KEDACOM
User Manual for
Data Docking Station ZCS-KDCA1
V2 (August, 2018)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ZCS-KDCA1 and is the answer not in the manual?

Questions and answers

Related Manuals for Kedacom ZCS-KDCA1

Summary of Contents for Kedacom ZCS-KDCA1

  • Page 1 KEDACOM User Manual for Data Docking Station ZCS-KDCA1 V2 (August, 2018)
  • Page 2 Trademark Kedacom™ and are trademarks of Suzhou Keda Technology Co., Ltd. in China and various other countries. All other trademarks mentioned in this document are the property of their respective holders. Suzhou Keda Technology Co., Ltd. 131 Jinshan Road New District, Suzhou, 215011 People's Republic of China http://www.kedacom.com/en...
  • Page 3 Target Audience Administrators and Operators of Video Surveillance Products Document Version Applicable Models ZCS-KDCA1 Related Document Quick Start Guide Convention Icon Convention Notices and warning: necessary supplement of operations Sign Convention Menu, e.g. Drag to Zoom Connector between menus of different level, e.g.

  • Page 4: Table Of Contents

    Data Docking Station User Manual Contents Product Introduction ..........................2 Appearance ............................. 2 Specifications ........................... 3 Features ............................3 Startup..............................5 Login ............................... 7 Non-card Login ..........................7 Card Login ............................8 Settings ..............................14 User ............................... 14 4.1.1 Create ............................14 4.1.2 Edit ............................

  • Page 5: Product Introduction

    Multi-point Management Software). User can acquire, upload, store and handle videos, voices and pictures in the BWC through the management platform. The DDS can collect data in BWC and upload it onto DDSMMS. The following will introduce functions of the DDS. 1.1 Appearance Picture 1-1 DDS ZCS-KDCA1...

  • Page 6: Specifications

    When it connects to 24 BWCs, the full load transmission data is no less than 5MB/s  The guide rail is designed especially for KEDACOM BWC; it locks the BWC automatically when it is inserted and input password on the touch panel to unlock ...
  • Page 7  Exported data from BWC will be deleted automatically  User can view information of imported files, including file size, video duration and user info, and can also play the video-audio files  User can upgrade connected KEDACOM BWC...

  • Page 8: Startup

    Start DDS User can start the DDS when it is connected to the power supply and well electrified. Input password “kedacom” to login. Meanwhile, the DDS program is started and a window will pop up as follows. No other operation is needed.
  • Page 9 Data Docking Station User Manual Picture 2-2 Alarm reminder interface of DDS Note: If the User or Device interface prompts “Offline”, no operations can be performed on the interface, as shown in the following pictures. Picture 2-3 Offline...

  • Page 10: Login

    Data Docking Station User Manual 3. Login Different users may have different authorities to perform on DDS. Please refer to Table 4-1 for the details. This manual will introduce all functions of the DDS from the super admin user’s point of view. There are two methods to login.

  • Page 11: Card Login

    Data Docking Station User Manual Picture 3-3 Operator user offline interface 3.2 Card Login After inserting a registered device, tap the card that indicates the device and a window pops up as shown below. Input login password to enter the user interface. Switch to “Unlock” interface and just input unlock password, which is the same as that of login password, to unlock the device.
  • Page 12 Data Docking Station User Manual Picture 3-5 Admin/Super admin user online/offline interface Super admin user can also edit the following setting interfaces while admin user can only view them: Picture 3-6-1 Super admin user settings interface...
  • Page 13 Data Docking Station User Manual Picture 3-6-2 Super admin user settings interface Picture 3-7-1 Admin user settings interface...
  • Page 14 Data Docking Station User Manual Picture 3-7-2 Admin user settings interface The operator user interfaces by card login are as shown below. Picture 3-8 Operator user offline interface...
  • Page 15 Data Docking Station User Manual Picture 3-9 Operator user online interface If the device bound with the user is not connected to the DDS, tap “Apply”. Picture 3-10 Apply Operator user taps “Password” to change login password, as shown below.
  • Page 16 Data Docking Station User Manual Picture 3-11 Change password by operator user Note: Refer to File part for operator user to manage files. When there is BWC inserted, the “Unlock” button shows: tap the button and when the indicator on the top of the device slot flashes, user can pull out the device;...

  • Page 17: Settings

    Data Docking Station User Manual 4. Settings 4.1 User On “User” interface, user can create, edit and remove users. If the system prompts “Offline”, please refer to the alarming part for details. Picture 4-1 User management 4.1.1 Create Tap “Create” and the system pops up a window. Fill in user name, user ID and password, and select authorization.

  • Page 18: Edit

    Data Docking Station User Manual Picture 4-2 Create user 4.1.2 Edit Tap the user to be edited and enter “Edit” interface. Tap “Edit” to edit user info. Refer to Table 4-1 for the parameters. Picture 4-3 Edit user 4.1.3 Remove Tap the user to be removed and enter the following interface.

  • Page 19: Synchronize With Ddsmms

    Data Docking Station User Manual Picture 4-4 Remove 4.1.4 Synchronize with DDSMMS When the DDS is connected to the DDSMMS, pull out all the devices and tap “Syncing” on the top right corner to synchronize users with the DDSMMS. Picture 4-5 Synchronize...

