- Page 1 AF03GT Program for weighbridges CALIBRATION METHOD - v7 MANUALE D’USO ITALIANO ENGLISH For 3590 series touch screen indicators www.diniargeo.com...
- Page 3 Index Calibration of a channel connected analogue weighbridge Analogue calibration with equalisation Setting and calibration of digital cell weighbridges Calibration of a WWS wireless weighing system Calibration of a dual digital weighbridge system Calibration of a dual scale system consisting of wireless WWS platforms AF03GT TECH_MAN_CAL_ENG_AF03GT_v7...
- Page 4 Calibration of a channel connected analogue weighbridge PREMISE CASE 1: An indicator connected to a weighbridge. Load cells Weighbridge Junction box CASE 2: An indicator connected to a scale composed of several weighbridges in series (up to 48 1000 Ohm cells). BOOT Procedure: With switched-off indicator and power supply unplugged, connect the weighbridge to the indicator.
- Page 5 Turn on the indicator, enter the setup menu and check that the signal coming from the weighbridge is stable and increases with weight increase. 15000 Technical set-up Diagnostics SCALE 1 d=74 Channel 344673 308333 308333 Diagnostic Weight test ADC-mV Select the number of weighbridges and each weighbridge load cell type. Calibration Scale selection Number of scales...
- Page 6 Calibration Scale configuration Scale configuration Calibration points Calibration Calibration Zero acquisition. Unload the platform and press Zero acquisition underway the OK button. Please wait... Bilancia 1 Calibrazione Calibrazione Cancel ADC=308261 BkSp 9. Load the weighbridge and distribute the mass evenly. Calibration Scale configuration Point 1 weight...
- Page 7 Repeat the procedure from step for calibration of the second weighbridge (if present). Perform backup Technical set-up Backup & Restore Backup & Restore Configuration backup Backup all settings? Backup & Restore Backup of the configuration Calibrazione It is possible to enter a protection password to restore the stored parameters. Backup of the configuration (*) Saving has completed correctly only if the asterisk is present: Receive calibration with Dinitools.
- Page 8 Analogue calibration with equalisation PREMISE CASE 1: The weighbridge load cells are connected to the 4 indicator channels. Load cells Weighbridge CASE 2: Scale composed of various weighbridges in sequence, each connected to a channel of the indicator. Up to 48 1000 Ohm cells.
- Page 9 Select the number of scales and load cell type. Calibration Scale selection Number of scales = Analogue Type of load cell Scale selection Number of channels (Scale 1) = 2 ... 4 Set scale metric parameters (capacity/division) etc. Calibration Scale configuration Parameters Number of decimals Unit of measure...
- Page 10 Calibration Scale configuration Scale configuration Calibration Insert the number of calibration points other than the zero. Scale 1 Calibration Calibrazione Cancel Calibration Scale configuration Scale configuration Calibration points Calibration Calibration Zero acquisition. Unload the platform and press Zero acquisition underway the OK button.
- Page 11 Perform backup Technical set-up Backup & Restore Backup & Restore Configuration backup Backup all settings? Backup & Restore Backup of the configuration Calibrazione It is possible to enter a protection password to restore the stored parameters. Backup of the configuration (*) Saving has completed correctly only if the asterisk is present: Receive calibration with Dinitools.
- Page 12 Setting and calibration of digital cell weighbridges PREMISE CASE 2: BOOT RS485 RS485 Load cells Weighbridge Junction box Procedure: With switched-off indicator and power supply unplugged, connect the scale to the weighing terminal 3590. SENSOR Chip 485 RS232 COM3 SIG- SIG+ EXC- EXC+...
- Page 13 Scale selection Serial number configuration = Enter for each load cell its serial number, Serial number configuration Cell n displayed on the casing of the cell. Address assignment Perform the load cell automatic numbering procedure: Serial number configuration Cell n = The indicator assigns to each load cell its number, which will identify it in each Address assignment programming or diagnostics menu.
- Page 14 Example of a 4 cell weighbridge: equalisation aims to Example of an 8 cell weighbridge: equalisation aims to optimise each cell of the scale. optimise each cell of the scale = 1/8 Max (kg) = 1/8 Max (kg) Perform calibration. Calibration Scale configuration Scale configuration...
- Page 15 Calibration Scale configuration Scale configuration Calibration Calibration Calibration Acquisition of point 1 underway. Calibration terminated Acquisition of point 1. Please wait... successfully. Load the platform with 30000kg Punti / div = 84 and press the OK button. ADC=308261 Bilancia 1 Calibrazione Calibrazione Cancel...
- Page 16 Calibration of a WWS wireless weighing system PREMISE System diagram: This configuration lets you manage up to 16 platforms. +BAT +Vaux OUT1 Procedure : OUT2 OUT3 Calibrate and set metric parameters of each WWS platform. Check that each platform is configured on the same OUT4 radio channel (channel “0”) With indicator switched-off and disconnected from the electrical grid, connect the radio module to the AUX port.
