USER MANUAL
INDICATOR, REPEATER, TRANSMITTER OF WEIGHT "DFW"
Review
Last update
SERIES
3.17
18/11/2014

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DFW and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Dini Argeo DFW

  • Page 1 USER MANUAL INDICATOR, REPEATER, TRANSMITTER OF WEIGHT “DFW” SERIES Review 3.17 Last update 18/11/2014...
  • Page 2 Page intentionally left blank...
  • Page 3: Table Of Contents

    USER MANUAL SERIES INDICATORS DFW Index INTRODUCTION ............................6 MAIN TECHNICAL SPECIFICATION ......................8 WIRING AND POWER ..........................9 CONNECTING THE WEIGHING SYSTEM ....................9 POWER SUPPLY ............................ 9 3.2.1 INTERNAL POWER CONNECTION 110-240 VAC ................9 3.2.2 CONNECTING EXTERNAL POWER SUPPLY 110-240 VAC ............. 10 3.3 BATTERY POWER ............................
  • Page 4 6.2.3 CANCELLING A TARE ........................25 6.2.4 AUTOMATIC/LOCKED/UNLOCKED/DISABLED TARE SELECTION ..........26 LIMITATION OF THE TARE FUNCTIONS ....................26 AUTO POWER OFF FUNCTION ......................26 AUTOMATIC STAND-BY FUNCTION ....................27 DIVISION OF FLOW IN MOST FIELDS ....................27 REMOTE CONTROL (OPTIONAL) ......................27 6.7.1 NINETEEN-KEY IR REMOTE CONTROL ..................
  • Page 5 USER MANUAL SERIES INDICATORS DFW 8.7.1 SAMPLING PROCEDURE ....................... 39 8.7.2 ERROR “” DUE TO WEIGHT INSTABILITY DURING THE SAMPLING AND MINIMUM WEIGHT OF THE SAMPLE ......................... 39 8.7.3 SETTING THE SAMPLING INTERVAL ..................... 39 8.7.4 PRINTING ............................. 40 DISPLAY WITH SENSITIVITY X 10 ()(TO BE USED IN TESTING DURING THE CALIBRATION) ..40 HOLD: FREEZING THE WEIGHT ON THE DISPLAY () ..............
  • Page 6: Introduction

    INTRODUCTION The purpose of this manual is to help the user get to know the weight indicator’s various functioning modes, the keys’ functions and the display indications. We advise to carefully follow the instructions for programming the weight indicator; by taking actions not indicated this manual, one could cause the scale to not work properly.
  • Page 7 INTRODUCTION The crossed-out wheeled bin on the product means that at the product end of life, it must be taken to separate collection or to the reseller when a new equivalent type of equipment is purchased. The adequate differentiated refuse collection in having the product recycled, helps to avoid possible negative effects on the environment and health and supports the recycling of the materials of which the equipment is made.
  • Page 8: Main Technical Specification

    MAIN TECHNICAL SPECIFICATION MAIN TECHNICAL SPECIFICATION Supply Model Internal power External power Battery 4 batteryes Power Recharger supply supply internal type supply 110-240Vac 110-240Vac rechargeable “AA” from PC via 50-60Hz 50-60Hz connector • • DFWL • • DFWLB • • DFWLI •...
  • Page 9: Wiring And Power

    WIRING AND POWER WIRING AND POWER CONNECTING THE WEIGHING SYSTEM The connection of the system depends on the weighing platform and indicator model purchased If required, connect the cable from the weighing system to the connector on the cable from the indicator of weight or place directly on it.
  • Page 10: Connecting External Power Supply 110-240 Vac

    WIRING AND POWER 3.2.2 CONNECTING EXTERNAL POWER SUPPLY 110-240 VAC Connect the power supply to the mains (110-240 VAC) and the plug to the socket on the indicator. Example 1 Plug power supply Socket on the indicator Esempio 2 Plug power supply Socket on the indicator BATTERY POWER The instrument may provide for the use in battery (refer to the table in paragraph 2).
  • Page 11: Power Supply With 4 Batteries Type "Aa

