- Page 1 ER600 Radio Expansion On the website www.elkron.com, you may find updated information relating to the documentation provided with the product. DS80WL24-004 LBT80969...
- Page 2 This manual may also contain references to or information about products (hardware or software) or services that are not yet on the market. These references or information in no way mean that the company intends to market such product or services. Elkron is a brand name of URMET S.p.A. All the brands cited in the document belong to their respective owners.
-
Page 3: Table Of Contents
Positioning the ER600 radio expansion ........................11 InstallaTion ....................................12 Installation procedure ................................12 4.1.1 Battery compartment and fastening points for the ER600 in the MP500/4N - MP500/8 control panels 4.1.2 Assembling ER600 expansion in the MP500/4N - MP500/8 control panel 4.1.3 Assembling ER600 expansion in the MP500/16 control panel Installation of the ER600 radio expansion .......................... - Page 4 Radio expansion module inputs 12.2.2 Radio expansion module outputs (sirens) 13 - TECHNICAL SPECIFICATIONS ..............................41 13.1 ER600 RADIO EXPANSION ..............................41 13.2 DC600 SLIM microcontact ..............................41 13.3 DC600 2I microcontact ................................. 41 13.4 IR600 IR DETECTOR FOR INDOORS ..........................41 13.5...
- Page 5 Figure 1 - Fastening points for optional features in the MP500/4N - MP500/8 control panels ..............12 Figure 2 – Fastening points for optional features in the MP500/4N - MP500/8 control panels ..............12 Figure 3 - ER600 radio expansion ................................13 Figure 4 - Connections via bus ................................14 Figure 5 - Position of the programming buttons ............................
-
Page 6: Er600 For Mp500/4N -Mp500/8 - Mp500/16 Systems
WARNING! The installation of the radio expansion or radio devices results in the loss of EN50131 certification. WARNING! The ER600 expansion can be installed on the control panels running SW 1.05 version or higher. ER500 and ER600 radio expansions cannot be connected to the same control panel. -
Page 7: Dc6002I Micro-Contact
(use of wire contacts for rolling blinds Elkron MF01 and MF02 is recommended). It is powered by a lithium battery and communicates via radio with the ER600 two-way radio module. -
Page 8: Im600 Dual Technology Motion Detector
Note: this device can be used in combination with an ER600 radio expansion 1.2.9 RC600 remote control The remote control is powered by a lithium battery and communicates via radio with the ER600 two-way radio module. The device has a two-tone LED to signal the command transmitted and a low battery. -
Page 9: Kp600 Led Keypad
1.2.10 KP600 Led keypad The led keypad is powered by a lithium battery and communicates via radio with the ER600 two- way radio module. It has 4 function keys, three keys for the arming and disarming of associate partitions and one key that can be configured to enable and disable potential outputs that can be commanded or generate other types of signals. -
Page 10: Basic Information
The bus A particular type of connection is the bus, which can be either wired or radio. It is essentially a channel of communication that transfers data and information among the various devices of the system, guaranteeing their interaction. Installation/Configuration ER600... -
Page 11: Design: Configuration Of The Alarm System
Unless they are specifically designed and constructed for outdoor installation, like the outdoor sirens, all the devices must be installed indoors, protected from the elements and vandalism. 3.1.1.1 Positioning the ER600 radio expansion It the radio expansion is used outside of the control panels, this must be positioned: ... -
Page 12: Installation
WARNING! The ER600 radio expansion may be used only on systems with MP500/4N – MP500/8 – MP500/16 control panels in which the control panels and keypads run SW version equal to or higher than 1.05; otherwise, the ER600 will not be acquired. -
Page 13: Assembling Er600 Expansion In The Mp500/16 Control Panel
Assembling ER600 expansion in the MP500/16 control panel IMPORTANT! It is advisable to NOT INSTALL the ER600 radio expansion module in the MP500/16 control panel, because the metallic container of the control panel reduces reception of the radio signals, obstructing control of the radio devices associated with it. -
Page 14: Connections
The cable shieldings can be connected together in the control panel at the negative pole (─) of the power supply. The figure below demonstrates how to connect the various devices to each other via the bus line. Figure 4 - Connections via bus Installation/Configuration ER600... -
Page 15: Commissioning
Once the acquisition of all the devices is complete, press ESC to exit from the menu. IMPORTANT! If the ER600 is not acquired, check that the control panel and all the installed keypads run SW version equal to or higher than 1.05. -
Page 16: Using The Service Keypad
