Summary of Contents for Diamond TV Wonder 750PEC
- Page 3 PCI Express Hybrid ATSC/QAM X8550A V1.3.08002.02101 Introduction Defining the PCI Express Hybrid ATSC/QAM HD 750PEC Important Notice: “All channels are subject to coverage and may be changed from time to time. Reception may depend on the type and condition of your existing aerial. Aerial upgrade may be required.
-
Page 4: System Requirements
PCI Express Hybrid ATSC/QAM X8550A V1.3.08002.02101 Defining HD 750PEC HD 750PEC s fully is a small board that is plugged into a PCI Express slot of your computer. It’ compatible with your desktop PC use. Let you enjoy digital (FTA) Radio and TV programs and Analog TV programs. -
Page 5: Package Contents
PCI Express Hybrid ATSC/QAM X8550A V1.3.08002.02101 Drivers) One free PCI Express interface Sound card for audio Supported operating systems: Windows 2000 Professional/Server (Service Pack 4 required) Windows XP Home/Professional (Service Pack 2 required) Windows Vista Additional requirements: DirectX 9 or higher MediaPlayer 9 or higher At least 10GB hard disc space or above, that’s necessary for DVR functionality Additional system requirements for PCI Express devices... -
Page 6: Installing The Driver And Software
PCI Express Hybrid ATSC/QAM X8550A V1.3.08002.02101 Installation of the PCI Express device To install the Hybrid ATSC/QAM HD 750PEC PCI Express board make certain that the computer is turned off. Precede the following steps to install the PCI Express card into your PC system: 1. - Page 7 PCI Express Hybrid ATSC/QAM X8550A V1.3.08002.02101 Step2: When insert CD, OS will promote setup automatically Step3: Run “Software Install” Computer will now automatically show an install page, click “Next”...
- Page 8 PCI Express Hybrid ATSC/QAM X8550A V1.3.08002.02101 Step4:Click “Install” to continue installation driver Step5: OS will promote to install devices Click “Continue Anyway”...
- Page 9 PCI Express Hybrid ATSC/QAM X8550A V1.3.08002.02101 Step6: Click “Finish” to completely install the Driver Software Installing TotalMedia Step7: Installation of Total Media, Choose setup languag...
- Page 10 PCI Express Hybrid ATSC/QAM X8550A V1.3.08002.02101 Step8: Click “Next” to continue installation Step9: Click “Yes” and then it will install “Arcsoft TotalMedia” Step10: If you want to change the destination folder, please click “Browse” and click “next” (Recommended is better)
- Page 11 PCI Express Hybrid ATSC/QAM X8550A V1.3.08002.02101 Step11: Please click “Next” Step12: Program starts to copy files.
- Page 12 PCI Express Hybrid ATSC/QAM X8550A V1.3.08002.02101 Step13: Click “Finish”, the Arcsoft TotalMedia software is installed on your computer. Step14: Click “Next” to continue installation “IR Receive”...
- Page 13 PCI Express Hybrid ATSC/QAM X8550A V1.3.08002.02101 Step15: If you want to change the destination folder, please click “Browse” and click “Next” (Recommended is better) Step16: Click “Finish”, the “IR Receive” software is installed on your computer.
- Page 14 PCI Express Hybrid ATSC/QAM X8550A V1.3.08002.02101 Step17: You will see that ATSC application icons will appear on your desktop. Step18: You will see that Remote application icons will appear on your desktop. Step19: When all finished, please check on Control panel, select “System”—“System properties”—“Device Manager”, you can see one device installed.
- Page 15 PCI Express Hybrid ATSC/QAM X8550A V1.3.08002.02101 Arcsoft Total Media Users How to use TotalMedia, you can get online help. Connection Summary HD 750PEC Connection (Only ATSC) 1. Connecting ATSC/QAM Hybrid HD 750PEC TV Receiver to PCI Express interface on your PC...
- Page 16 PCI Express Hybrid ATSC/QAM X8550A V1.3.08002.02101 2. Connecting Analog TV Cable (for analog TV) or digital antenna (for digital TV) to ATSC Hybrid HD 750PEC TV Receiver.
- Page 17 PCI Express Hybrid ATSC/QAM X8550A V1.3.08002.02101 3. When you want to switch Analog, please switch to Analog Cable (ATSC Antenna can’t receive the Analog TV Channel) 4. Input & Output Connections...
- Page 18 PCI Express Hybrid ATSC/QAM X8550A V1.3.08002.02101 Remote Controller Button List TV/AV: Switch between S-Video, Composite, and TV TotalMedia TotalMedia: Open/Close Software 0 - 9: Channel Number Keys ESC: Return MUTE: On/Off volume mute Down Left Right CH+/CH-: Channel Up/Channel Down 9 10 VOL-/VOL+: Volume Down/Volume Up Record: Record/Stop recording the current program...
- Page 19 PCI Express Hybrid ATSC/QAM X8550A V1.3.08002.02101 2. I do find some channels, but this time I get fewer channels than last time 1. Maybe you moved antenna’s position or angle, try to find the better position and keep the antenna vertical 2.
-
Page 20: Technical Support Options
PCI Express Hybrid ATSC/QAM X8550A V1.3.08002.02101 Technical Support Diamond Technical Support staff is here to help resolve any issues that you may be experiencing with the installation of the Diamond product. Prior to contacting technical support please make sure you have the following information available. - Page 21 Diamond product are warranted to be free from defects in materials or workmanship under normal use and service for a period of for (90) ninety days from date of purchase at retail. Diamond ’s sole obligation under this warranty shall be, at Diamond ’s option, to: (i) repair the defective product or part;...
- Page 22 MAINTENANCE, USE, PERFORMANCE, FAILURE, OR INTERRUPTION OF ITS PRODUCTS, EVEN IF DIAMOND, ITS SUPPLIERS OR ITS RESELLER HAS BEEN ADVISED OF THE POSSIBLITY OF SUCH DAMAGES. DIAMOND ’S SOLE LIABILITY WITH RESPECT TO ITS PRODUCT IS LIMITED TO REPAIR OR REPLACEMENT OF THE PRODUCT, AT DIAMOND ’S OPTION. THIS DISCLAIMER OF LIABILITY FOR DAMAGES WILL NOT BE AFFECTED IF ANY REMEDY PROVIDED HEREIN SHALL FAIL FOR ESSENTIAL PURPOSE.
