Crest Electronics CDR-1104 User Manual

4 channel dvr
Hide thumbs Also See for CDR-1104:
Table of Contents

Advertisement

Quick Links

Download this manual
Thank you for purchasing our product.
Please read this User s Manual before
using the
product.
Change without Notice
4 Channel DVR
User s Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CDR-1104 and is the answer not in the manual?

Questions and answers

Related Manuals for Crest Electronics CDR-1104

Summary of Contents for Crest Electronics CDR-1104

  • Page 1 Thank you for purchasing our product. Please read this User s Manual before using the product. Change without Notice 4 Channel DVR User s Manual...

  • Page 2: Safety Precautions

    Safety Precautions CAUTION RISK OF ELECTRICAL SHOCK. DO NOT OPEN ! CAUTION: TO REDUCE THE RISK OF ELECTRICAL SHOCK, DO NOT REMOVE COVER (OR BACK), NO USER SERVICEABLE PARTS REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of insulated dangerous Voltage within the product s enclosure that may be sufficient magnitude to constitute risk of electrical shock to persons.

  • Page 3: About This Document

    About this document Before installing stand alone DVR, be sure to thoroughly review and follow the instructions in this User s Manual. Pay particular attention to the parts that are marked NOTICE. Also, when connecting with external application, first turn the power OFF and follow manual instruction for appropriate installation.

  • Page 4: Front Panel

    FRONT PANEL Video playback function . 1.PLAY Record button (Start / Stop ) 2.REC Change the record quality level . (HST / HIG / NOR / LOW / LST). 3.SHIFT + MODE Video backup function. 4.SHIFT 5.MODE Change display mode (quad mode ) / Full channel select Display menu setup 6.MENU...

  • Page 5: Rear Panel

    REAR PANEL Power code in 12V/ 5A 1. DC IN USB device slot 2. USB Camera 1 ~ 4 input BNC type 3. CAM IN Monitor out 4. MONITOR...
  • Page 6 REMOTE Controller The key on the remote controller function control is same as the front keypad of the unit. Record button (Start / Stop ) Display menu setup MENU Video backup function. BACKUP Video search function SEARCH record quality level (Highest) Video record quality level (High) Video...

  • Page 7: Operation

    1 . OPERATION Power on the DVR system , the real-time video can be seen by 4 quad screen or full screen display . User can press MODE button to switch the display mode . Playback mode : Press PLAY button , user can search date-time to playback . Record mode : Press REC button start to record .
  • Page 8 Icon Indicator: In live mode or playback mode , the icons show at top line on screen to notify user the system status , below are the icons status . Live mode Forward Recording Pause Video loss Reverse Motion detect SHIFT mode Display Channel Hard disk usage...

  • Page 9: System Setup

    2 . SYSTEM SETUP When user first time use admin menu setup , please press direction key ▲ ▲ ▼ ▼ and MENU ,then user can into admin menu setup successful. 2.1 Camera Setup User can setup each channel display status and adjust the cameras Brightness , contrast, hue and saturation .
  • Page 10 2.2.1 Schedule Record Frame rate direction left crease direction User can use the button to de the frame rate or right button to increase the frame rate value . After changed the frame rate value , press MENU button to exit the setup menu . Schedule record will follow these frame rate values .
  • Page 11 2.2.6 Data Retention: OFF / 1 ~ 15 days selectable 2.2.7 Schedule Record left Use the button or right button to select time and use the Enter button to change record type . Notice: 1. Each channel has own frame rate adjustment in different recording mode. 2.
  • Page 12 2.3 Motion Detection User can setup each channel with different motion detection . 2.3.1 Channel : User can setup different motion detection of channels (1~ 4 ) 2.3.2 Sensitivity : Off / Low / Normal / High 2.3.3 Pop up : OFF/ 1 ~ 30 Seconds /CONT Alarm POP UP: Each channel jumps to full screen when alarm triggered.
  • Page 13 2.4 SCREEN Let user setup the screen display 2.4.1 SCREEN: Split border on or off . 2.4.2 Video Adjustment: Video screen position movement. Use direction button to move. NTSC/ PAL/ AUTO 2.4.3 Video system : 2.5 System Setup 2.5.1 Hard Disk Setup : Overwrite Enable : Yes ->...
  • Page 14 2.5.2 Time Setup User can setup time zone and daylight saving time in this menu , also can use up-down button move to time set change the date and time. 2.5.3 Buzzer Setup System Buzzer: OS operating Key Press Buzzer: Button operating Motion Buzzer: Motion detection warning Video Loss Buzzer Video loss warning...
  • Page 15 2.5.6 Load Player Software Stop all hard disk working and insert USB device into USB slot before load Player Software then press ENTER . After press ENTER, the system will search software file from USB device. After the file is detected, the system auto load player file when finished it return to setup menu. Player Software is loaded in hard disk as factory default.
  • Page 16 2.6 Search User can search video image by Time list , Event list and Time search . 2.6.1 Time List mode Use direction button up and down to select date and time section, and then press ENTER start to playback. Time list total can save 120 records 2.6.2 Event List mode Each event will list on event list , user can use direction button up and down to move and it will show the event start time and end time for user reference .
  • Page 17 2.6.3 Time Search: 1. Press ENTER into time search menu . 2. Use direction left or right button to move the cursor position . 3. Press ENTER to change date and time . 4. Press MENU return to the previous screen and move cursor to Search. 5.
  • Page 18 2.7 Language Standard is English / Chinese 2.8 Exit User needs to save changes if any function value has changed then exit menu.
  • Page 19 3 . Player Software Start to play : Fast Reverse Play Play Reverse Fast Forward Previous Frame Full Screen (manual switch) Pause Quad Screen Next Frame Capture image AVI Button: .vvf files export to .avi format Browse for the source file Browse a path for file output Select a compression codec Percentage of the export AVI progress...
  • Page 20 4 . Specification 4 CH Digital DVR Model Input 4 CH Inputs 1.0Vp-p, 75ohm unbalanced (BNC Type) Output Main monitor x 1 S/N Ratio More than 40dB 0Color 6.7 Million Monitoring Method Channel Display Single / Quad channel 640(H) x 448(V) Active Pixels(NTSC); Screen Quality 640(H) x 544(V) Active Pixels (PAL) Display Rate...
