emz smart Box Quick Start Manual page 4

„Service":
1 Adjustments for the desired time period.
2 Display of temperatures, energy-yield, CO
output activity
3 Hide / show by clicking on the related curve
For displaying detailed values, move the cursor within the graph. Zoom range adjustment by click and
hold the left mouse key.
2
1
1 Confirm the erase by click on „delete all data".
2 A click on „Cancel" aborts the process. After that the ser-
vice page is displayed.
1 1 1
2
3
- savings and
2
Quick Start Guide smartBox V1.0.1| -4- | V1.1 | 10.11.2016
1 Choose the related menu
2 Adjust the desired parameter
3 By clicking the save button the adjustment is transmitted
to the controller
3
2
1 Select the desired „.dfu-file" from the drop-
field. Continue with step 3. Otherwise do step first.
2 Click on „Upload File", to upload the „dfu-
from your computer.
3 Start the upgrade by clicking on „start update".
Please notice: The responsibility for firmware upgrates is falling to our support partners. So if
needed, please ask them for firmware upgrades.
EN
3
1
2
1
down
File"
