- Page 1 One-Point Ionizer with S Power Supply INSTALLATION AND OPERATING INSTRUCTIONS One-Point Ionizer with S Power Supply 52 00 19 9 Re v. F...
- Page 2 TABLE OF CONTENTS 1. SAFETY WARNINGS ................1 2. INSTALLATION .................. 2 One-point Ionizer Location ....................2 Installation ..........................2 Mounting the Power Supply ....................3 Cable Supports ........................3 Grounding ..........................3 Checking for Proper Operation ....................4 3. MAINTENANCE .................. 4 4. TROUBLESHOOTING ................4 5.
- Page 3 1. SAFETY WARNINGS NOTE – Statements identified with a NOTE indicate precautions necessary to avoid potential equipment failure. CAUTION! – Statements identified with a CAUTION indicate potential safety hazards. NOTE – This equipment must be correctly installed and maintained. Adhere to the following cautions for safe installation and operation: Read the complete Operation Manual before operating.
- Page 4 2. INSTALLATION Carefully remove the equipment from the carton and inspect the contents. NOTE – If any damage has occurred during shipment, notify the local carrier at once. A report should also be forwarded to Simco-Ion, 2257 North Penn Road, Hatfield PA 19440.
- Page 5 corresponding AC receptacle of the voltage and frequency marked on the nameplate and with a good electrical ground connection for the ground pin of the plug. If a grounded socket is not available, either bolt the power supply to a well-grounded metal machine frame or connect a heavy copper wire from the ground terminal on the rear of the power supply to a well-grounded electrical conduit or to a cold water pipe.
- Page 6 Checking for Proper Operation When the one-point ionizer had been connected to the power supply using the high voltage cable, turn the power supply ON. Then use Simco-Ion’s voltage detector to check for proper functioning of the emitter point and high voltage supply. Place the voltage detector tip on the one-point ionizer’s emitter point.
- Page 7 If no spark occurs and no arcing is heard, the trouble is in the power supply. If a spark does occur the fault is in one or more of the ionizers. To find the faulty Ionizer or Ionizers: Turn OFF current to power supply. Insert the high voltage cable from one of the ionizers into the exposed hole of one of the plastic receptacles and screw knurled plug FINGER TIGHT ONLY.
- Page 8 Simco-Ion 2257 North Penn Road Hatfield, PA 19440 (215) 822-6401 (800) 203-3419 www.simco-ion.com customerservice@simco-ion.com © 2015 Simco-Ion. Printed in the U.S.A. One-Point Ionizer with S Power Supply 52 00 19 9 Re v. F...