    WIRING AND POWER Make the complete recharge of the battery (12 hours) at the first installation of the instrument. To avoid the deterioration of the rechargeable battery: - In condition of normal use is recommended to never leave it partially or fully discharged; fully recharge it at least once a week.
  • Page 12: Indicator Connected To The Printer, Battery Operated

    WIRING AND POWER For correct reporting of the charge may be necessary to set the type of power ( The display also indicates when the battery is being charged:     STEP CHARGING: … CHARGING COMPLETE: During recharging, the instrument can normally be used. The instrument switches off automatically when the voltage drops belove the minimum level.
  • Page 13: Turning On / Off The Instrument

    TURNING ON / OFF THE INSTRUMENT TURNING ON / OFF THE INSTRUMENT TURNING ON TO TURN ON the instrument press the C key until the indicator turns on; then release. The display shows  is the installed software version The instrument turns on all the display segments and symbols Then displays ...
  • Page 14: Front Panel Keys And Indicators

    LEDS, if present, will be active during weighing to indicate the operative status (see paragraph “WARNING LAMPS”). If the indicator has an LCD display, while weighing, various multifunction symbols indicating the functioning status will turn on (see section “SYMBOLS ON THE LCD DISPLAY”). FRONT PANEL KEYS AND INDICATORS (5 key version) DFW LCD DISPLAY VERSION...
  • Page 15 FRONT PANEL KEYS AND INDICATORS DFW LED DISPLAY VERSION SCALE KEY FUNCTION - Zeros the displayed gross weight, if it is within +/- 2% of the total capacity. ZERO - Cancels the negative tare value. - When entering numbers it decreases the digit to be modified.
  • Page 16: Numeric Input With The 5-Key Keypad

    FRONT PANEL KEYS AND INDICATORS - It carries out a specific function of the operating mode set in the set-up environment. - In the numeric input phase, it confirms the entry made. - In the SET-UP, it allows to enter a step or to confirm a parameter within a step. ENTER / PRINT - It transmits the data from the serial port dedicated to the printer.
  • Page 17: Key Function In The Version 17-Key

    FRONT PANEL KEYS AND INDICATORS KEY FUNCTION IN THE VERSION 17-KEY Example of a 17-key keypad, picture 1 Example of a 17-key keypad, picture 2...
  • Page 18 FRONT PANEL KEYS AND INDICATORS SCALE KEY FUNCTION - Zeros the displayed gross weight, if it is within +/- 2% of the total capacity. - Cancels the negative tare value. ZERO - When entering numbers it decreases the digit to be modified. - If pressed for an instant it carries out the semiautomatic tare.
  • Page 19: Mode Key Function

    FRONT PANEL KEYS AND INDICATORS MODE KEY FUNCTION /  Function Effect Effect MODE STANDARD Switch Kg/Lb → MODE NET /GROSS Switch Net/Gross → ENTER ENTER SETPOINT Type value   ENTER MODE IN /OUT In weigh Out weigh  →...
  • Page 20: Function F / Fn Button In Combination With Numeric Keys

    FRONT PANEL KEYS AND INDICATORS FUNCTION F / FN BUTTON IN COMBINATION WITH NUMERIC KEYS Effect Continue with Lock/unlock ENTER Recall tare (database) Type memory (1..30)  Lock/unlock tare ENTER Enter ID Type memory (1 or 2)  Lock/unlock ID Piece counting Type piece counting Totalizer...
  • Page 21: Keyboard Lock

    FRONT PANEL KEYS AND INDICATORS KEYBOARD LOCK It is possible to disable the keyboard functions in order to avoid accidental pressing of the keys. It’s possible to lock the keyboard in two different ways: a) Enabling in SETUP ( ) the function of automatic keyboard lock, after 15 seconds of inactivity of the keyboard in weighing, the keyboard is automatically locked (the message “”...
  • Page 22: Symbols On The Lcd Display

    FRONT PANEL KEYS AND INDICATORS SYMBOLS ON THE LCD DISPLAY The LCD display has symbols which show the indicator’s functioning status; you will find the description for each symbol below. NUMBER SYMBOL FUNCTION 0 The weight detected on the weighing system is near zero, within the interval of –1/4 ÷...
  • Page 23: Letters And Numbers Shown On The Lcd/Led Display

