Lighting Control With
Human Centric Lighting System
Touch Panel HBP01
Applications
A wall-mounted touch panel designed to operate with the Hytronik range of
bluetooth wireless controls. It features support for human centric features to
provide elegant control of pre-difined circadian rhythm profiles to suit office,
education and healthcare applications. 4 programmable one-touch scene
recall memories are provided, as well as brightness and white balance control.
The HBP01 is programmable using the free to download Hytronik APP on both
iOS and Android platforms.
Time sustainability: The touch panel HBP01 can keep the time runing for up to
1 month during power failure.
Office / Commercial Lighting
Classrooms
Hospital / Healthcare
Features
Free smartphone (iOS and Andriod) App for set-up and comissioning:
Scene control
Configurable night light
Circadian rhythm control
5 Year, 50,000hr Warranty
Technical Data
Bluetooth Transceiver
Operation frequency
Transmission power
Range (Typical indoor)
Protocol
Environment
Operation temperature
Relative humidity
IP rating
Note:
This datasheet is intended for information related to the HBP01 panel only. For detailed information realted to the Hytronik Human Centric system, please refer to
the System data sheet and App user guide available from our website.
Wireless Technology
2.4 GHz - 2.483 GHz
7 dBm
15~30m
4 Wireless Mesh
O
O
Ta: 0
C ~ +50
C
20% ~ 90%
IP20
Free smartphone App for
set-up and commissioning
Input Characteristics
Operating voltage
Stand-by power
With night light
Safety and EMC
EMC standard (EMC)
EN55015, EN61000, EN61547
Safety standard (LVD)
Certification
Bluetooth Touch Panel
HBP01
iOS
220~240VAC 50/60Hz
<1W
0.35W
EN60669, AS/NZS60669
Semko, CB, CE , EMC, RED, RCM