- Page 17 Set the instrument’s radio channel Technical setup Serial ports Radio Frequency interface Input texts Serial ports function mode Communication port Serial ports Printer port configuration Printout Pc port configuration Ext. keyboard - Barcode reader Auxiliary port configuration Remote scale Radio Frequency interface Digital outputs Communication port Radio Frequency interface...
- Page 18 This operation overwrites the data in the memory. If WWS platforms are approved for use in relation with third parties: • total system capacity must be equal to the sum of each individual WWS platform’s capacity. • system division must be equal to the sum of each individual WWS platform’s division rounded up to the highest one. •...
- Page 19 It is possible to enter a protection password to restore the stored parameters. Backup of the configuration (*) Saving has completed correctly only if the asterisk is present Receive calibration with Dinitools. Exit setup and save. Technical set-up Technical set-up Technical set-up Setup changed.
- Page 20 Calibration of a dual digital weighbridge system PREMISE System diagram: Weighbridge RS485 Load Junction cells It is possible to install weighing systems with more than one weighbridge based on the number of cells of each (Max. 16 digital cells, max. 8 CCI AD cells). With this configuration the weight of each platform is displayed separately.
- Page 21 Procedure: With switched-off indicator and power supply unplugged, connect the scale to the weighing terminal 3590. SENSOR Chip 485 RS232 SIG- COM3 SIG+ EXC- EXC+ CH4 CH3 CH2 CH1 RS232 RS232 COM1 COM2 Dip switch to enable termination resistor. For digital cells operation installation of chip 485 is required.
- Page 22 Set digital cell serial number. Premise Number the load cells for easier identification during maintenance, for example: Scale selection Serial number configuration = Enter for each load cell its Serial number configuration Cell n serial number, displayed on the casing of the cell. Address assignment Perform the load cell automatic numbering procedure: Serial number configuration...
- Page 23 Perform equalisation following the indicator’s guided procedure. Scale configuration Scale configuration Equalisation Excute load cells equalization? Equalisation For CASE 1: equalisation aims to optimise the angles of the scale. = 1/8 Max (kg) For CASE 2: equalisation aims to make each weighbridge the same, in order for the weight measured on each individual one to be the same.
- Page 24 9. Load the weighbridge and distribute the mass evenly. Calibration Scale configuration Point 1 weight Calibration 30000 999999 Acquisition of point 1. Insert the weight value. Bilancia 1 Calibrazione Cancel BkSp Calibration Scale configuration Scale configuration Calibration Calibration Calibration Acquisition of point 1 underway. Calibration terminated Acquisition of point 1.
- Page 25 Perform backup Technical set-up Backup & Restore Backup & Restore Configuration backup Backup all settings? Backup & Restore Backup of the configuration Calibrazione It is possible to enter a protection password to restore the stored parameters. Backup of the configuration (*) Saving has completed correctly only if the asterisk is present: Receive calibration with Dinitools.
- Page 26 Calibration of a dual scale system consisting of wireless WWS platforms PREMISE System diagram: This configuration lets you manage up to 16 platforms. Scale 1 Traction unit Bilancia 2 Trailer Trailer Traction unit With this configuration the weight of each platform is displayed separately. GROSS Weight “A”, Weight “B”...
- Page 27 +Vaux Procedure: OUT1 Calibrate and set metric parameters of each WWS platform. Check that each platform is configured on the same radio channel OUT2 (channel “0”) OUT3 With indicator switched-off and disconnected from the electrical grid, connect the radio module to the AUX port. OUT4 CPU Board Radio module...
- Page 28 Establish communication between indicator and WWS platform. 2. Set the gravity value of the area of use. WWS configuration WWS configuration Gravity value Remote WWS configuration 9.80390 WWS configuration acquisition 9.75001 ~ 9.84999 = Acquires metric parameters from the WWS and modifies them on the BkSp indicator.
- Page 29 How to display the sum of “A”+”B” With this configuration it is possible to display simultaneously the weights of the two platforms and their sum. Technical set-up A+B function mode AF03 functions Disabled Enabled AF03 functions A+B function mode Cancel Perform backup Technical set-up Backup &...
- Page 30 Notes This publication, or portions thereof, may not be duplicated without written permission from the Manufacturer. All information herein is based on the data available at the time of publication. The Manufacturer reserves the right to make changes to its products at any time without notice and without incurring any penalty.
-
Page 32: Service Assistance
Authorised service centre stamp HEAD OFFICE Via Della Fisica, 20 41042 Spezzano di Fiorano, Modena - Italy Tel. +39 0536 843418 - Fax +39 0536 843521 SERVICE ASSISTANCE Via Dell’Elettronica, 15 41042 Spezzano di Fiorano, Modena - Italy Tel. +39 0536 921784 - Fax +39 0536 926654 www.diniargeo.com...