    FRONT PANEL KEYS AND INDICATORS (10) The manual tare is active. The instrument is in the first weighing range. (11) The instrument is in the second weighing range. The instrument is in the third weighing range. LETTERS AND NUMBERS SHOWN ON THE LCD/LED DISPLAY LETTERS A B C D E F G H I K L M N O P Q R S T U V W X Y Z...
  • Page 24: Intensity Backlight / Led

    FRONT PANEL KEYS AND INDICATORS INTENSITY BACKLIGHT / LED The brightness of the backlight (LCD display) or LED (red LED display) is customizable from setup. In the “Crane” series, a long pressure of the Zero button will launch a menu in which intensity can be set. In other indicators, except the wheel weighing ones, a long pressure of the F button will launch that menu.
  • Page 25: Basic Functions

    BASIC FUNCTIONS BASIC FUNCTIONS ZERO SCALE By pressing the ZERO key, it is possible to zero a gross weight value which is within +/- 2% of the capacity; after the zeroing, the display shows 0 weight and the relative pilot lights are turned on. TARE OPERATIONS 6.2.1 SEMI-AUTOMATIC TARE...
  • Page 26: Automatic/Locked/Unlocked/Disabled Tare Selection

    BASIC FUNCTIONS 6.2.4 AUTOMATIC/LOCKED/UNLOCKED/DISABLED TARE SELECTION By pressing the keys F and 2 in the indicator to 17 keys or by pressing the MODE key twice in succession, you can quickly select the mode of operation of the tare:  LOCKED TARE: when a tare value has been acquired or entered (manually or from memory), after unloading the scale, the display shows the tare value with a negative sign.
  • Page 27: Automatic Stand-By Function

    BASIC FUNCTIONS AUTOMATIC STAND-BY FUNCTION It is possible to enable in SETUP ( ) the automatic stand-by function of the indicator. The instrument is normally in stand-by (the display is turned off except for the point): at the pressure of any button for an instant appears the message “”, then the weight on the scale is displayed for 30 seconds;...
  • Page 28: Nineteen-Key Ir Remote Control

    BASIC FUNCTIONS 6.7.1 NINETEEN-KEY IR REMOTE CONTROL The remote control is designed for indoor use / not in the light of the sun Through the remote control with 19-keys is possible to remotely the functionality of all the keys, including numeric, both in SHORT pressure, both in LONG pressure and correspond to the following key keys indicator: REMOTE KEY...
  • Page 29: Date/Time Adjustment (Optional Or Included Depending On The Model)

    BASIC FUNCTIONS While setting up the remote control ( ) is also possible select whether: a) Use multiple remotes with a single indicator, without associating to it, therefore without limit the number of remote controls used. b) Use different indicators in the same area, matching each remote control to the desired indicator, in order to execute the function only on it and thus avoid that the function is repeated on all indicators in use.
  • Page 30: Conditions For Performing The Weigh And Prints

    BASIC FUNCTIONS detected, or a key is pressed, the indicator returns to view the current weight. 6.10 CONDITIONS FOR PERFORMING THE WEIGH AND PRINTS If a printer is connected, it is possible to print the programmed weight data, for example: - 4 heading lines of 24 characters - GROSS weight - TARE weight...
  • Page 31: Reenabling The Printouts And The Indicator Functions

    BASIC FUNCTIONS 6.11 REENABLING THE PRINTOUTS AND THE INDICATOR FUNCTIONS While using the indicator, it is possible to incur into the “”error shown on the display along with an acoustic signal; this means that the printing or the function which one wants to carry out must be reenabled (in order to avoid unwanted executions).
  • Page 32: Additional Functions Of The 17-Key Indicator

    ADDITIONAL FUNCTIONS OF THE 17-KEY INDICATOR ADDITIONAL FUNCTIONS OF THE 17-KEY INDICATOR STORED TARE MEMORY VALUES It’s possible to store up to 30 tare memory values, identified by the location numbers 1 to 30, which the user can recall when needed. To insert or modify a tare value: - press the keys “F”+ “9”...
  • Page 33: Locked / Unlocked Code Selection

