A. GENERAL PRODUCT INFORMATION
The ORFITUBE
ADJUSTER is a structural unit for
TM
placing onto a hand orthosis, in order to give the orthosis
added adjustable and dynamic action. The dynamic splint
can be dened as 'outrigger with rubber band' type
The outrigger is adjustable, as biomechanical clues may
change over time.
B. PRODUCT SUMMARY
Art. N°
Description
35305
5x single ORFITUBE ADJUSTER
5x ORFITUBE
5x ORFITUBE END
1x bending rod
1x ORFITUBE TM ADJUSTER - SET
INSTRUCTIONS FOR USE
1x allen wrench
Instructions for use: ORFITUBE
p. 1/4
ORFITUBE
INSTRUCTIONS FOR USE
TM
TM
Adjuster Kit (ref. no. 31201E)
ADJUSTER KIT
TM
TM
Single ORFITUBE
adjuster:
ORFITUBE
TM
:
TUBE END:
Bending thread:
Adjusting screw
(stainless steel)
Secures the position of the
ORFITUBE
in the
TM
adjusting ring
Adjusting ring
:
(Polyacetal)
Holds and allows alterations
of the ORFITUBE
TM
Fixation plate
:
®
(ORFIT
)
fastens and stabilises the
ADJUSTER to a splint
Tube
into which
(polycarbonate)
a braided elastic or extension
spring is introduced,
provides a spatial suspension
point for the nger
Metal cap
(nickel-coated brass)
with rounded edges, to reduce
friction of the elastic.
Synthetic thread used to
prevent kinks from arising
when the ORFITUBE
is
TM
shaped.
