Biostar TF7025-M2 User Manual

Biostar tf7025-m2 motherboard: user guide
Hide thumbs Also See for TF7025-M2:
Table of Contents

Advertisement

Quick Links

See also: Setup Manual
TF7050-M2/TF7025-M2 Setup Manual
FCC Information and Copyright
This equipment has been tested and found to comply with the limits of a Class
B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. There is no guarantee
that interference will not occur in a particular installation.
The vendor makes no representations or warranties with respect to the
contents here and specially disclaims any implied warranties of merchantability
or fitness for any purpose. Further the vendor reserves the right to revise this
publication and to make changes to the contents here without obligation to
notify any party beforehand.
Duplication of this publication, in part or in whole, is not allowed without first
obtaining the vendor's approval in writing.
The content of this user's manual is subject to be changed without notice and
we will not be responsible for any mistakes found in this user's manual. All the
brand and product names are trademarks of their respective companies.

Advertisement

Table of Contents
loading

Related Manuals for Biostar TF7025-M2

Summary of Contents for Biostar TF7025-M2

  • Page 1 TF7050-M2/TF7025-M2 Setup Manual FCC Information and Copyright This equipment has been tested and found to comply with the limits of a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 2: Table Of Contents

    Before You Start ... 3 Package Checklist... 3 Motherboard Features... 4 Rear Panel Connectors (for TF7050-M2)... 6 Rear Panel Connectors (for TF7025-M2) ... 7 Motherboard Layout (for TF7050-M2)... 8 Motherboard Layout (for TF7025-M2)... 9 Chapter 2: Hardware Installation ... 10 Installing Central Processing Unit (CPU)...

  • Page 3: Chapter 1: Introduction

    CHAPTER 1: INTRODUCTION EFORE TART Thank you for choosing our product. Before you start installing the motherboard, please make sure you follow the instructions below: Prepare a dry and stable working environment with sufficient lighting. Always disconnect the computer from power outlet before operation.

  • Page 4: Motherboard Features

    10 / 100 Mb/s / 1Gb/s auto negotiation (Gigabit bandwidth is for RTL 8111B PHY only) Half / Full duplex capability EATURES TF7025-M2 Socket AM2 AMD Athlon 64 / Athlon 64 FX / Athlon 64 x2 / Sempron processors AMD 64 Architecture enables 32 and 64 bit...
  • Page 5 RAID 0 / 1 / 5 / 0+1 support Features Windows 2000 / XP / VISTA OS Support Biostar Reserves the right to add or remove support for any OS With or without notice. TF7050-M2/TF7025-M2 TF7025-M2 ALC888 (Ver 5.x) / ALC861VD (Ver 6.x) 7.1 channels audio out (Ver 5.x) /...

  • Page 6: Rear Panel Connectors (For Tf7050-M2)

    Motherboard Manual ANEL ONNECTORS PS/2 Mouse Port S-Video TV-Out Port Transmit analog video signals to TV or any other display panels equipped with S-Video input. HDMI Port The High-Definition Multimedia Interface (HDMI) is an all-digital audio/video interface capable of transmitting uncompressed streams to an AV receiver or any compatible digital audio and/or video monitor, such as a digital television.

  • Page 7: Rear Panel Connectors (For Tf7025-M2)

    Port 2-Channel Blue Line-In Green Line-Out Pink Mic In Orange Black Rear Speaker Out Grey TF7050-M2/TF7025-M2 TF7025-M2) PS/2 Keyboard Port The DVI-D connector RJ-45 LAN Port 4-Channel 6-Channel/8-Channel Line-In Line-In Front Speaker Out Front Speaker Out Mic In Mic In...

  • Page 8: Motherboard Layout (For Tf7050-M2)

    Motherboard Manual OTHERBOARD JKBMS1 JATXPWR2 JUSBV1 JATXPWR1 JUSB1 JUSBLAN1 JCFAN1 JAUDIO2 (for Ver 5.x) JNFAN1 JAUDIO1 (for Ver 6.x) JAUDIOF1 PEX1_1 PEX16_1 PCI1 JCOM1 PCI2 Codec JPRNT1 JSPDIF_IN1 JSPDIF_OUT1 JCDIN1 Note: represents the 1 ■ TF7050-M2) AYOUT GeForce 7050PV/ NF630...