IMPORTANT! By using the Service keypad, the max number of keypads which can be used in the system is decreased by one unit: it becomes 3 in the MP500/4N control panel, 7 in the MP500/8 and MP500/16 control panels. Installation/Configuration ER600... -
Page 17: Maintenance
IMPORTANT! If for any reason it should become necessary to delete any bus device and later reacquire it, the power supply to the system or the bus device (reset) must be disconnected before carrying out any reacquisition procedure. Installation/Configuration ER600... -
Page 18: Identifying A Bus Device
The yellow LED “B” (see Figure 3 - ER600 radio expansion) of the device flashes quickly for 40 seconds; the delete operation is concluded only when the LED stops flashing and remains on steadily. 3. Turn the system off. -
Page 19: Acquisition/ Maintenance Of The Radio Devices
ACQUISITION/ MAINTENANCE OF THE RADIO DEVICES As soon as the control panel acquires the first ER600 expansion (see paragraph 5.1 ACQUISITION OF BUS DEVICES), the specific menu to acquire and configure radio devices will appear on the system keypads. Below is a diagram of the navigation flow of the “Radio Devices” menu. -
Page 20: Radio Connection Test
Radio connection test The ER600 radio expansion makes it possible to evaluate the quality of the radio connection between the peripheral devic es subject to supervision through an integrated test that provides an indication correlated to the power of the signal measured by each individual device. -
Page 21: Configuring Radio Parameters
...), it is necessary to identify a different site for the radio expansion. Once the ER600 has been moved, press the OK key and repeat the test from point 5. 11. In case of doubt on the functioning of a device, position it temporarily near the control panel (about one metre) and repeat the test. -
Page 22: Resetting Factory Settings
Resets the control panel programming and all the devices connected to the system data BUS to default. In reference to the ER600 radio expansion it is also necessary to reacquire all the radio devices associated with it (IR, DC, RC, KP, sirens). -
Page 23: Troubleshooting
< Installer code > < Technical Manager code > < Master / User code > This means that either code may be entered on the keypad indifferently. This means that the described function or service is always active. Installation/Configuration ER600... -
Page 24: Control Devices
NOT received and performed by the control unit. The indications disappear after short while. Battery housing The remote control is powered by a CR2032 3 V lithium battery Note: The ER600 radio expansion must be installed to use the remote control. Installation/Configuration ER600... -
Page 25: Kp600 Keypad
Enter a four-digit user code and press the key, to disarm all associated Disarming key partitions. Not used Acquisition key 11-12 Not used Function keys Pressing the two keys at the same time will start the function associated to them Battery isolator Assembly holes Tamper Installation/Configuration ER600... -
Page 26: System Commissioning
2 of the readers are NOT USED by default. So, if several EP500 expansion modules and at least one ER600 expansion are installed and you want to use some auxiliary inputs, you will need to deactivate an equal number of inputs to prevent exceeding the maximum number of inputs.. -
Page 27: Ancillary Functions (Gong, Courtesy Light, Door Opener, Absence Of Move)
SYSTEM (all partitions) or only to some ASSIGN SYSTEM PARTITIONS. Press to confirm 13) If SYSTEM is selected, press to select SYSTEM ASSIGN or SYSTEM DO NOT ASSIGN and press to confirm. Then Installation/Configuration ER600... - Page 28 DC01.In1: InNNN NAME 27) Press . Enter a descriptive name for the input using the keypad. The name can be up to 24 NAME Inxxx:... characters long. Press to confirm. DC01.In1: InNNN 28) Press VOCAL NAME Installation/Configuration ER600...
-
Page 29: Wireless Output Programming
IMPORTANT! Program all inputs used in the system. WIRELESS OUTPUT PROGRAMMING The wireless outputs are available only if the radio expansion module is installed. Each ER600 radio expansion module can manage up to two wireless sirens. There are no other wireless output types. 9.2.1 Wireless output encoding Each output has two addresses: a physical address and a logical address. -
Page 30: Programming Procedure
. To record, press RECORD 14) Press to cancel the vocal message of the input. MSG OUTPUT ON DELETE 15) Press repeatedly until the screen page shown here by the side appears. SIRENS SELECT SIREN 16) Press SIRENS ASSIGN Installation/Configuration ER600... -
Page 31: Rc600 Remote Control Programming
The menu is shown as it actually appears on the keypad display for the sake of simplicity. The navigation and confirmation keys are also shown to provide step-by-step help to the installer during the programming procedure. IMPORTANT! Only one ER600 module can be acquired by the MP500/4N control panel. Installation/Configuration ER600... - Page 32 UT00: INSTALLER PROGRAMMING ER01:ER SELECT IR RC01:… SELECT RC RC01:… KEYS PROGRAM. PROGRAMMING RADIO DEVICES READERS ER01:ER ER01:ER 01 SELECT DC RC01:… SELECT RC PROGRAMMING NAME RC02:… RADIO DEVICES SELECT RC RADIO DEVICES ER01:ER 01 RC03:… ER02:ER SELECT RC PROGRAMMING ADVANCED NAME SELECT RC...
