General Specifications
Input Voltage
Input Current
Input Power
Power Factor
THD
Standby Power
Output Type
Output Current
Output Voltage Range
Output Power
Output runtime
Dimming Type
Dimming Percentage
Number of Output Channels
RFI/EMI
Ambient Operating Temperature Range
Sound Rating
Input Surge Protection
Protections
Service Life
Self-Diagnostic
Safety Standards
Mechanical Data
Fulham extends a limited warranty to the original purchaser or first user for a period of 5 years from the date of manufacture when properly installed
and operated under normal conditions of use. For complete terms and conditions, please refer to the Warranty Center at www.fulham.
Specifications subject to change without notice.
®
FHSAC1-230-45CE
INSTALLATION INSTRUCTIONS
2 0-240VAC, 50/60Hz
2
0.27
.
A Max.
58W
>0.9
<
20
%
<0.5W
SELV
250 1400
-
11-50VDC
45W (1W to 6W @ Emergency)
Minimum 90min at 6W, Minimum 180 Minutes at 3W (Factory set for 3W / 180min)
0-10V or Pulse DIM
0%, 1%-100%
1 Channel
EN55015
0°C To 40°C(32°F To 104F°)
A
Line-Neutral kV, Line & Neutral-Ground kV
Output Open Circuit Protection
Overload Protection
Short-Circuit Protection
Battery Deep Discharge Protection
Over Temprature Protection
50,000 hours
Factory Enabled
IEC/EN 61347-1,IEC/EN 61347-2-7,IEC/EN 61347-2-13,IEC/EN 60598-1
IEC/EN 60598-2-22,IEC 62384,EN 62493,IEC / EN 62034
EN 61547,EN 55015 , EN 61000-3-2 , EN 61000-3-3
mA
2
2
0-10VDC
Pulse DIM
EL-T
Tolerance=±0.02"[ .
02
]
0 5mm
com.
Page 1 of 8
2017-718-1 Rev A
