Nemo Meter Set‐Up
R
F
EASON
New Issue
Added More Info on configuration.
Figures 2, 3 & 4
Test Procedure
C
OR
HANGE
Procedure No.: T18
Page 1 of 4
Revision: 1
Approved: F. Foley
O
&
A
RIGINATED
PPROVED
Francis Foley
Francis Foley
Uncontrolled when printed.
Advertisement
Table of Contents
Related Manuals for STT Nemo
Summary of Contents for STT Nemo
- Page 1 Procedure No.: T18 Test Procedure Page 1 of 4 Revision: 1 Nemo Meter Set‐Up Approved: F. Foley & EASON OR HANGE RIGINATED PPROVED Oct 2017 0 New Issue Francis Foley Added More Info on configuration. July 2018 1 Francis Foley Figures 2, 3 & 4 ...
- Page 2 Procedure No.: T18 Test Procedure Page 2 of 4 Revision: 1 Nemo Meter Set‐Up Approved: F. Foley 1 Purpose The purpose of this procedure is to explain how to Set‐Up and Program a Nemo Panel Meter 2 Equipment Required Appropriate Supply Voltage 230VAC 50Hz or 24VDC (Meter Dependent) Nemo Instruction Manual Figure 1. Nemo Panel Meter 3 Programing and Set‐Up Instructions Connect the meter to the auxiliary supply voltage 230VAC or 24VDC as appropriate; terminals 20+ and 21‐. Connect the meter to the appropriate circuit 1N1E or 3N3E as shown on the Nemo Instruction Manual. Press the 2 Centre Keys on the Meter (Up and Down Arrows) until the PASS symbol appears in the display. Change the display to 1000 by pressing the up arrow once and then hit the Enter Key (Under E‐T) If the meter is connected to a 1N1E circuit then: Uncontrolled when printed. ...
- Page 3 Procedure No.: T18 Test Procedure Page 3 of 4 Revision: 1 Nemo Meter Set‐Up Approved: F. Foley 3.5.1 If the meter is connected to a 1N1E circuit press the Enter Key again and then change the second screen to L in2 A by pressing the down arrow key 10 times, then hit Enter. Note on the top corner there will be a number 1 shown as in the Figures below. Top Corner: 1 Line 1: L in 1 Line 2: Line 3: Bottom: 1-11 Figure 2. Screen 1 Top Corner: 1 Line 1: ...
- Page 4 Procedure No.: T18 Test Procedure Page 4 of 4 Revision: 1 Nemo Meter Set‐Up Approved: F. Foley 3.5.7 Press Enter twice after the Ct ratio is set and the meter will save the settings. 3.5.8 The voltages and currents can be checked easily by using a known load such as a fan heater. If the meter is connected to a 3N3E circuit then ignore steps 3.5.1 and 3.5.2 and then complete the rest of the steps in the same way except set the SYS display to read 3n1E in step 3.5.2. Uncontrolled when printed. ...