    - By turning off the instrument, the information relative to the last printout made, will be lost; therefore this function is not enabled until the first printout is made. - This function is available only in the DFW type indicators. SELECTABLE OPERATING MODES PREMISE: For the indicator functions in the “Weight repeater”...
  • Page 34: Unit Of Measure/Pounds Conversion ()

    SELECTABLE OPERATING MODES - HORIZONTAL TOTALIZER - VERTICAL TOTALIZER - PIECE COUNTING. The operating mode is selectable in the Setup environment ( UNIT OF MEASURE/POUNDS CONVERSION () By pressing the MODE key the weight conversion between the scale unit of measure and lb is made and vice versa.
  • Page 35: Input/Output ()

    SELECTABLE OPERATING MODES present). - Once finished the programming of the set points, one should exit with the C key to return to weighing. INPUT/OUTPUT () Simple display functioning mode with in / out weighing function: the indicator acquires two weight values through the confirmation of the operator and calculates the difference, automatically printing the data (if the presence of a printer has been configured).
  • Page 36: Reading Of The Weighs Carried Out

    SELECTABLE OPERATING MODES After the button ENTER/PRINT is pressed: the indicator transmits on the PC serial the gross weight, " the tare, an ID code that uniquely identifies the weight; in addition the display show the message " for about 2 seconds. The storage when pressing ENTER/PRINT follows the same conditions for the implementation of weighing and printing, refer to paragraph “CONDITIONS FOR PERFORMING THE WEIGH AND PRINTS”.
  • Page 37: Tolerance Check ()

    SELECTABLE OPERATING MODES +/- TOLERANCE CHECK () In this operating mode the instrument is able to perform a control tolerance and indicate the tolerance level reached at the display and, where provided, on a light or external device, through the use of four optional outputs.
  • Page 38: Acoustic Signal

    SELECTABLE OPERATING MODES Weight level on scale Display message Active STANDARD BACKLIGHT COLOR alternating to weight outputs DFWLID/ DFWLIDCC (if enabled in setup) WEIGHT BELOW THE CHECK TRESHOLD  ≤  None None WEIGHT OVER THE CHECK TRESHOLD BUT HIGHER THAN TRESHOLD ...
  • Page 39: Sample Weight Percentage ()

    SELECTABLE OPERATING MODES SAMPLE WEIGHT PERCENTAGE () In this operating mode, the instrument shows on the display the net weight expressed as a percentage, comparing it with a reference weight which has been previously linked to a percentage. 8.7.1 SAMPLING PROCEDURE With the 5-key indicator Place the empty container on the scale and press TARE to tare it.
  • Page 40: Printing

    SELECTABLE OPERATING MODES greater will the sampling be accurate. With the 5-key indicator, setting the sampling time is only possible in the setup environment ( 8.7.4 PRINTING If the presence of a printer has been configured and a sampling was performed, the execution of the weight using the key ENTER/PRINT, will run a print showing also the percentage quantity present on the scale, in addition to the programmed data.
  • Page 41: Weight Peaks Detection ()

    SELECTABLE OPERATING MODES 8.10 WEIGHT PEAKS DETECTION () It is possible to use the instrument to store the maximum weight value measured during the weigh (PEAK), useful to measure, for example, the breaking load of the materials. By pressing the MODE key, the peak mode is enabled; on the LED display the maximum weight reached will be displayed, alternated with the message ””, every 5 sec.
  • Page 42: Horizontal Totalizer (Sum Of Lots)

    SELECTABLE OPERATING MODES 8.11 ) HORIZONTAL TOTALIZER (Sum of lots) ( In this mode it is possible to score a weight manually or automatically depending on the setting in the setup. 8.11.1 TOTALISATION OPERATIONS In order to carry out the totalisation it is necessary: - to load the weight on the scale - press the MODE key (if the automatic totalisation has not been set) The weight is accumulated in two total levels (a partial total and a general total).
  • Page 43: Totalisation With Printing

    SELECTABLE OPERATING MODES 8.11.3 TOTALISATION WITH PRINTING If it has configured the presence of a printer at the execution of the weigh will be run a print showing also the number of weighing, in addition to the data programmed in SETUP . 8.11.4 PRINTING AND ZEROING OF THE TOTALS The instrument has two different total levels, a partial total and a general total, which increase upon each...
  • Page 44: Memory Storages (Only For 17-Key Indicator)

