User manual 4D massage chair HM-8200
Remote control
On/Off: Press the on/off button to start the massage chair; the massage chair will
now place itself in standby mode. Select an automatic or manual massage program
from the menu; the massage device will first detect the shoulder height and then
start the massage. To turn the chair off, press the on/off button again, the massage
chair will now turn off and return to its original position. The control panel will shut
down in 3-5 seconds.
Menu: It is possible to set and view all the massages using the menu button. Some
settings can also be adjusted here. This includes the air cushions, foot roller, time of
the desired massage and language; there is also a stop function to stop the chosen
massage. The user can choose between all the different massage functions here.
Press this button again to return to the home page.
Timer: The standard massage time is set to 20 minutes. The duration of the massage
can be adjusted in 10-minute increments by pressing this button. The time at the top
right will change each time this button is pressed. When the time is up, the massage
chair will turn itself off and return to its original position.
Hot rocks: Press this button to start the "Quick relax program". This is a massage
program lasting eight minutes. Press again to stop the massage.
Navigation: The direction button has four options: up, down, left and right. The menu
button allows the user to press up or down to choose a massage. The user presses
left or right to access the previous or next menu. The up and down button can also be
used to adjust the massage position in acupuncture point tracking. When being used
as music controls, the left and right buttons skip to the previous and next track. The
up and down buttons adjust the volume. The volume increases by one bar every two
times the button is pressed.
OK: Press the OK button to confirm the menu selection and move to the next menu.
Reducing the angle of the backrest: Pressing this button will decrease the angle of
the backrest. When the button is released, both the backrest and the leg support will
stop moving. The text, "Chair posture adjusting..." will appear on the controller
1
Advertisement
Related Manuals for Health Mate HM-8200
Summary of Contents for Health Mate HM-8200
- Page 1 User manual 4D massage chair HM-8200 Remote control On/Off: Press the on/off button to start the massage chair; the massage chair will now place itself in standby mode. Select an automatic or manual massage program from the menu; the massage device will first detect the shoulder height and then start the massage.
- Page 2 display while the massage chair position is adjusting. The massage must be in progress before this function can be used. Increasing the angle of the backrest: Pressing this button will increase the angle of the backrest. When the button is released, both the backrest and the leg support will stop moving.
- Page 3 extra massage functions, namely “Therapy”, “Recovery”, “Relaxation”, “Healing”, “Sleeping” and “Slimming”. Manual mode: After switching the massage chair on, press this button to select a manual program. Pressing the button will cause the selected manual program to appear at the top of the start screen. Press again to go to the next program. The choices offered are “Kneading”, “Knocking”, “Tapping”, “Kneading &...
- Page 4 Extra information: After the power has been applied, press the power button, a buzzer will beep once shortly. The LCD screen will now appear, after 2-3 seconds it will show the home screen and enter standby mode. Pressing the menu button will enable management of all possible massage functions and the settings.
- Page 5 Note: 1. Overall: When choosing a full massage, the shoulder height detection process will only be performed once. 2. Partial or point: The “Partial” and “Fixed point” massages do not require shoulder height detection, choosing a different massage will cause a shoulder height detection to be performed.