  • Page 9: Motherboard Layout (For Tf7025-M2)

    JAUDIO1 (for Ver 6.x) JAUDIOF1 PEX1_1 PEX16_1 PCI1 JCOM1 PCI2 Codec JPRNT1 JSPDIF_IN1 JSPDIF_OUT1 JCDIN1 Note: represents the 1 ■ TF7050-M2/TF7025-M2 TF7025-M2) AYOUT GeForce 7025 / NF630 JUSB2 JUSB3 JUSB4 BIOS SATA1 SATA2 Super I/O JSFAN1 FDD1 pin. JUSBV2 JSFAN2...

  • Page 10: Chapter 2: Hardware Installation

    Motherboard Manual CHAPTER 2: HARDWARE INSTALLATION NSTALLING ENTRAL Step 1: Remove the socket protection cap. Step 2: Pull the lever toward direction A from the socket and then raise the lever up to a 90-degree angle. Step 3: Look for the white triangle on socket, and the gold triangle on CPU should point towards this white triangle.
  • Page 11 Step 4: Hold the CPU down firmly, and then close the lever toward direct B to complete the installation. Step 5: Put the CPU Fan on the CPU and buckle it. Connect the CPU FAN power cable to the JCFAN1. This completes the installation. TF7050-M2/TF7025-M2...

  • Page 12: Fan Headers

    Motherboard Manual FAN H EADERS These fan headers support cooling-fans built in the computer. The fan cable and connector may be different according to the fan manufacturer. Connect the fan cable to the connector while matching the black wire to pin#1.

  • Page 13: Installing System Memory

    DIMM on the slot such that the notch on the DIMM matches the break on the Slot. Insert the DIMM vertically and firmly into the slot until the retaining chip snap back in place and the DIMM is properly seated. TF7050-M2/TF7025-M2 EMORY...
  • Page 14 DIMMB2 256MB/512MB/1024MB C. Dual Channel Memory installation To trigger the Dual Channel function of the motherboard, the memory module must meet the following requirements: Install memory module of the same density in pairs, shown in the following table. Dual Channel Status DIMMA1...

  • Page 15: Connectors And Slots

    IDE1: Hard Disk Connector The motherboard has a 32-bit Enhanced PCI IDE Controller that provides PIO Mode 0~4, Bus Master, and Ultra DMA 33/66/100/133 functionality. The IDE connector can connect a master and a slave drive, so you can connect up to two hard disk drives.
  • Page 16 2X bandwidth over the traditional PCI architecture. PCI1~PCI2: Peripheral Component Interconnect Slots This motherboard is equipped with 2 standard PCI slots. PCI stands for Peripheral Component Interconnect, and it is a bus standard for expansion cards. This PCI slot is designated as 32 bits.

  • Page 17: Chapter 3: Headers & Jumpers Setup

    This 16-pin connector includes Power-on, Reset, HDD LED, Power LED, Sleep button and speaker connection. It allows user to connect the PC case’s front panel switch functions. Assignment Speaker HDD LED (+) HDD LED (-) Ground Reset control TF7050-M2/TF7025-M2 UMPERS Pin closed PWR_LED On/Off HLED Function Assignment Sleep control...
  • Page 18 Motherboard Manual JATXPWR1: ATX Power Source Connector This connector allows user to connect 24-pin power connector on the ATX power supply. Assignment +3.3V -12V Ground PS_ON Ground Ground Ground Ground JATXPWR2: ATX Power Source Connector By connecting this connector, it will provide +12V to CPU power circuit.

  • Page 19: Power Source Headers For Usb Ports

    JUSBV2: USB ports at front panel (JUSB2/JUSB3/JUSB4) are powered by +5V standby voltage. Note: In order to support this function “Power-On system via USB device,” “JUSBV1/ JUSBV2” jumper cap should be placed on Pin 2-3 individually. TF7050-M2/TF7025-M2 Assignment +5V (fused) +5V (fused) JUSB2...
  • Page 20 Motherboard Manual SATA1~SATA4: Serial ATA Connectors The motherboard has a PCI to SATA Controller with 4 channels SATA interface. JAUDIOF1: Front Panel Audio Header This header allows user to connect the front audio output cable with the PC front panel. It will disable the output on back panel audio connectors.

