Over-Center Hydraulic Aluminum Boat Lift
6,700 lbs / 3,039 kg Capacity
866.GoBasta
www.gobasta.com
© Basta, Inc.
2020
Specifications subject to change.
04/21
L392-0100D

Advertisement

loading
Need help?

Need help?

Do you have a question about the 6.7k60 AR and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Basta Boatlifts 6.7k60 AR

  • Page 1 MODEL # 6.7k REPLACEMENT PARTS INSTALLATION ASSEMBLY Over-Center Hydraulic Aluminum Boat Lift 6,700 lbs / 3,039 kg Capacity 866.GoBasta www.gobasta.com © Basta, Inc. 2020 Specifications subject to change. 04/21 L392-0100D...
  • Page 2 INDEX Warning Page 2, 3 Parts List and Diagrams Pages 4 - 5, 13 - 14 Assembly Instructions Pages 6 - 15 First Use / Adjustments Page 16 Troubleshooting / FAQ Page 18 Maintenance Page 19 Warranty Page 20 DANGER CLEAR! STAY Always avoid being under, and maintain...
  • Page 3: Maximum Capacity

    lift unattended INSPECT the lift monthly for frayed hoses, loose fasteners and corrosion In the following pages various symbols are used: indicates an illustration for a procedure. indicates a major part described in the parts list on pages 4 and 5. indicate hardware items shown above and described in the parts list 1&2 on pages 4 and 5.
  • Page 4 15&16 15&16 15&16 15&16 15&16 15&16 4&2 1&2 4&2 7&2 1&2 7&2 7&2 1&2 1&2 1&2 1&2 7&2 1&2 7&2 1&2 7&2 1&2 LIFT: A206-6603 7&2 1&2 7&2...
  • Page 5 MECHANISM PARTS LIST SEE PAGES 13 & 14 FOR ELECTRICAL AND HYDRAULIC PARTS ITEM PART NO. DESCRIPTION QTY. ITEM PART NO. DESCRIPTION QTY. K200-0001 A427-0024 Bunk Rail Assembly, Left Std. Foot Pad W117-0001 MM * A427-0031 Bunk Rail Assembly, Left Rubber A427-0025 Bunk Rail Assembly, Right Std.
  • Page 6 ASSEMBLY INSTRUCTIONS NOTE: use a small amount of 'moly' lube on bolt threads NOTE: assemble lift on level ground and adjust legs so that lift base frame is level during lift assembly. NOTE: the 3 different holes shown can be used for pin “11” to allow fine height adjustment after installation DOWN...
  • Page 7 Assemble lift on level ground and adjust legs so that lift base frame is level during lift assembly. Assemble lift on level ground and adjust legs so that lift base frame is level during lift assembly.
  • Page 8 ASSEMBLY INSTRUCTIONS NOTE: use a small amount of 'moly' lube on bolt threads NOTE: stop blocks slope down & forward Assemble lift on level ground and adjust legs so that lift base frame is level during lift assembly.
  • Page 9 NOTE: forward H-frame BOTH is shown. Aft H-frame H-FRAMES installation is the same are installed with curved Bushings are pre-installed - side up remove cable ties used for shipping Assemble lift on level ground and adjust legs so that lift base frame is level during lift assembly.
  • Page 10 ASSEMBLY INSTRUCTIONS NOTE: use a small amount of 'moly' lube on bolt threads 15+16 Assemble lift on level ground and adjust legs so that lift base frame is level during lift assembly.
  • Page 11 ASSEMBLY INSTRUCTIONS NOTE: use a small amount of 'moly' lube on bolt threads Install cylinder with lift in 'down' position washers here NOTE: install plastic washers here NOTE: install cylinder with hose fittings facing dock!
  • Page 12 ASSEMBLY INSTRUCTIONS NOTE: use a small amount of 'moly' lube on bolt threads The angles and directions of bunk rail assemblies MUST face the directions shown below. LONG SHORT FORWARD AT AFT cotter pin washer cotter pin washer bushings are pre-installed Right Rail [NN] Left Rail [MM]...
  • Page 13 CONNECT POWER UNIT FEMALE QUICK COUPLER DO NOT SUBMERSE H700-0019 COMPLETE POWER PACKAGE Keep inside dry H653-0013 Prevent unauthorized use - KEEP BOX LOCKED up/down switch NOTE: NOTE: power REMOVE SHIPPING PLUG IN REMOVE SHIPPING PLUG IN switch RESERVOIR AND REPLACE RESERVOIR AND REPLACE solar WITH BREATHER PLUG...
  • Page 14 POWER SYSTEM COMPONENTS SOLAR PANEL ASSEMBLY R281-0004 Padlock not included ENCLOSURE C243-0003 NOTE: NOTE: REMOVE SHIPPING PLUG IN REMOVE SHIPPING PLUG IN RESERVOIR AND REPLACE RESERVOIR AND REPLACE WITH BREATHER PLUG WITH BREATHER PLUG BEFORE START-UP BEFORE START-UP CONTROL PANEL ASSEMBLY R815-0008 pre-wired...
  • Page 15 ASSEMBLY INSTRUCTIONS NOTE: use a small amount of 'moly' lube on bolt threads raise lift to install 1/4 x 1.75” bolts ("15") 15+16 15+16 15+16 15+16 Assemble lift on level ground and adjust legs so that lift base frame is level during lift assembly.
  • Page 16 FIRST USE AND ADJUSTMENTS First test lift on dry ground for oil leaks, remote control function and correct operation. IMPORTANT: After installation, the legs MUST be adjusted so that the lift frame is level. Lift must move into Over-Center position when fully raised. H-frame arms should appear to be tilted slightly forward.
  • Page 17 Use these diagrams to help place the lift 135" 117" 36" 138" 21" 84" 70" 26" 53" 24" 24" 39" 22"...
  • Page 18 We use a special low-toxicity hydraulic fluid that is safe for the environment. This mineral oil based fluid is different than food-grade oil. Only use Basta Boatlifts approved fluid in your hydraulic system. FOR ASSISTANCE OR SERVICE: Q: WHAT IF I GET A NEW BOAT? Contact your local dealer or call 1 - 866 - GO - BASTA Re-leveling the boat lift may be necessary.
  • Page 19: Maintenance

    The hydraulic fluid level should be about one inch below the top of the reservoir with the lift DOWN. DO NOT add fluid with the lift in the raised position! Use only Basta Boatlifts biodegradable non-toxic hydraulic fluid. DATE: WHAT WAS DONE:...
  • Page 20 Company or when an active Authorized Dealer is not located on the water. Welcome to the Basta Boatlifts family and Boat Happy! within 50 miles of the location of the Product.
