Table 1: Terminal Identification (See Figure 5.)
Terminal
Number
TEC2627-4
(On/Off or
Floating Control)
4 24 V~ Hot
5 24 V~ Com
6 BO5 Aux
7 BO5 Aux
8 BO3
9 BO4
10 BO1
11 BO2
12 BI1
13 RS
14 Scom
15 BI2
16 UI3
Blank +, –, REF
©2016 Johnson Controls | The performance specifications are nominal and conform to acceptable industry standards. For applications at conditions beyond these specifications, consult the local
Johnson Controls office. Johnson Controls, Inc. shall not be liable for damages resulting from misapplication or misuse of its products.
®
BACnet MS/TP Networked Thermostat
TEC - 2647 - 4
Terminal Label
TEC2647-4
(Proportional
0 to 10 VDC Control)
24 V~ Hot
24 V~ Com
BO5 Aux
BO5 Aux
Blank
AO2
AO1
Blank
BI1
RS
Scom
BI2
UI3
+, –, REF
Installation / Operation Manual
Function
24 VAC from Transformer
24 VAC (Common) from Transformer
Aux BO (Auxiliary Output)
Aux BO (Auxiliary Output)
Open Heat
Close Heat
Open Cool
Close Cool
Configurable Binary Input 1
Remote Sensor
Sensor Common
Configurable Binary Input 2
Configurable Universal Input 3
MS/TP Bus
