BA_X018
Operating instructions
Product group:
Limit switch box wave
Certifications:
EVP-K2D
Table of Contents
1. Device description ................................................................................................................................................................................................. 2
2. Intended use ......................................................................................................................................................................................................... 2
3. Labeling................................................................................................................................................................................................................. 2
4. Special Conditions ................................................................................................................................................................................................ 3
5. Safe activation ....................................................................................................................................................................................................... 3
6. Assembly on actuators ......................................................................................................................................................................................... 3
7. Assembly on manual valves ................................................................................................................................................................................. 3
8. Electrical connection ............................................................................................................................................................................................ 3
9. Disassembly .......................................................................................................................................................................................................... 4
10. Adjusting the swivel range .................................................................................................................................................................................. 4
11. Connecting solenoid coils ................................................................................................................................................................................... 5
12. Outdoor use ......................................................................................................................................................................................................... 5
13. Maintenance ........................................................................................................................................................................................................ 5
14. Malfunctions........................................................................................................................................................................................................ 5
15. Item number ....................................................................................................................................................................................................... 5
16. EU Declaration of Conformity ............................................................................................................................................................................. 6
EUROTEC Antriebszubehör GmbH | Bildstock 37 | DE-88085 Langenargen | sales@eurotec.global | www.eurotec.global | 20.11.2020 | Page 1 of 6
Product type:
EV...-K2D / EA...-K2D
EVE-K2D
EAE-K2D
EN
Advertisement
Table of Contents
Related Manuals for Eurotec EV K2D Series
Summary of Contents for Eurotec EV K2D Series
- Page 1 13. Maintenance ........................................5 14. Malfunctions........................................5 15. Item number ........................................5 16. EU Declaration of Conformity ..................................... 6 EUROTEC Antriebszubehör GmbH | Bildstock 37 | DE-88085 Langenargen | sales@eurotec.global | www.eurotec.global | 20.11.2020 | Page 1 of 6...
- Page 2 1-4 V3 proximity switches, 1-3 slot type sensors, 1-2 cylindrical sensors, 1 dual sensor. The dust ignition protection comes from the switch box housing. 2. Intended use The wave Ex t limit switch boxes from the EUROTEC Antriebszubehör GmbH are intended for use in the explosive area of zone 21 and 22 with combustible dust. ATEX / IECEx EAC Ex (TR-CU-012) Ex t IIIC T80°C Db X...
- Page 3 It is best to use 2 open-ended spanners for this purpose. One to secure the base body of the cable gland and one to tighten the screw nut. EUROTEC Antriebszubehör GmbH | Bildstock 37 | DE-88085 Langenargen | sales@eurotec.global | www.eurotec.global | 20.11.2020 | Page 3 of 6...
- Page 4 4. Now, unscrew the 4 screws with which the bracket of the box is attached to the actuator and remove the limit switch box from the actuator. 10. Adjusting the swivel range The actuators are always preset to a swivel range of 0-90° by the EUROTEC Antriebszubehör GmbH. Should you require a different swivel range for your application, please carry out the following steps: 1.
- Page 5 11. Connecting solenoid coils Depending on the model, the wave Ex t limit switch boxes of EUROTEC provide the possibility to connect one or two solenoid coils Ex m, Ex dm or Ex d inside the housing. The suitable switch boxes for one coil are marked with an additional '-MA' in their part number. This version has a cable with a length of 500mm that is connected to the terminal block inside the housing and lead outside the housing through a cable gland.
- Page 6 EPS 19 ATEX Q 057 Bureau Veritas Consumer Products Services Germany GmbH Businesspark A96, DE-86842 Türkheim Ident.-No.: 2004 2020-01-23 Date General Manager: Melissa Berge EUROTEC Antriebszubehör GmbH | Bildstock 37 | DE-88085 Langenargen | sales@eurotec.global | www.eurotec.global | 20.11.2020 | Page 6 of 6...
