Avery Dennison Intrace RH5 Quick Start Quide

Avery Dennison
Smartrac
Instructions
®
Intrace
Handheld Reader RH5
Overview
Frequency Band
LF 124 kHz - 134.2 kHz
Hard Tag Dimensions
155 x 82 mm / 6.10 x 3.23 in
Industry Segments
Animal Identification
Instructions
The RH5 can read all ISO 11784 and
11785 compliant animal transponders
(FDX-B and HDX) and also FDX-A and
EM4102 transponders.
Switch Reader Off
Press the 'ON/OFF' button for about
2 seconds. In case of inactivity the reader
switches off automatically after about
2 minutes.
Charging Battery
Connect the reader to a computer or an
USB power supply. When fully charged the
LED changes from red to green. The battery
status is shown in the upper right corner
of the OLED display during scan view.
Reader Configuration
From initial scan view press 'UP' once and
enter Settings by pressing 'OK'. The menu
offer configuration of Language, Memory,
®
Bluetooth , Hex. For selecting the desired
function please press 'OK'.
Classification: Avery Dennison - Public Classification: Avery Dennison - Internal
Intrace-Handheld-Reader-RH5-05-21-EN-IS
®
Bluetooth Setting
Scroll to 'Bluetooth' and press 'OK' for
disabling or enabling communication
via Bluetooth ® . When enabled the LED
is blue. For saving battery power please
disable Bluetooth ® .
Reading Transponders
Switch on the reader, wait until Scan
is shown and press 'OK'. Approach the
reader to the area where the transponder
is supposed to be. After detecting a
transponder the identification number is
shown on the OLED display. For another
reading press 'OK' again.
Continuous Scan
Continuous reading can be activated by
scrolling down from initial scan view to
'Continuous Scan' and pressing 'OK'.
rfid.averydennison.com
