BA_X003
Operating instructions
Product group:
Limit switch box i-box
Certifications:
IV-IA
Table of Contents
1. Device description ................................................................................................................................................................................................. 2
2. Intended use ......................................................................................................................................................................................................... 2
3. Labeling................................................................................................................................................................................................................. 2
4. Safe activation ....................................................................................................................................................................................................... 3
5. Assembly on actuators ......................................................................................................................................................................................... 3
6. Assembly on manual valves ................................................................................................................................................................................. 3
7. Electrical connection ............................................................................................................................................................................................ 4
8. Disassembly .......................................................................................................................................................................................................... 4
9. Adjusting the swivel range .................................................................................................................................................................................... 4
10. Connecting magnetic coils.................................................................................................................................................................................. 5
11. Outdoor use ......................................................................................................................................................................................................... 5
12. Maintenance ........................................................................................................................................................................................................ 5
13. Malfunctions........................................................................................................................................................................................................ 5
14. Item number ....................................................................................................................................................................................................... 5
15. EU Declaration of Conformity ............................................................................................................................................................................. 6
EUROTEC Antriebszubehör GmbH | Bildstock 37 | DE-88085 Langenargen | sales@eurotec.global | www.eurotec.global | 05.03.2021 | Page 1 of 6
Product type:
IV...-IA
DE
Advertisement
Table of Contents
Related Manuals for Eurotec i-box BA X003
Summary of Contents for Eurotec i-box BA X003
- Page 1 12. Maintenance ........................................5 13. Malfunctions........................................5 14. Item number ........................................5 15. EU Declaration of Conformity ..................................... 6 EUROTEC Antriebszubehör GmbH | Bildstock 37 | DE-88085 Langenargen | sales@eurotec.global | www.eurotec.global | 05.03.2021 | Page 1 of 6...
- Page 2 Operating instructions Thank you for choosing a EUROTEC product. In doing so, you have chosen a quality product. To ensure functionality and your own safety, please read these operating instructions carefully before beginning with the installation. Nevertheless, should you have any further questions, please contact: EUROTEC Antriebszubehör GmbH...
- Page 3 ISO 5211 and a threaded hole in the shaft. Please use the “MSH” instruction manual for detailed assembly instructions. EUROTEC Antriebszubehör GmbH | Bildstock 37 | DE-88085 Langenargen | sales@eurotec.global | www.eurotec.global | 05.03.2021 | Page 3 of 6...
- Page 4 4. Now loosen the two point set screws securing the box to the actuator and remove the limit switch box from the actuator. 9. Adjusting the swivel range The actuators are always preset to a swivel range of 0-90° by the EUROTEC Antriebszubehör GmbH. Should you require a different swivel range for your application, please carry out the following steps: a.
- Page 5 10. Connecting magnetic coils Depending on the style, i-box Ex ia limit switch boxes by EUROTEC can be used to connect one to two intrinsically safe magnetic coils (Ex i). Boxes suitable for connecting a magnetic coil have "-MA" added in the item number. With this version, a 500 mm-long cable is already connected to the terminal strip in the housing and exits the box through a cable gland.
- Page 6 EPS 19 ATEX Q 057 Bureau Veritas Consumer Products Services Germany GmbH Businesspark A96, DE-86842 Türkheim Ident.-No.: 2004 2021-03-05 Date General Manager: Melissa Berge EUROTEC Antriebszubehör GmbH | Bildstock 37 | DE-88085 Langenargen | sales@eurotec.global | www.eurotec.global | 05.03.2021 | Page 6 of 6...
