Summary of Contents for Pilot Air Hobby Oil Free Series
- Page 1 Hobby Oil Free Series: AIRBAG User Guide P a g e Hobby Oil Free Series: AIRBAG User Guide...
- Page 2 Dear Customer, Thank you for choosing Pilot Air. In order to get the best performance out of this product, please read this manual carefully. To avoid incorrect operation of the equipment and possible physical risk to the operator, please read and strictly follow the instructions contained in this manual.
- Page 3 INDEX General Information Installation Operation Maintenance Illustrations Warrant Terms and Conditions P a g e Hobby Oil Free Series: AIRBAG User Guide...
-
Page 4: General Check
The compressor may be transported in different ways, either by lifting it completely using the upper handle, or by sliding it on wheels by using the side handle (Fig.2). P a g e Hobby Oil Free Series: AIRBAG User Guide... -
Page 5: Installation
After the positions of the compressor has been determined, check that the compressor is level with the rear part positioned towards the most ventilated area. Special foundations or bases are not necessary. P a g e Hobby Oil Free Series: AIRBAG User Guide... -
Page 6: Electric Connection
Any damage caused by improper power connections to the line automatically excludes the guarantee of electrical parts. To avoid improper connections, consult a specialized technician. P a g e Hobby Oil Free Series: AIRBAG User Guide... -
Page 7: Operation
Release the knob of the pressure reducer by pulling it out. Set the pressure to the desired value by turning the knob clockwise to increase it and counter-clockwise to decrease it (Fig.7). The desired value is displayed on gauge no.3. P a g e Hobby Oil Free Series: AIRBAG User Guide... -
Page 8: Thermal Protection
• The compressor is cut off from the compressed air system. • The compressor and the internal pneumatic circuit are unloaded from any pressure. PANEL REMOVAL Unfasten the lock screws to remove the side panels (Fig.9) P a g e Hobby Oil Free Series: AIRBAG User Guide... -
Page 9: Water Drainage
The internal pneumatic circuit and the compressor must be unloaded from any pressure. • Unfasten the hexagonal head of the valve (A). • Clean the rubber disc (B) and its housing carefully. • Reassemble carefully. P a g e Hobby Oil Free Series: AIRBAG User Guide... - Page 10 • Never direct the air nozzleat persons or animals. • Do not transport the compressor with the tank under pressure. • Keep children and animals away from the area where machine is operating. 10 | P a g e Hobby Oil Free Series: AIRBAG User Guide...
- Page 11 AIRBAG HP1.5 dB(A) 65 Rpm 2850 - 3450 The sound level value may increase by 1 to 10 dB(A) depending on the area where the compressor is installed. 11 | P a g e Hobby Oil Free Series: AIRBAG User Guide...
- Page 12 Illustrations 12 | P a g e Hobby Oil Free Series: AIRBAG User Guide...
- Page 13 1. For a period of 12 months from the date of purchase, the Product will be free from defects due to defective factory workmanship or materials; and 2. For a period of 12 months from the date of purchase that Pilot Air branded accessories supplied by Pilot Air will be free from defects due to defective factory workmanship or materials.
- Page 14 In the circumstances where the guarantees under the Australian Consumer Law do not apply in respect to the purchase of its Products, Pilot Air will not be liable for any losses or damages (whether direct or indirect) including property damage or personal injury, consequential loss, economic loss or loss of profits, arising in contract or negligence or howsoever arising.
- Page 15 Air will bear all of the claimant's reasonable and proximate expenses incurred as a result of claiming under this warranty. The claimant is to inform Pilot Air in writing to the address identified below within 21 days from when the claimant first makes a claim under this warranty of all such claims and expenses and provide it with copies of all receipts and invoices where relevant before any reimbursement is made by Pilot Air to the claimant.
- Page 16 Warranty Important Note: If you acquire goods from Pilot Air as a consumer according to the Australian Consumer Law, our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure and for compensation for any other reasonably foreseeable loss or damage.