  • Page 21: Clear Cmos Procedures

    Set the jumper to “Pin 2-3 close”. Wait for five seconds. Set the jumper to “Pin 1-2 close”. Power on the AC. Reset your desired password or clear the CMOS data. TF7050-M2/TF7025-M2 Pin 1-2 Close: Normal Operation (default). Pin 2-3 Close:...
  • Page 22 Motherboard Manual JSPDIF_OUT1: Digital Audio-out Connector This connector allows user to connect the PCI bracket SPDIF output header. JCOM1: Serial port Connector The motherboard has a Serial Port Connector for connecting RS-232 Port. Assignment SPDIF_OUT Ground Assignment Carrier detect Received data...
  • Page 23 RSTSW1: This is an on-board Reset button. On-Board LED Indicators There are 2 LED indicators on the motherboard to show system status. LED_D1 and LED_D2: These 2 LED indicate system power on diagnostics. Please refer to the table below for different messages:...
  • Page 24 Motherboard Manual JPRNT1: Printer Port Connector This header allows you to connector printer on the PC. Assignment -Strobe -ALF Data 0 -Error Data 1 -Init Data 2 -Scltin Data 3 Ground Data 4 Ground Data 5 JSPDIF_IN1: Digital Audio-out Connector (Optional) This connector allows user to connect the PCI bracket SPDIF input header.

  • Page 25: Chapter 4: Raid Functions

    Drawbacks: Does not deliver any fault tolerance. If any drive in the array ­ fails, all data is lost. Fault Tolerance: No. ­ Block 1 Block 3 Block 5 TF7050-M2/TF7025-M2 Block 2 Block 4 Block 6...
  • Page 26 Motherboard Manual RAID 1: Every read and write is actually carried out in parallel across 2 disk drives in a RAID 1 array system. The mirrored (backup) copy of the data can reside on the same disk or on a second redundant drive in the array.
  • Page 27 ­ the same as RAID level 1. Fault Tolerance: Yes. ­ GeForce 7050PV GeForce Block 1 Block 2 Block 3 Block 4 Block 5 Block 6 TF7050-M2/TF7025-M2 7025 Block 1 Block 3 Block 5 Block 2 Block 4 Block 6...
  • Page 28 Motherboard Manual RAID 5: RAID 5 stripes both data and parity information across three or more drives. It writes data and parity blocks across all the drives in the array. Fault tolerance is maintained by ensuring that the parity information for any given block of data is placed on a different drive from those used to store the data itself.

  • Page 29: Chapter 5: Overclock Quick Guide

    CHAPTER 5: OVERCLOCK QUICK GUIDE OWER NTRODUCTION Biostar T-Power is a whole new utility that is designed for overclock users. Based on many precise tests, Biostar Engineering Team (BET) has developed this ultimate overclock engine to raise system performance. No matter whether under BIOS or Windows interface, T-Power is able to present the best system state according to users’...

  • Page 30: T-Power Bios Feature

    Motherboard Manual BIOS F OWER A. Overclocking Navigator Engine (O.N.E.): ONE provides two powerful overclocking engines: MOS and AOS for both Elite and Casual overclockers. Manual Overclock System (M.O.S.) MOS is designed for experienced overclock users. It allows users to customize personal overclock settings.
  • Page 31 Chipset Overclock Setting: NB/SB Voltage Regulator: This function will increase chipset stability when overclocking. Choices: 1.52V, 1.60V, 1.68V, 1.76V. HT Frequency: We recommend users to set this item at “x4” when overclocking. Choices: x1, x2, x3, x4, x5, Auto. TF7050-M2/TF7025-M2...
  • Page 32 Motherboard Manual Automatic Overclock System (A.O.S.) For beginners in overclock field, BET had developed an easy, fast, and powerful feature to increase the system performance, named A.O.S. Based on many tests and experiments, A.O.S. provides 3 ideal overclock configurations that are able to raise the system performance in a single step.
  • Page 33 Users are able to reload any saved CMOS setting for customizing system configurations. Moreover, users are able to save an ideal overclock setting during overclock operation. There are 50 sets of record addresses in total, and users are able to name the CMOS data according to personal preference. TF7050-M2/TF7025-M2...
  • Page 34 Motherboard Manual C. Memory Integration Test (M.I.T.): This function is under “Overclocking Navigator Engine” item. MIT allows users to test memory compatibilities, and no extra devices or software are needed. Step 1: The default setting under this item is “Disabled”; the condition parameter should be changed to “Enable”...
  • Page 35 E. Integrated Flash Program (I.F.P.): IFP is a safe and quick way to upgrade BIOS. Step 1: Go to Biostar website (http://www.biostar.com.tw) to download the latest BIOS file. Then, save the file into a floppy disk. Step 2: Insert the floppy disk and reboot the system to get into CMOS screen.
  • Page 36 Motherboard Manual F. Smart Fan Function: Smart Fan Function is under “PC Health Status”. This is a brilliant feature to control CPU Temperature vs. Fan speed. When enabling Smart Fan function, Fan speed is controlled automatically by CPU temperature. This function will protect CPU from overheat problem and maintain the system temperature at a safe level.
  • Page 37 S3: CPU temperature is 60℃, and PWM value is 3 PWM/℃. Increasing the value of slope PWM will raise the speed of CPU fan. As in above diagram, when the CPU temperature reaches 60℃, the CPU fan speed for 3 PWM/℃ is higher than 1 PWM/℃ (S1<S2<S3). TF7050-M2/TF7025-M2...

