  • Page 1 Thank you for purchasing our product. Please read this User s Manual before using the product. Change without Notice 4 Channel DVR User s Guide...
  • Page 2 Safety Precautions CAUTION RISK OF ELECTRICAL SHOCK. DO NOT OPEN ! CAUTION: TO REDUCE THE RISK OF ELECTRICAL SHOCK, DO NOT REMOVE COVER (OR BACK), NO USER SERVICEABLE PARTS REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of insulated dangerous Voltage within the product s enclosure that may be sufficient magnitude to constitute risk of electrical shock to persons.

  • Page 3: Front Panel

    FRONT PANEL Video playback function . 1.PLAY Record button (Start / Stop ) 2.REC Change the record quality level (HST / HIG / NOR / LOW / LST). 3.SHIFT + MODE 4.SHIFT Video backup function. 5.MODE Change display mode (quad mode ) / Full channel select Display menu setup 6.MENU...

  • Page 4: Rear Panel

    REAR PANEL Power code in 12V/ 5A 1. DC IN USB device slot 2. USB Camera 1 ~ 4 input BNC type 3. CAM IN 4. MONITOR Monitor out...
  • Page 5 REMOTE Controller The key on the remote controller function control is same as the front keypad of the unit. Record button (Start / Stop ) Display menu setup MENU Video backup function. BACKUP Video search function SEARCH Video record quality level (Highest) Video record quality level (High) Video...

  • Page 6: Operation

    1 . OPERATION Power on the DVR system , the real-time video can be seen by 4 quad screen or full screen display . User can press MODE button to switch the display mode . Playback mode : Press PLAY button , user can search date-time to playback . Record mode : Press REC button start to record .

  • Page 7: System Setup

    2 . SYSTEM SETUP 2.1 Time Setup User can setup daylight saving time and date format in this menu , also can use up-down button move to time set change the date and time. Finally press apply to change time . 2.2 Auto Record: On / Off When auto record is set on , the DVR will start recording after the DVR power on .
  • Page 8 2.5 Search User can search record data by time search , press PLAY button and input time to search video . 1. Press ENTER into time select . 2. Use direction left or right button to move the cursor position . 3.
  • Page 9 3 . Player Software Start to play : Fast Reverse Play Play Reverse Fast Forward Previous Frame Full Screen (manual switch) Pause Quad Screen Next Frame Capture image AVI Button: .vvf files export to .avi format Browse for the source file Browse a path for file output Select a compression codec Percentage of the export AVI progress...
  • Page 10 4 . Specification Model 4 CH Digital DVR Input 4 CH Inputs 1.0Vp-p, 75ohm unbalanced (BNC Type) Output Main monitor x 1 S/N Ratio More than 40dB Color 6.7 Million Monitoring Method Channel Display Single / Quad channel 640(H) x 448(V) Active Pixels(NTSC); Screen Quality 640(H) x 544(V) Active Pixels (PAL) Display Rate...
