  • Page 1 形 形 形 形 名 名 名 名 を を を を 入 入 入 入 力 力 力 力 。 。 。 。         複 複 複 複 数 数 数 数 の の の の 場 場 場 場 合 合 合 合 は は は は 「 「 「 「 /」 」 」 」 で で で で 区 区 区 区 切 切 切 切 る る る る 。 。 。 。 9603-01 品...

  • Page 3: Table Of Contents

    C C C C o o o o n n n n t t t t e e e e n n n n t t t t s s s s Introduction Safety Notes Notes on Use C C C C h h h h a a a a p p p p t t t t e e e e r r r r 1 1 1 1 O O O O v v v v e e e e r r r r v v v v i i i i e e e e w w w w 1 1 1 1 C C C C h h h h a a a a p p p p t t t t e e e e r r r r 2 2 2 2 D D D D i i i i s s s s p p p p l l l l a a a a y y y y S S S S c c c c r r r r e e e e e e e e n n n n 3 3 3 3...
  • Page 5 3194 MOTOR/HARMONIC HiTESTER. Before use Before using the product, inspect it and check the operation to make sure that the product was not damaged due to poor storage or transport conditions. If damage is found, contact your dealer or HIOKI representative. ______________________________________________________________________________________________...

  • Page 6: Safety Notes

    _____________________________________________________________________________________________ Safety Notes This product is designed to conform to IEC 61010 Safety Standards, and has been thoroughly tested for safety prior to shipment. However, DANGER mishandling during use could result in injury or death, as well as damage to the product. Be certain that you understand the instructions and precautions in the manual before use.

  • Page 7: Notes On Use

    For accurate measurement, allow one hour for warming up before use. The 9603-01 can be used together with a strain gauge type torque meter, but depending on torque meter specifications, the combination may not work. It may not be possible to obtain accurate measurements close to a transformer or conductor carrying a large high-frequency current, or close to any device such as a radio transmitter generating a strong magnetic field.
  • Page 8 _____________________________________________________________________________________________ ______________________________________________________________________________________________...

  • Page 9: C C C C H H H H A A A A P P P P T T T T E E E E R R R R 1 1 1 1 O O O O V V V V E E E E R R R R V V V V I I I I E E E E W W W

    3194 product. Further, tachometer signals (analog or pulse) Channel A input via the 9603-01 can be used by the 3194 to calculate and display motor power and efficiency. Channel B...
  • Page 10 _____________________________________________________________________________________________ ______________________________________________________________________________________________...

  • Page 11: C C C C H H H H A A A A P P P P T T T T E E E E R R R R 2 2 2 2 D D D D I I I I S S S S P P P P L L L L A A A A Y Y Y Y S S S S C C C C R R R R E E E E E E E E N N N

    _____________________________________________________________________________________________ Chapter 2 Display Screen There are two display screens: showing two measurement channels and showing the motor power. Two measurement channels Two measurement channels Motor power ______________________________________________________________________________________________...
  • Page 12 _____________________________________________________________________________________________ ______________________________________________________________________________________________...

  • Page 13: C C C C H H H H A A A A P P P P T T T T E E E E R R R R 3 3 3 3 S S S S E E E E T T T T T T T T I I I I N N N N G G G G M M M M E E E E T T T T H H H H O O O O D D D

    _____________________________________________________________________________________________ Chapter 3 Setting Method 3.1 Changing the chA Input Connector chA input is used to select either the strain gauge input (7 pin connector) or DC voltage input (BNC pins). Press the key to switch to the external input screen. STATUS Input is switched using the internal circuits but do not connect to connectors that NOTE...

  • Page 14: Changing The Range

    _____________________________________________________________________________________________ 3.2 Changing the Range 3.2.1 Strain Gauge Input Channel A (Strain Gauge) can be used for the torque meter output, and has three ranges: 1 mV/V, 1.5 mV/V, and 2 mV/V. The full scale screen display values for these ranges are 1.0000, 1.5000, and 2.0000 respectively (when the scaling value is 1).

  • Page 15: Dc Voltage Input

    _____________________________________________________________________________________________ 3.2.2 DC Voltage Input Both channels A and B have three ranges, of ±1 V, ±5 V, and ±10 V. Changing on the MEAS screen The range for channel A corresponds to the voltage range switching key, and the range for channel B corresponds to the current range switching key.

  • Page 16: Setting The Products

    _____________________________________________________________________________________________ 3.3 Setting the Products Input DC voltage values can be displayed together with a unit designation. 1. Display the " " page on the STATUS EXT UNIT screen. 2. Using the keys, move the cursor to" ." CURSOR UNIT 3.

  • Page 17: Zero Adjustment

    _____________________________________________________________________________________________ 3.5 Zero adjustment A numerical value may be displayed even if no torque is generated by the torque sensor or connection cable. If this happens, perform zero adjustment. 1. Make sure that no torque is applied to the torque sensor. 2.