  • Page 38: T-Power Windows Feature

    Motherboard Manual OWER INDOWS A.Hardware Monitor: T-Power Hardware monitor allows users to monitor system voltage, temperature and fan speed accordingly. Additionally, a rescue action will be taken by the program automatically while the system faces an abnormal condition. The program will trigger an alarm or shut down the system when unpredictable errors occur.

  • Page 39: Cpu Temperature

    If any one of the fans speeds is lower than the set value, the status line will change into a red warning line, and the program will trigger an alarm system automatically. Also, the system tray icon TF7050-M2/TF7025-M2 would change to...
  • Page 40 Motherboard Manual CPU/Battery Voltage VCore This item displays the CPU voltage, represented by a light blue line. Users can set the upper and lower limit by adjusting CPU operating voltage. If CPU voltage is higher or lower than the set value, the status line will change into a red warning line, and a warning sound will alert you.
  • Page 41 4 sub-screens, users can tune the system performance to an optimal level. TF7050-M2/TF7025-M2 Graphic 1 A. Clicking on “Biostar” will lead you to the Biostar Homepage. B. This column shows the CPU speed information. C. Click on this button and the utility will pop-up 4 sub-screens (Please refers to Graphic 3).
  • Page 42 Motherboard Manual CPU Overclocking Settings: By adjusting for CPU overclocking. Memory Overclocking Settings: By adjusting Memory overclocking. A. Memory Clock Frequency B. Memory Voltage AGP/PCI-Express Overclocking Setting: By adjusting overclocking. And this function helps to increase VGA card performance. Range: 100MHz~150MHz.
  • Page 43 TF7050-M2/TF7025-M2 PCI Overclocking Setting: This diagram shows present PCI working status and helps to monitor PCI peripherals working status. This item cannot be adjusted.
  • Page 44 Motherboard Manual C. Smart Fan Function When Smart Fan Function is activated, screens will pop-up to illustrate the fan speed information. CPU Temperature: Show current CPU temperature. CPU Fan speed: Show current CPU Fan speed. iii. System Fan speed: Show current system Fan speed.
  • Page 45 Cursor Up or Down. vi. Program Tool Bar: About: Click on this button to get program-related information. Minimize: Click on this button to minimize the program to system tray Exit: Click on this button to exit this program. TF7050-M2/TF7025-M2...
  • Page 46 When Live Update program is activated, a screen will pop up to illustrate BIOS related information. Link to Internet: Click on this button will link to Biostar website and BIOS file will be downloaded. Update BIOS: Click on this button to run BIOS flashing process, and it’s easy and safe.

  • Page 47: Chapter 6: Useful Help

    You will see the following window after you insert the CD The setup guide will auto detect your motherboard and operating system. Note: If this window didn’t show up after you insert the Driver CD, please use file browser to locate and execute the file SETUP.EXE under your optical drive.

  • Page 48: Award Bios Beep Code

    BIOS contents are corrupted. In this Case, please follow the procedure below to restore the BIOS: 1. Make a bootable floppy disk. 2. Download the Flash Utility “AWDFLASH.exe” from the Biostar website: www.biostar.com.tw 3. Confirm motherboard model and download the respectively BIOS from Biostar website.
  • Page 49 If the system shutdown automatically after power on system for seconds, that means the CPU protection function has been activated. When the CPU is over heated, the motherboard will shutdown automatically to avoid a damage of the CPU, and the system may not power on again.

  • Page 50: Troubleshooting

    Motherboard Manual ROUBLESHOOTING Probable No power to the system at all Power light don’t illuminate, fan inside power supply does not turn Indicator light on keyboard does not turn on. System inoperative. Keyboard lights are on, power indicator lights are lit, and hard drive is spinning.
  • Page 51 TF7050-M2/TF7025-M2 This page is intentionally left blank.

