GAME SPECIFICATIONS
WEIGHT
NET WEIGHT
SHIP WEIGHT
DIMENSIONS
WIDTH
DEPTH
HEIGHT
OPERATING TEMPERATURE
FAHRENHEIT
CELSIUS
SAFETY PRECAUTIONS
!
Modifications to the mechanical, electrical and structural components of this game
This appliance is suitable for INDOOR, DRY locations only.
!
DO NOT perform repairs or maintenance on this game with the power ON.
Unplug the unit from the wall outlet or shut off the power strip located inside the cabinet.
!
Use of flammable subtances can cause sever burns or serious injury.
Always use NON-FLAMMABLE solvents for cleaning. DO NOT use gasoline kerosene or thinners.
!
Lifting heavy objects can cause back, neck or other injuries. Be sure adequate lifting and moving
devices are available when unloading, unpacking and moving this game.
!
Be sure the electrical power matches the game requirements. See the serial number located on the
back of the game cabinet. Always plug into a grounded circuit. If the supply cord is damaged, it must
be replaced by an approved cord or assembly provided by the manufacturer.
A shielded power cable must be used for the game to retain EU/EMC compliance.
!
The power cord must be accessible at all times in case of an emergency.
490 LBS.
INPUT VOLTAGE
550 LBS.
INPUT FREQUENCY
63"
34"
89"
80-100
26.7-37.8
NOTICE
may void its compliance certifications.
DANGER
WARNING
CAUTION
ATTENTION
IN CASE OF EMERGENCY
UNPLUG THE POWER CORD.
6
POWER REQUIREMENTS
100 to 120
RANGE VAC
50 HZ
RANGE
MAX OPERATING
CURRENT
3.2 AMPS @ 115 VAC
1.8 AMPS @ 230 VAC
220 to 240
/
VAC
/ 60 HZ
!
!
!
!
!
!
