- Page 1 Full Commercial/Club Rated Self-Generated Curved Treadmill CT700 Curved Treadmill Owners Manual Installation Instructions and Specifications...
-
Page 2: Table Of Contents
CONTENTS Treadmill Model Assumption of Risk For Your Saftey Proper Use of Your Treadmill CT700 Description and Specifications Assembly Instructions and Procedures Display Console Functions Packing List Warranty Warranty Information... -
Page 3: Treadmill Model
TREADMILL MODEL CT700 Full Commercial/Club Rated Self-Generated Curved Treadmill - 1 -... -
Page 4: Assumption Of Risk
ASSUMPTION OF RISK - 2 -... -
Page 5: For Your Saftey
FOR YOUR SAFETY 1. Consult your physician or health care provider before using your CT700 Treadmill and/or exercise equipment. 2. Only one (1) person is permitted on the treadmill at any time. 3. In order to avoid accidents, injuries, or death, please keep children, disabled people, and pets away from the treadmill at all times. -
Page 6: Proper Use Of Your Treadmill
7. Never touch any moving part on your CT700 Treadmill with your hand. If you have long hair, you should tie it up for safety from the track, due to the space between the slats. - Page 7 PROPER USE OF YOUR CT700 TREADMILL 9. When the CT700 Treadmill is in use or not in use, keep children and pets away at least 10 feet from all sides, front & rear at all times. 10. Place the treadmill in a clean, flat area. Do not place the CT700 Treadmill on a heavy carpet.
-
Page 8: Ct700 Description And Specifications
CT700 DESCRIPTION AND SPECIFICATIONS SB Fitness CT700 Make/Model Commercial Self-Generated Curved Treadmill Resistance 8 Levels of Magnetic Resistance Levels Magnetically Controlled Resistance Brake Mode for Tension and to Aid in Stopping Belt Super Heavy Duty Running Belt Durable Rubber Self-Generated... -
Page 9: Assembly Instructions And Procedures
2. Because of its large size and weight, the CT700 Treadmill should be assembled near the location where it will be used. 3. Place all parts of the CT700 Treadmill in the empy area and remove all packing material. Do not discard the packaging material until the assembly is complete. - Page 10 ASSEMBLY INSTRUCTIONS AND PROCEDURES CT700 TREADMILL SCHEMATIC DIAGRAM Sport Training Handlebars Sport Training Handlebars Resistance Adjustment Display Console Upright Column Running Belt Running Belt Transport Wheels Leveling Feet Transport Handle - 8 -...
- Page 11 AND PROCEDURES Step 1: Remove From Box and Prepare For Assembly 1. Be careful not to scratch or damage your CT700 Treadmill while removing it from the wooden box. 2. Put the main treadmill where you intend to keep it. Make sure there is plenty of room around your treadmill.
- Page 12 ASSEMBLY INSTRUCTIONS AND PROCEDURES Step 2: Remove Left and Right Front Covers 1. Use a phillips screwdriver to remove the 5mm screws at the left and right sides as shown, removing both left and right front side covers. Each side panel has 4 screws on the top and 2 on the side. 2.
- Page 13 ASSEMBLY INSTRUCTIONS AND PROCEDURES Step 3: Assemble the Right Column You may want to get the assistance of a second person for this step. To install the right column, first place the hole of the connecting plate on the inside of the right column on the “Center Bolt” of the main frame.
- Page 14 ASSEMBLY INSTRUCTIONS AND PROCEDURES Step 4: Attach Resistance Cable 1. Now attach Resistance Cable to the Resistance Adjustment Bolt. (see picture below) Carefully follow these steps: a. Connect Resistance to the inside anchor bolt that controls the lever arm, housing the magnets.
- Page 15 ASSEMBLY INSTRUCTIONS AND PROCEDURES Step 5: Assemble the Left Column You may want to get the assistance of a second person for these steps. Carefully connect the Data Cable from the bottom of the Left Column through the Data Cable Hole in the Main Frame. 2.
- Page 16 ASSEMBLY INSTRUCTIONS AND PROCEDURES Step 6: Connect Remaining Data Cables and Assemble the Multi-Functional Handrails You may want to get the assistance of a second person for this step. Connect main handlebars to each upright using the (4) M10x20 Allen Head Bolts.
-
Page 17: Display Console Functions
DISPLAY CONSOLE FUNCTIONS Note: Once batteries are installed and you begin walking/running on the track, console display will automatically turn on. Time, Distance, Calories will begin to count up. Speed Distance Time Calories Reset Total Distance Mode Time 00:00 - 99:59 (min:sec) Speed 0.0 - 999.9 (mi/h) Distance... - Page 18 DISPLAY CONSOLE FUNCTIONS Display Key Functions: Mode Key: Select and view a function, Press key for 3-4 seconds, Console will automatically reset mode if you wish to make changes. Set Key: Press this key to enter each desired function. Reset Key: It is valid for the current data reset/clear. (Not valid in the non-scanning state, invalid for the total distance) Automatic Shut Off: Upon completion of a workout and track stopping, the console will shut...
-
Page 19: Packing List
PACKING/PARTS LIST Serial Name Quantity Notes Mainframes/Runways Handrail Console Upright Post M10*20 Hexagon Socket Headscews For Handrail w/Cylindrical Head and Column M8*16 Hexagon Socket Headscews For Mainframe w/Round Head and Column For the side M5*20 Phillips Head Screws plastic shell 8mm L-shaped Hex Wrench 3mm Hex Wrench 4mm Hex Wrench... -
Page 20: Warranty
Parts: 5 Years Parts: 7 Years Electronics: 2 Years Electronics: 2 Years Labor: 1 Year Labor: 1 Year If you have questions or need assistance with your CT700 Curved Treadmill, please call Customer Service: 1-814-558-4859 or email Chad: chad@sbfitnessequipment.com - 18 -... -
Page 21: Warranty Information
WARRANTY INFORMATION WHAT IS COVERED SB Fitness warrants to the original purchaser of this CT700 Treadmill (the “Product”) that the frame of the Product shall be free from defect in materials and workmanship for a period of five years from the date of purchase. All other parts and components of the...