  • Page 52: Appendencies: Spec In Other Language

    Realtek RTL 8111B PHY / 8101E PHY (optional) 10 / 100 / 1000 Mb/s Auto-Negotiation (Gigabit-Bandbreite nur beim RTL 8111B PHY) Halb-/ Vollduplex-Funktion TF7025-M2 Sockel AM2 AMD Athlon 64 / Athlon 64 FX / Athlon 64 x2/ Sempron Prozessoren Die AMD 64-Architektur unterstützt eine 32-Bit- und 64-Bit-Datenverarbeitung Unterstützt Hyper Transport und Cool’n’Quiet...
  • Page 53 235 mm (B) X 244 mm (L) Sonderfunkti Unterstützt RAID 0 / 1 / 5 / 0+1 onen Windows 2000 / XP / VISTA Biostar behält sich das Recht vor , ohne OS-Unterstüt Ankündigung die Unterstützung für ein zung Betriebssystem hinzuzufügen oder zu entfernen.

  • Page 54: France

    10 / 100 / 1000 Mb/s négociation automatique (La bande passante Gigabit est pour le RTL 8111B PHY uniquement) Half / Full duplex capability TF7025-M2 Socket AM2 Processeurs AMD Athlon 64 / Athlon 64 FX / Athlon 64 x2 / Sempron...
  • Page 55 Prise en charge RAID 0 / 1 / 5 / 0+1 spéciales Windows 2000 / XP / VISTA Biostar se réserve le droit d'ajouter ou de Support SE supprimer le support de SE avec ou sans préavis. TF7050-M2/TF7025-M2 TF7025-M2 ALC888 (Ver 5.x) / ALC861VD (Ver 6.x)

  • Page 56: Italian

    Negoziazione automatica 10 / 100 / 1000 Mb/s (la larghezza di banda Gigabit è solo per RTL 8111B PHY) Capacità Half / Full Duplex TF7025-M2 Socket AM2 Processori AMD Athlon 64 / Athlon 64 FX / Athlon 64 x2/ Sempron L’architettura AMD 64 abilita la...
  • Page 57 Caratterist iche Supporto RAID 0 / 1 / 5 / 0+1 speciali Windows 2000 / XP / VISTA Sistemi Biostar si riserva il diritto di aggiungere o operativi rimuovere il supporto di qualsiasi sistema supportati operativo senza preavviso. TF7050-M2/TF7025-M2 TF7025-M2 ALC888 (Ver 5.x) / ALC861VD (Ver 6.x)

  • Page 58: Spanish

    Red Local de banda Gigabit es únicamente para RTL 8111B PHY) Funciones Half / Full dúplex TF7025-M2 Conector AM2 Procesadores AMD Athlon 64 / Athlon 64 FX / Athlon 64 x2/ Sempron La arquitectura AMD 64 permite el procesado de 32 y 64 bits Soporta las tecnologías Hyper Transport y...
  • Page 59 Admite RAID 0 / 1 / 5 / 0+1 especiales Soporte de Windows 2000 / XP / VISTA sistema Biostar se reserva el derecho de añadir o retirar operativo el soporte de cualquier SO con o sin aviso previo. TF7050-M2/TF7025-M2 TF7025-M2 ALC888 (Ver 5.x) / ALC861VD (Ver 6.x)

  • Page 60: Portuguese

    Auto negociação de 10 / 100 / 1000 Mb/s (a largura de banda Gigabit refere-se apenas à especificação RTL 8111B PHY) Capacidade semi/full-duplex TF7025-M2 Socket AM2 Processadores AMD Athlon 64 / Athlon 64 FX / Athlon 64 x2/ Sempron A arquitectura AMD 64 permite uma computação...
  • Page 61 Suporta as funções RAID 0 / 1 / 5 / 0+1 especiais Windows 2000 / XP / VISTA Sistemas A Biostar reserva-se o direito de adicionar ou operativos remover suporte para qualquer sistema suportados operativo com ou sem aviso prévio.

  • Page 62: Polish

    10 / 100 / 1000 Mb/s z automatyczną negocjacją szybkości (Pasmo gigabitowe wyłącznie dla RTL 8111B PHY) Działanie w trybie połowicznego / pełnego dupleksu TF7025-M2 Socket AM2 AMD Athlon 64 / Athlon 64 FX / Athlon 64 x2 / Sempron Procesory Architektura AMD 64 umożliwia przetwarzanie 32 i 64 bitowe Obsługa Hyper Transport oraz Cool’n’Quiet...
  • Page 63 Funkcje Obsługa RAID 0 / 1 / 5 / 0+1 specjalne Obsluga Windows 2000 / XP / VISTA systemu Biostar zastrzega sobie prawo dodawania lub operacyjne odwoływania obsługi dowolnego systemu operacyjnego bez powiadomienia. TF7050-M2/TF7025-M2 TF7025-M2 ALC888 (Ver 5.x) / ALC861VD (Ver 6.x) 7.1 kanałowe wyjście audio (Ver 5.x) /...

