cover by pinching the sides together and pulling up. Unroll
about 10 inches of paper and place the roll on the table behind the instrument. Feed a
cleanly cut edge of the paper from the back into the printer, along the top of the metal
guide inside the printer paper well. A ragged edge or wrinkled paper will be difficult to load
and could cause a paper jam. Feed just over 1 inch of paper in and then press the paper
advance key (labeled Paper) several times to automatically feed the paper through the
printer. You will see the paper appear through the paper slot in front. Drop the roll of
paper into the printer paper well in back, spooling up any loose paper. If you have
difficulty, cut a new straight edge before trying again. Replace the paper cover by
pinching the sides together and pushing it down over the roll of paper. Insert the slotted
tabs into the printer panel. Use of the cover is optional for holding the roll of paper down in
the printer paper well.
