GTStar ZX User Manual

GTSTAR NEW 4G TRACKER
USER MANUAL (ZX)
Preface
Thank you for purchasing the tracker. This manual shows how to operate the device
smoothly and correctly. Make sure to read this manual carefully before using this
product. Please note that specification and information are subject to changes without
prior notice in this manual. Any change will be integrated in the latest release. The
manufacturer assumes no responsibility for any errors or omissions in this document.
1.Summary
Working Based on existing 4G/3G/2G (4G Version FDD-LTE/TDD-LTE) network and
GPS satellites, this product can locate and monitor any remote targets by SMS or
internet. The most advanced technology of GPS and AGPS dual positioning.

2. Applications

• Vehicle rental / Fleet management etc
• Outdoor sports
• Protect child / the elder/ the disabled / pet etc
• Provide peace-of-mind for businessmen
• Personnel Management
• Criminals Tracking

3. Hardware Description

Content
4G: FDD-LTE:B1 B2 B3 B4 B5 B7 B8 B12(17) B20 B28
TDD-LTE: B38 B39 B40 B41
Network
Frequency error
GPS chip
GPS sensitivity
GPS accuracy
Time To First Fix
Battery
Build-in 3.7V Voltage Polymer battery
Storage Temp
Operation Temp
Humidity
4.Usage
• Please charge 12hours at first use.
• Insert SIM card in right way. Please put the unit outside and make
sure the trademark side facing up.
• Confirm your SIM card have calling, send SMS function.
• Confirm your SIM card have enough balance (money).
• Confirm your SIM card can show caller ID and don not use call forwarding function.
Specs
3G:WCDMA:B1/B5/B8
2G:900/1800 MHz
±0.1ppm
Spreadtrum SC9820ES
-159dBm
5--10m
Cold status 35-80s
Warm status 35s
Hot status 1s
-40°C to +85°C
-20°C to +55°C
5%--95% non-condensing
- 1 -
5.Battery And Charger
Do charge the battery to capacity in 8 -12 hours for first time. Please use the battery
and charger provided by the manufacturer. This unit adopts built-in Li-ion battery.
Cautions:
a: For it's Polymer battery, which contains harmful chemicals and may burst, please
don't bump, puncture it violently and keep it off fire.
b: Please charge the battery in time to keep it working normally.
6.Startup Steps
• Put the SIM card and battery in place.
• Turn on the unit outdoors by pressing the "On/Off" button until the indicator is on.
(some of model just need to insert the sim card, it willbe turn on by itself).
• For first use, please initialize the unit and restore it to default setting.
• In 10 or 40 seconds, the unit will begin to work and acquire the GSM signals as
well as the GPS signals. The indicator will keep flashing every 3 seconds when the
unit has received the signals.
• When this unit receives GPS signals normally, you can use it and do any setting as
the instructions of this manual.
A: Set admin number,by sending a SMS command to the SIM card inside device. For
example: admin123456 +86186*********(+86186********should be your phone
number)
B: Set APN: APN123456 CMNET (please use your local APN instead of CMNET,if you
do not know the APN content,you should contact your SIM card supplier)
Green LED for Network working status
Status of indicator
Slow flash (flash 1s after every 2s)
Continuously in bright status
Green Led off
Blue LED for GPS working status
Status of indicator
Slow flash (flash 1s after every 2s)
Continuously in bright status
Blue led off
Red LED for GPS working status
Status of indicator
Red led on all the time
Red led flash
Red led off
Meaning
GSM/GPRS(WCDMA)conversation start
No Network signal
Device fault or dormant
Meaning
GPS location successful
Searching GPS signal
Device fault or dormant
Meaning
Charging
Low battery
Full battery or charged full
- 2 -