  • Page 18: Calculating Motor Power (Pm)

    _____________________________________________________________________________________________ 3.6 Calculating Motor Power (Pm) When the units for channel A are set to torque (N･m, mN･m, kN･m, kgf･m, kgf･cm) and the units for channel B are set to rotation rate (rpm), then the following expression is automatically evaluated and displayed. Unit for channel A Motor power calculation 2×π×display value for channel B...

  • Page 19: Overview

    This section lists the extra commands added for measurement. This section explains only commands added for the 9603-01. For details on operation of the GP-IB or RS-232C interface, first refer to Chapter 12, "GP-IB/RS-232C Interface" in the instruction manual of the 3194.

  • Page 20: Command Reference

    4.2.2 Specific Commands :DATAout:ITEM:EXTernalin Sets the output item for the measurement value by using the 9603-01. S S S S y y y y n n n n t t t t a a a a x x x x...
  • Page 21 _____________________________________________________________________________________________ :DATAout:ITEM:EXTernalin? Queries the output item for the measurement value by using the 9603-01. S S S S y y y y n n n n t t t t a a a a x x x x F F F F u u u u n n n n c c c c t t t t i i i i o o o o n n n n...
  • Page 22 ":EXTERNALINA:SCALE 10" :EXTernalin[CH]:UNIT Sets the units for channel of the 9603-01 S S S S y y y y n n n n t t t t a a a a x x x x F F F F u u u u n n n n c c c c t t t t i i i i o o o o n n n n Sets the units for the specified channel :EXTernalin[CH]:UNIT <units>...
  • Page 23 ":EXTernalinA:GAGE OFF" :EXTernalinB:PULSe Sets the input type for channel B of the 9603-01. S S S S y y y y n n n n t t t t a a a a x x x x F F F F u u u u n n n n c c c c t t t t i i i i o o o o n n n n Sets the input type for the channel B of :EXTernalinB:PULSe <ON/OFF>...
  • Page 24 UNIT NM;PULSE OFF;GAGE OFF" :MEASure:ITEM:EXTernalin Sets the output item for the measurement value by using the 9603-01. S S S S y y y y n n n n t t t t a a a a x x x x...
  • Page 25 Degaussing Makes a setting of the external input :DISPlay:EXTernalin display. :EXTernalin[CH]:RANGe NR1/NR2 numerical data (1) Setting the voltage range for the 9603-01. :EXTernalin[CH]:RANGe? Querying the 9603-01 voltage range. :EXTernalin[CH]:SCALe NR2 numerical data (1) Sets the scaling value of the 9603-01.
  • Page 26 _____________________________________________________________________________________________ Valid Command According to Condition Condition Integration reset Integration start Integration stop HOLD HOLD PEAK HOLD HOLD PEAK HOLD HOLD PEAK Command :DATAout:ITEM:EXTernalin ○ × × × × × × × × :DATAout:ITEM:EXTernalin? ○ ○ ○ ○ ○ ○ ○...
  • Page 27 _____________________________________________________________________________________________ Chapter 5 Specifications Operating method Using with the main 3194 (factory-fitted option) However, it is necessary to change to the 3194 version. Operating method Applying as to the specifications of the main 3194 product Temperature ±0.03%f.s./℃ coefficient Analog output ±5 Vf.s.
  • Page 28 _____________________________________________________________________________________________ Strain Gauge Input (chA Special Connector) Measurement ±0.1%rdg.±0.065%f.s.（23℃±5℃, 80%RH or less） accuracy (Adjust including energizing voltage accuracy and the cable configuration.) Strain gauge type transducer (Bridge resistance: 350 Ω〜1.5 Suitable transducer kΩ) Connectors in use (TAJIMI ELECTRONICS CO.,LTD, PRC03-23A10-7F) Bridge voltage 3 Vrms, 3 kHz±10%, Sine wave Zero ajustment...
  • Page 29 _____________________________________________________________________________________________ Chapter 6 Internal Block Diagram The voltage input through the connector is converted, in differential and range circuits, to a voltage proportional to the input voltage, and transferred to the 3194 proper by an A/D converter. When measuring a rotation rate by counting pulses, channel B can be switched so that pulses are counted by the frequency measurement function in the 3194 proper.
  • Page 30 _____________________________________________________________________________________________ ______________________________________________________________________________________________...
  • Page 31 All reasonable care has been taken in the production of this manual, but if you find any points which are unclear or in error, please contact your supplier or the Sales and Marketing International Department at HIOKI headquarters. In the interests of product development, the contents of this manual are subject to revision without prior notice.
  • Page 32 HEAD OFFICE 81 Koizumi, Ueda, Nagano 386-1192, Japan TEL +81-268-28-0562 / FAX +81-268-28-0568 E-mail: os-com@hioki.co.jp HIOKI USA CORPORATION 6 Corporate Drive, Cranbury, NJ 08512, USA TEL +1-609-409-9109 / FAX +1-609-409-9108 9603B981-00 01-07H Printed on recycled paper...
