- Page 1 GEL-2060 LLDP Configuration Commands...
-
Page 2: Table Of Contents
Table of Contents Table of Contents LLDP Configuration Commands ............................1 Table of Contents .................................. I Chapter 1 LLDP Configuration Commands .......................... 1 1.1 LLDP Commands ..............................1 1.1.1 lldp run ..............................1 1.1.2 lldp holdtime ............................2 1.1.3 lldp timer ..............................2 1.1.4 lldp reinit .............................. -
Page 3: Lldp Configuration Commands
LLDP Configuration Commands Chapter 1 LLDP Configuration Commands 1.1 LLDP Commands 1.1.1 lldp run Description lldp run no lldp run To start up LLDP, run lldp run; to shut down LLDP, run no lldp run. Parameter None Default Shut down Explanation None Command mode... -
Page 4: Lldp Holdtime
LLDP Configuration Commands 1.1.2 lldp holdtime Description lldp holdtime time no lldp holdtime To configure the ttl value of LLDP, run lldp holdtime time. To resume the default transmission delay, run no lldp holdtime. Parameter Parameter Description time Storage time of the transmitted message, ranging between zero to 65535 seconds Default 120s... -
Page 5: Lldp Reinit
LLDP Configuration Commands Parameter Parameter Description time Interval for transmitting the LLDP message, ranging between 5 to 65534 seconds. Default Explanation The transmission interval of the LLDP message must be shorter than its storage time, ensuring multiple updates in the storage time and preventing error which is led by packet loss. -
Page 6: Lldp Tlv-Select
LLDP Configuration Commands Default ２ s Explanation None Command mode Global configuration mode Example The following example shows how to set the transmission delay of LLDP to five seconds. Switch_config# lldp reinit ５ Switch_config# 1.1.5 lldp tlv-select Description lldp tlv-select tlv-type no lldp tlv-select tlv-type To add TLV which is transmitted by the LLDP message, run lldp tlv-select tlv-type. -
Page 7: Lldp Transmit
LLDP Configuration Commands Explanation Three mandatory TLVs must be sent. Command mode Global configuration mode Example The following example shows how to enable the port description not to be transmitted in the message. Switch_config#no lldp tlv-select port-description Switch_config# 1.1.6 lldp transmit Description lldp transmit no lldp transmit... -
Page 8: Lldp Receive
LLDP Configuration Commands Switch_config_f0/0# 1.1.7 lldp receive Description lldp receive no lldp receive To set the port to the receivable LLDP message mode, run lldp receive. To forbid receiving the LLDP message, run no lldp receive. Parameter None Default Receivable LLDP message mode Explanation Only after the LLDP module is started can the configuration be valid. -
Page 9: Show Lldp Interface
LLDP Configuration Commands Parameter None Default None Explanation None Command mode EXEC/Global configuration mode Example The following example shows how to set port f0/0 to the LLDP message mode. switch_config#show lldp errors LLDP errors/overflows: Total memory allocation failures: 0 Total encapsulation failures: 0 Total table overflows: 0 switch_config# 1.1.9... -
Page 10: Show Lldp Neighbors
LLDP Configuration Commands Default None Explanation After LLDP is started, you can check the state of the port. Command mode EXEC/global configuration mode Example The following example shows how to check the transmission and reception mode of port f0/1. switch_config#show lldp interface f0/1 FastEthernet0/1: Rx: enabled Tx: enabled... -
Page 11: Show Lldp Neighbors Detail
LLDP Configuration Commands Command mode EXEC / global configuration mode Example switch_config#show lldp neighbors Capability Codes: (R)Router,(B)Bridge,(C)DOCSIS Cable Device,(T)Telephone (W)WLAN Access Point, (P)Repeater,(S)Station,(O)Other Device-ID Local-Intf Hldtme Port-ID Capability switch Fas0/2 Fas0/32 switch Fas0/32 Fas0/2 Total entries dispalyed: 2 switch_config# 1.1.11 Show lldp neighbors detail Description Show lldp neighbors detail... - Page 12 LLDP Configuration Commands Example switch_config#show lldp neighbors detail chassis id: 00e0.0f61.ca53 port id: Fas0/32 port description: FastEthernet0/32 system name: switch. system description: (tm) S3448 Software, Version 2.0.1K Serial: S35000456 Copyright by Shanghai Baud Data Communication CO. LTD. Compiled: 2008-11-13 13:33:36 by 16170F032B9F Time remaining: 98 system capabilities: R B enabled capabilities: B...
-
Page 13: Show Lldp Traffic
LLDP Configuration Commands Compiled: 2008-11-13 13:33:36 by 16170F032B9F Time remaining: 95 system capabilities: R B enabled capabilities: B Managment Address: IP: 90.0.0.66 Auto Negotiation -- supported,enabled Physical media capabilitise: 100baseTX(FD) 100baseTX(HD) 10baseT(FD) 10baseT(HD) Media Attachment Unit type: 16 ------------------------------------------ Total entries dispalyed: 2 switch# 1.1.12 Show lldp traffic... -
Page 14: Clear Lldp Counters
LLDP Configuration Commands Command mode EXEC/global configuration mode Example switch_config#show lldp traffic LLDP traffic statistics: Total frames out: 1599 Total entries aged: 0 Total frames in: 624 Total frames received in error: 0 Total frames discarded: 0 Total TLVs unrecognized: 0 switch_config# 1.1.13 clear lldp counters... -
Page 15: Clear Lldp Table
LLDP Configuration Commands 1.1.14 clear lldp table Description clear lldp table To remove the neighbor list, run clear lldp table. Parameter None Default None Explanation None Command mode EXEC Example switch#clear lldp table switch# 1.1.15 debug lldp errors Description debug lldp errors To report some error information about the LLDP module, run debug lldp errors. -
Page 16: Debug Lldp Events
LLDP Configuration Commands Explanation None Command mode EXEC Example switch#debug lldp errors debug lldp errors on switch#show debug lldp errors debugging is on switch#Nov 14 09:39:04LLDP recive a bad frame on interface FastEthernet0/2 Nov 14 09:49:44LLDP transmit fail on interface FastEthernet0/2 1.1.16 debug lldp events Description... -
Page 17: Debug Lldp Packets
LLDP Configuration Commands lldp event debugging is on switch#config switch_config#int f0/2 switch_config_f0/2#no lldp tr switch_config_f0/2#Nov 14 09:39:04 LLDP transmit a end packet on interface FastEthernet0/2 Nov 14 09:44:08LLDP recive a unrecognized tlv frame on interface FastEthernet0/2 1.1.17 debug lldp packets Description debug lldp packets To report the message transmission event of the LLDP module, run debug lldp... -
Page 18: Debug Lldp States
LLDP Configuration Commands 1.1.18 debug lldp states Description debug lldp states To report the information about the state of the LLDP port, run debug lldp states. Parameter None Default None Explanation None Command mode EXEC Example switch#debug lldp states debug lldp states on switch#show debug lldp state debugging is on switch#Nov 13 16:39:51 LLDP transmit state on FastEthernet0/2 set to TX FRAME...
