- Page 1 User Manual: PS-DIN-DC24/48/72 Booster Version 4.2020...
- Page 2 Introduction This Rugged design 72Watts Power Booster is a power device which boosts 24VDC up to 55VDC to power up your PD for up to 72Watts. It is designed for environments where 48VDC power is not available. With all industrial graded components, this industrial power booster will guarantee a steady voltage output to your PD in a harsh environment.
- Page 3 Power connection This unit provides a 4 pin terminal block. It can be operated using 24-56 VDC power source. Always make sure your input voltage is within this supported voltage range To connect power: Follow the printed polarity for V+, V-. Connect positive wire to V+, connect negative wire to V- Power connecting procedure: Step1 －...
- Page 4 LED indicator Voltage adjustable Knob – Rotate the Knob clockwise to increase output voltage from 48VDC to 55VDC Rotate the Knob counterclockwise to decrease output voltage from 55VDC to 48VDC Power Connector PWR (Amber) V IN – VDC Power Input ON- power ready.
- Page 5 Specifications PWR(Amber) ON- power ready. OFF – no power input Overload current protection Present 4 pin terminal block. Removable Terminal Block / 2 pin for 24-56VDC Voltage input, Power Connector 2 pin for 48 to 55 VDC Voltage output Wire range: 0.34mm^2 to 2.5mm^2 Solid wire (AWG):12-24/14-22 Removable Terminal Block Stranded wire (AWG): 12-24/14-22...
- Page 6 Housing Dimension (mm) Page 6/6...
