ELK-M1XRF2H
v2
Wireless Receiver and Input Expander
Compatible with Wireless Transmitters that operate on the 345MHz
Frequency and adhere to the Ademco 5800 protocol.
A list of known compatible transmitters can be found inside.
INSTALLATION
MANUAL
IMPORTANT NOTE:
Please consult the Elk M1 Dealer website for downloads of the latest M1 Control firmware and
ElkRP Software. For compatibility with this Receiver we recommend the M1 Control be operating
firmware version 5.3.10 or higher and the ElkRP software be version 2.0.36 or higher.
Ademco is a registered trademark belonging to Honeywell.
TM
L675 Rev. C 3/14/2019
Advertisement
Table of Contents
Related Manuals for Elk Products ELK-M1XRF2H
Summary of Contents for Elk Products ELK-M1XRF2H
- Page 1 ELK-M1XRF2H Wireless Receiver and Input Expander Compatible with Wireless Transmitters that operate on the 345MHz Frequency and adhere to the Ademco 5800 protocol. A list of known compatible transmitters can be found inside. INSTALLATION MANUAL IMPORTANT NOTE: Please consult the Elk M1 Dealer website for downloads of the latest M1 Control firmware and ElkRP Software.
-
Page 2: Table Of Contents
DC 20402. The user shall not make any changes or modifications to the equipment unless authorized by the Installation Instructions or Users Manual. Unauthorized changes or modifications could void the user’s authority to operate the equipment. Page 2 ELK-M1XRF2H v2 Installation Manual... -
Page 3: Installation And Setup
OVERVIEW The ELK-M1XRF2H v2 Wireless Receiver allows the ELK-M1 Controllers to accept wireless transmitters that operate on the 345MHz Frequency and adhere to the Ademco 5800 protocol. See the list of known compatible transmitters. The receiver connects to the M1's RS-485 four (4) wire data bus and integrates much the same as a hardwired zone expander. It can be installed remotely from the control virtually anywhere inside the premises up to the maximum allowed distance of the data bus. -
Page 4: Setting The Data Bus Address Of The Wireless Receiver And The Starting Wireless Zone Id
48 hardwired expanded zones even on a fully loaded wireless panel. If hardwired expanded zones are installed inside the range of zones 17 through 160 a full group of 16 wireless zones will be lost even if only a few of the hardwired zones are being used. Page 4 ELK-M1XRF2H v2 Installation Manual... -
Page 5: Data Bus Enrollment
Bus Modules that are enrolled. To view the enrolled devices and/or remove a XX Bus Modules device press the RIGHT arrow key next to the word Edit. Enrolled, Edit r Press the * or Exit keys to exit Installer Programming. ELK-M1XRF2H v2 Installation Manual Page 5... -
Page 6: Operation
Should the announced level number seem unusually high we recommend retesting the sensor(s) a second or third time to get a more correct packet decode level. Page 6 ELK-M1XRF2H v2 Installation Manual... -
Page 7: List Of Ademco 345Mhz Transmitters
Repeat the enroll process for each of the other zones prior to setting their Loop #. Use Enroll Method 4 Smoke Detector Ademco Part # 5808W3 Use Enroll Method 4 Heat 'Rate Of Rise' Xmtr Ademco Part # 5809 ELK-M1XRF2H v2 Installation Manual Page 7... - Page 8 Step 4 - To view the Xmtr Decimal ID & set the Loop # it is necessary to reselect the zone number and press the left arrow "HW". Step 5 - Move cursor over to Loop using the right arrow. Set Loop # for smoke and heat Xmtr to a "1". When done press ELK twice. NOTE: In the Keypad enroll process an Ademco Xmtr ID displays as a 7 digit HEX number instead of the DECIMAL number printed on the Sensor & Packaging. The reason for this is that M1 originally accomodated only GE wireless which used HEX ID numbers. The display will not accomodate both, but the Decimal ID can viewed as follows: Step 1. Locate the Zone by entering the 3 digit zone #, or use the keypad Up/Down arrow keys to scroll and locate the zone. Step 2. Press the left arrow "HW". The displayed Decimal ID should match the label on the sensor and the Loop should be verified as correct. When done press Elk twice. Page 8 ELK-M1XRF2H v2 Installation Manual...
- Page 9 This page intentionally left blank. ELK-M1XRF2H v2 Installation Manual Page 9...
-
Page 10: Programming Via Keypad
The sensor will appear to be dead during this times. For this reason wireless PIRs are not recommended for automation or occupancy detection applications. WZn017 shown as an example only! < continued on next page > † Not evaluated by UL Page 10 ELK-M1XRF2H v2 Installation Manual... - Page 11 Key 7. The M1 Default Event Value is "0000" or "No default function". [name of event] Pressing the Light and Asterisk buttons together momentarily will trigger the event assigned to Key 8. The M1 Default Event Value is "0000" or "No default function". ELK-M1XRF2H v2 Installation Manual Page 11...
-
Page 12: Appendix A - Data Bus Selection Tables
Cells marked " RRF " indicate bus addresses where ONLY a redundant Wireless Receiver can be installed. Cells marked " H or RRF " indicate bus addresses where either a Hardwired Expander OR a redundant Wireles Receiver can be installed. Page 12 ELK-M1XRF2H v2 Installation Manual... - Page 13 Cells marked " RRF " indicate bus addresses where ONLY a redundant Wireless Receiver can be installed. Cells marked " H or RRF " indicate bus addresses where either a Hardwired Expander OR a redundant Wireless Receiver can be installed. ELK-M1XRF2H v2 Installation Manual Page 13...
-
Page 14: Appendix B - Examples Of Zone Configurations
Zones Bus Addr Zones Bus Addr Wireless Rec. * Wireless Rec. * 177‐192 Expander 177‐192 177‐192 Hardwired Hardwired Hardwired Zones Bus Addr Zones Bus Addr Zones Bus Addr Exp. or Exp. or Exp. or 193‐208 193‐208 193‐208 Keypad Zns Keypad Zns Keypad Zns Bus Addr Bus Addr Bus Addr Bus Addr Bus Addr Bus Addr Page 14 ELK-M1XRF2H v2 Installation Manual... -
Page 15: Appendix C - Installing Multiple Redundant Receivers
Receivers are Addresses 3 and 4. In theory it is possible to install up to 9 total Wireless Receivers on a single M1 Control provided none of those addresses are being used by a Hardwired Expander. * For large installations or added coverage in areas experiencing poor wireless conditions additional Wireless Receivers can be connected to the data bus. Each Receiver must be assigned its own Bus Address and be enrolled for proper supervision. Loss of any enrolled bus device causes a Missing Bus Device Trouble. Warehouse Production Sales Offices Additional Wireless Shipping First Wireless Additional Wireless Receiver Receiver Receiver Bus Address 3 Bus Address 2 Bus Address 4 Example of larger Commercial Building with 3 Wireless Receivers ELK-M1XRF2H v2 Installation Manual Page 15... - Page 16 PO Box 100 3266 US Hwy 70 West Hildebran, NC 28637 828-397-4200 828-397-4415 Fax http://www.elkproducts.com Page 16 ELK-M1XRF2H v2 Installation Manual...