    SELECTABLE OPERATING MODES A value of 0 disables the function. The changed parameters are not stored permanently in the memory of the indicator; if you want to permanently store these settings, you must edit in the indicator’s SETUP. 8.11.6 MEMORY STORAGES (only for 17-key indicator) It is possible to memorize the weigh totalisation in one of nine memory storages (identified from 1 to 9): - Press in sequence the F and 5 keys;...
  • Page 45: Error "" For Weight Instability During The Sampling And Minimum Weight Of The Sample

    SELECTABLE OPERATING MODES Add the rest of the items to count in the container and whose value will appear on the display. Unload the scale, the APW will remain stored in memory for the next counting of similar pieces, without having to repeat the REFERENCE operation. By pressing the MODE key one switches from the display of the number of pieces to the display of the net weight and vice versa.
  • Page 46: Counting With Introduction Of The Average Piece Weight

    SELECTABLE OPERATING MODES 8.13.4 COUNTING WITH INTRODUCTION OF THE AVERAGE PIECE WEIGHT It is possible to view or to enter through the keyboard a APW known to accelerate the reference operations: - With the scale at zero, after having stored a tare, press “F” + “6”, or the ENTER/PRINT key at length. - The display will indicate "...
  • Page 47: Use The Indicator As Weight Repeater

    USE THE INDICATOR AS WEIGHT REPEATER USE THE INDICATOR AS WEIGHT REPEATER If it has purchased the indicator in the repeater version, the indicator can play a function in the choice between the following: UNIVERSAL SINGLE SCALE WEIGHT REPEATER WEIGHT REPEATER MULTISCALE The operating mode is selectable in the Setup environment ( UNIVERSAL SINGLE SCALE REPEATER () Through this way of operation it is possible to use the indicator to repeat the weight of any scale, but...
  • Page 48: Operation

    USE THE INDICATOR AS WEIGHT REPEATER Morover, it is possible to realize a network with a MASTER, which performs remotely functions of the connected scales, and one or more REPEATERS, having the only function to repeat the weight. 9.2.1 OPERATION When turned on, the MASTER predisposes himself to the connection with the present SLAVES (the message “...
  • Page 49: Slave Selection / Sum

    USE THE INDICATOR AS WEIGHT REPEATER 9.2.3 SLAVE SELECTION / SUM If more slaves are configured, it is possible to toggle the viewing on a single SLAVE or on the SUM. With the 5-key indicator - Pressing the MODE key it toggles SLAVE in SLAVE in order of address: the display shows “ ”...
  • Page 50 USE THE INDICATOR AS WEIGHT REPEATER - scale number or text indication “” - indication of PARTIAL TOTAL indicated by an asterisk next to the number of scales or text “” - date and hour - net weight (equal to the gross weight, even if the tare is done) - tare weight (always equal to zero).
  • Page 51: Turning Off The Master And Slaves

    USE THE INDICATOR AS WEIGHT REPEATER  Print of the weighs list: pressing the ENTER/PRINT key, the message “” appears, pressing the ENTER/PRINT key to confirm (the message “” appears) or the C key to exit from the step without print. If confirm with ENTER/PRINT but the list is empty, the message “”...
  • Page 52: Instrument Messages While In Use

    INSTRUMENT MESSAGES WHILE IN USE INSTRUMENT MESSAGES WHILE IN USE MESSAGE DESCRIPTION  The scale is zeroing the weight.  It is displayed when one selects the alibi memory functioning mode, and upon start-up, the alibi memory is not connected or there are communication problems between the indicator and the board.
  • Page 53 INSTRUMENT MESSAGES WHILE IN USE  Date/time not set: check the  >>  step of the set-up (  It is displayed if one tries to calibrate the zero point without first having confirmed the number of calibration points. ...
  • Page 54 DECLARATION OF CONFORMITY This device conforms to the essential standards and norms relative to the applicable European regulations. The declaration of Conformity is available in the site web www.diniargeo.com. WARRANTY The TWO YEARS warranty period begins on the day the instrument is delivered. It includes spare parts and labour repair at no charge if the INSTRUMENT IS RETURNED prepaid to the DEALER’S PLACE OF BUSINESS.