  • Page 64: Russian

    Автоматическое согласование 10 / 100 / 1000 сеть Мб/с (гигабитная пропускная способность только для гигабитного физического уровня) Частичная / полная дуплексная способность TF7025-M2 Гнездо AM2 Процессоры AMD Athlon 64 / Athlon 64 FX / Althlon 64X2 / Sempron Архитектура AMD 64 разрешать обработка...
  • Page 65 Поддержка RAID 0 / 1 / 5 / 0+1 е характерис тики Windows 2000 / XP / VISTA Поддержка Biostar сохраняет за собой право добавлять или удалять средства обеспечения для OS с или без предварительного уведомления. TF7050-M2/TF7025-M2 TF7025-M2 ALC888 (Ver 5.x) / ALC861VD (Ver 6.x) 7.1канальный...

  • Page 66: Arabic

    Motherboard Manual RABIC TF7025-M2 ‫ﻡﻌﺎﻟﺠﺎت‬AMD Athlon 64 / Athlon 64 FX / Athlon 64 x2 / Sempron AMD 64 ‫ﺔ‬ ‫ﺗﻤﻜﻦ ﺗﻘﻨﻴ‬ ‫ﺏﺖ‬ ‫و‬ ‫إﺝﺮاء اﻟﻌﻤﻠﻴﺎت اﻟﺤﺎﺳﻮﺏﻴﺔ ﺏﺴﺮﻋﺔ‬ ‫ﺗﺪﻋﻢ ﺗﻘﻨﻴﺔ‬Hyper Transport ‫ و‬Cool’n’Quiet ‫ﺗﺪﻋﻢ ﺗﻘﻨﻴﺔ‬HyperTransport ‫ﺗﺮدد0001 ﺏﺘﺮدد ﻳﺼﻞ إﻟﻰ‬ GeForce 7025/NF630a ‫ﻋﺪد‬...

  • Page 67: Pci Express X16

    ‫ﺗﺪﻋﻢ ﺗﻘﻨﻴﺔ‬RAID 0 / 1 / 5 / 0+1 ‫ارﺗﻔﺎع‬ ‫ﻡﻢ‬ ‫ﻋﺮض‬ ‫ﻡﻢ‬ Windows 2000 / XP / VISTA ‫ﺗﺤﺘﻔﻆ‬Biostar ‫ﺏﺤﻘﻬﺎ ﻓﻲ إﺿﺎﻓﺔ أو إزاﻟﺔ اﻟﺪﻋﻢ ﻷي ﻥﻈﺎم ﺗﺸﻐﻴﻞ ﺏﺈﺥﻄﺎر أو‬ ‫ﺏﺪون إﺥﻄﺎر‬ TF7050-M2/TF7025-M2 TF7050-M2 ALC888 (Ver 5.x) / ALC861VD (Ver 6.x) ‫اﻟﺼﻮت‬...

  • Page 68: Japanese

    最高3 Gb/秒のデータ転送速度 SATAバージョン2.0仕様に準拠。 Realtek RTL 8111B PHY / 8101E PHY(オプション) 10 / 100 / 1000 Mb/秒のオートネゴシエーション (Gigabitバンド幅はRTL 8111B PHY専用です) 半/全二重機能 TF7025-M2 Socket AM2 AMD Athlon 64 / Athlon 64 FX / Athlon 64 x2/ Sempron プロセッサ AMD 64アーキテクチャでは、32ビットと64ビット計 算が可能です ハイパートランスポートとクールアンドクワイアット...
  • Page 69 ボードサイズ 235 mm (幅) X 244 mm (高さ) RAID 0 / 1 / 5 / 0+1 のサポート 特殊機能 Windows 2000 / XP / VISTA OSサポート Biostarは事前のサポートなしにOSサポートを追加ま たは削除する権利を留保します。 TF7050-M2/TF7025-M2 TF7025-M2 ALC888 (Ver 5.x) / ALC861VD (Ver 6.x) 7.1チャンネルオーディオアウト (Ver 5.x) / 5.1チャンネルオーディオアウト (Ver 6.x) ハイデフィニションオーディオのサポート PCIスロット...