  • Page 20: Device

    Data Docking Station User Manual Note: When the DDS is connected to the DDSMMS, user can neither add nor edit users on DDS, but only synchronize with that of the DDSMMS manually. 4.2 Device 4.2.1 Register BWC Offline When a BWC is offline, user can register it to or delete it from the DDS. Tap “Create”.
  • Page 21 Data Docking Station User Manual Picture 4-9 Status on “Device” interface On the interface of “Slot”, the status of the device is “Registered” and “Asynchronous”. Picture 4-10 Status on “Slot” interface On the homepage, the device is an “Invalid user”. Picture 4-11 Status on homepage...
  • Page 22 Data Docking Station User Manual Tap the card on the interface and enter “User ID” and “Password”. Tap “Bind Device” to bind the device with the user. Picture 4-12 Bind device with user Note: One user can apply to bind with multiple devices. On the homepage, it indicates to pull the device out and insert it again to validate the user.

  • Page 23: Register Bwc Online

    Data Docking Station User Manual Picture 4-14 Validate user After pulling out and inserting the device again, the data on the BWC is synchronized to the DDS. Picture 4-15 Synchronize data of BWC to the DDS 4.2.2 Register BWC Online When a BWC is online, user can register it to the DDSMMS and it will synchronize data of BWC to the DDS automatically.
  • Page 24 Data Docking Station User Manual Picture 4-16 Login to DDSMMS Click Device > BWC, and the following interface will come out. Picture 4-17 Add BWC to DDSMMS Tap “Add”, on the following interface, enter “Channel ID” according to BWC Settings > Advanced > Protocol Access >...

  • Page 25: File

    Data Docking Station User Manual Tap “OK” to validate registration. Go back to the DDS and pull out all the devices from the DDS. Tap “Syncing” on the interface and all the devices registered to the DDSMMS in the same department as the DDS will be synchronized to the DDS automatically.

  • Page 26: View

    Data Docking Station User Manual Picture 4-21 Query files 4.3.2 View Select video or audio files and tap any one on the file list. The system will pop up the play window and play the file and show details of the file such as file name, upload time, size, shot time, resolution and type.

  • Page 27: Download

    Data Docking Station User Manual Picture 4-22View files 4.3.3 Download and set file save path. Then tap “All”, “Deselect” or Query the files to be downloaded and tap “Yes/No” to confirm required files. Tap “Yes” and in the popup window tap “OK” to download the file(s) to the specified path.

  • Page 28: Delete

    Data Docking Station User Manual Picture 4-23 Download files 4.3.4 Delete Query files to be deleted and tap . Select all, check one by one or deselect to confirm files and tap “Yes”. In the popup window, tap “OK” to delete the selected file(s). Picture 4-24 Delete files 4.4 Upgrade User can obtain the installation packet from local storage and upgrade DDS no matter it is connected or...
  • Page 29 Data Docking Station User Manual Picture 4-25 Upgrade Tap “Local Importing” and select the packet to be imported. Tap “Install” to upgrade version of the DDS. The system will pop up the following interface. Tap “Next” according to the prompt on the window. Select the installation path.
  • Page 30 Data Docking Station User Manual After selecting the installation path, tap “Install” and the system will pop up a window indicating the installation progress. Wait patiently for installation. After installation, tap “Finish” and the version of the DDS succeeds.

  • Page 31: Slot

    Data Docking Station User Manual Note: When the network is connected normally, after the BWC synchronizes its data to the DDS, it will upgrade the version automatically without any operation. 4.5 Slot After the BWC is inserted into the slot, the DDS will identify and lock the device automatically. Meanwhile, it will show the slot the BWC is in and the data synchronization progress.

  • Page 32: Configurations

    Data Docking Station User Manual Picture 4-27 Device information 4.6.2 Configurations Tap “Configurations” and enter the following interface. Tap “Edit” to configure parameters. Picture 4-28 Device configurations 4.6.3 Network Tap “Network” and “Edit” to configure device IP and other parameters, as shown below.

  • Page 33: Server

    Data Docking Station User Manual Picture 4-29 Network configurations 4.6.4 Server Tap “Server” and “Edit” to configure DDSMMS server IP and port, and VIID IP and port, as shown below. Picture 4-30 Server configurations Note: When user wants to disconnect the DDS with the DDSMMS, tap “Edit” and configure the Server IP as 0.0.0.0.
  • Page 34 Data Docking Station User Manual Picture 4-31 Reboot to validate settings Table 4-3 Settings Setting Item Parameter Notes Product ID ID of the DDS Software Version Software version of the DDS Compiled At The compilation time of software Information BIOS Version BIOS version of the DDS MAC Address MAC address of the DDS...
  • Page 35 Data Docking Station User Manual Server IP Fill the IP address of DDSMMS server Port Number Fill the port number of DDSMMS server Connect to VIID Enable it to connect the DDS to VIID VIID IP Fill the IP address of VIID Server VIID Port Fill the port number of VIID...

  • Page 36: Log

    Data Docking Station User Manual 4.7 Log Tap “Log” to view the operation logs of the DDS and all the BWCs connected to it. Picture 4-32 Log of DDS...

  • Page 37: Appendix: Glossary Of Terms

    Data Docking Station User Manual 5. Appendix: Glossary of Terms Term Explanation Body Worn Camera Data Docking Station DDSMMS Data Docking Station Multi-point Management System...