-
Page 33: Kp600 Keypad Programming
The menu is shown as it actually appears on the keypad display for the sake of simplicity. The navigation and confirmation keys are also shown to provide step-by-step help to the installer during the programming procedure. IMPORTANT! Only one ER600 module can be acquired by the MP500/4N control panel. - Page 34 UT00: INSTALLER PROGRAMMING ER01:ER SELECT IR KP01:… SELECT KP KP01:… KEYS PROGRAM PROGRAMMING RADIO READERS DEVICES ER01:ER 01 ER01:ER SELECT:… KP01:… SELECT KP PROGRAMMING NAME KP02:… RADIO DEVICES ER01:ER 01 SIRENE SELECT KP RADIO DEVICES KP03:… ER02:ER PROGRAMMING ADVANCED NAME SELECT KP ER01:ER 01 KP01:…...
-
Page 35: Radio Devices Test
The type of command to be combined to the text can be selected in addition to the association procedure illustrated above by pressing GENERIC key 4. The possible options are: Not Used. The key does not perform any action. ... -
Page 36: System Commissioning
During programming, the “+” key on the remote control may be configured to activate or deactivate a specific output to access one of the following technological functions (fire, emergency, panic, silent panic) directly. Hold the “+” key pressed for at least five seconds to generate the respective event. Installation/Configuration ER600... -
Page 37: Arming Using Kp600 Keypad
A The “System state” LED will light up as follows when the keypad key is pressed: Red LED on: the system is in Total Armed state.. Red LED blinking: the system is in Partial Armed state. Blue LED on fixed: the system is disarmed Installation/Configuration ER600... -
Page 38: Maintenance
USB memory stick and the upgrading procedure will not be started. Several files related to different device types or other files non-Elkron files may coexist on the same USB memory stick... -
Page 39: Tables
1. To identify the device which generated Event generated by the battery of a radio device of the radio the low battery alarm expansion module 2 Table 2 - ID code or input with IDP protocol Installation/Configuration ER600... -
Page 40: Factory Settings
IR15 IR16 Device DC11 DC12 DC13 DC14 DC15 DC16 Radio expansion module 2 (MP500/8 - MP500/16) 12.2.2 Radio expansion module outputs (sirens) Partition Physical Logical Status report Customisation Outputs Name assignment address address … Disabled Burglar SYSTEM Seq. Installation/Configuration ER600... -
Page 41: Technical Specifications
13 - TECHNICAL SPECIFICATIONS 13.1 ER600 RADIO EXPANSION Nominal power voltage 13.8 Vdc (taken from bus) Expansion operating voltage 9 Vdc to 15 Vdc Nominal current absorbed at 12 Vdc 35 mA Max peak current absorption 45 mA Max total length of control panel-radio expansion serial Bus line... -
Page 42: Irt600 Ir Detector Curtain Effect
2 3.6V AA Lithium Batteries. Battery life 3 years (Typical value, may vary depending on use) Operating temperature -10°C to +45°C Degree of protection IP66 Dimensions (W x H x D) 66 x 148 x 50 mm Weight 400g Installation/Configuration ER600... -
Page 43: Im600 Indoor Dual Technology Detector
Power supply 1 Lithium battery type EL 123AP Battery life 5 years (Typical value, may vary depending on use) Operating temperature -10°C to +45°C Dimensions (W x H x D) 80 x 116 x 20.5 mm Weight 100g Installation/Configuration ER600... - Page 44 ELKRON is a trademark of URMET S.p.A. ELKRON Via Bologna, 188/C - 10154 Torino (TO) – Italy Tel. +39 011.3986711 - Fax +39 011.3986703 www.urmet.com Installation/Configuration ER600 – mail to: info@elkron.it www.elkron.com MADE IN ITALY...
