Coast Spas Patio Quick Start Manual

Initial Start-up
Your spa will enter Priming Mode (Pr) when it is
energized. During Priming Mode, press "PUMP"
button(s) repeatedly and be sure all pumps are
free of air. Priming Mode lasts for less than 5
minutes. Press "Warm" or "Cool" to exit. After
Priming Mode, the spa will run in Standard Mode
(see Mode section).
Temp Control (80°F - 104°F / 26°C - 40°C)
The last measured water
constantly displayed. The water temperature
displayed is current only when the pump has
been running for at least 2 minutes. To display
the set temperature, press "Warm" or "Cool"
once. To change the set temperature, press
temperature button again before the display
stops flashing. After three seconds, the display
will stop flashing and begin to display the current
spa temperature. At this time the spa will begin
to work towards adjusting the water temperature
until it is at the set temperature.
PUMP 1
Press "Pump 1" to turn pump 1 on or off and to
shift between low and high speeds. The low-
speed will turn off after 4 hours. High-speed will
turn off after 15 minutes. Low-speed may run
automatically at times (filtration cycles, etc.)
during which it cannot be deactivated from the
panel, however the "high-speed" mode may be
operated.
Patio—6 Button Topside Upgrade
PUMP 2 & AUX (if equipped)
Press the corresponding button once to turn the
device on. The device will turn off after 15 minutes.
If the secondary device on your hot tub is an
additional Jet Pump, when you press the button to
activate the pump it will be on "Low Speed". Press
the button again to activate "High Speed". Press
once again to turn "Off".
Light
Press "Light" to operate the spa light. Turns off
after 4 hours. If your hot tub is equipped with a
multicolor lighting package, then pressing the
"Light" button consecutively will toggle the lights
through different colors modes.
Mode
Mode is changed by pressing "Warm or Cool" then
once the display is flashing "Light".
temperature is Press the "Light" button until you reach "Mode".
Press the "Warm or Cool" to toggle the "Mode" to
"Ready" or "Rest". Once you have the desired
mode on screen press the "Light" button set.
TEMPERATURE RANGE
Temperature Range is changed by pressing "Warm
or Cool" then once the display is flashing "Light".
Press the "Light" button until you reach "TEMP".
Press the "Warm or Cool" to toggle the "TEMP" to
"High" (Arrow Up) or "Low" (Arrow Down). Once
you have the desired Temperature Range on
screen press the "Light" button set.
Adjusting Filtration
Filter cycles are set using a start time and a
duration. Start time is indicated by an "A" or "P" in
the bottom right corner of the display. Duration has
no "A" or "P" indication. Each setting can be
adjusted in 15-minute increments. The panel
calculates
automatically. Filtration Cycles are changed by
pressing "Warm or Cool" then once the display is
2021
the end time and displays it
