ELK-M1XRFEG
Wireless Receiver and Input Expander
Compatible with many models of GE branded Wireless Sensors,
including other brands which comply with the GE protocol.
Refer to page 8 & 9 for listing of known compatible sensors.
INSTALLATION
MANUAL
IMPORTANT NOTE:
ELK-M1G and M1EZ8 Controls SHOULD have application firmware ver. 5.2.0 or higher
to be compatible with the M1XRFEG Receiver. Refer to M1Dealer website for update 'flash' files.
The latest version of ElkRP Programming Software is required for programming.
TM
GE is a registered trademark belonging to GE & United Technologies.
PO Box 100
3266 US Hwy 70 West
Hildebran, NC 28637
828-397-4200 828-397-4415 Fax
L629 Rev. B 7/30/2012
http://www.elkproducts.com
Advertisement
Table of Contents
Related Manuals for Elk Products ELK-M1XRFEG
Summary of Contents for Elk Products ELK-M1XRFEG
- Page 1 ELK-M1XRFEG Wireless Receiver and Input Expander Compatible with many models of GE branded Wireless Sensors, including other brands which comply with the GE protocol. Refer to page 8 & 9 for listing of known compatible sensors. INSTALLATION MANUAL IMPORTANT NOTE: ELK-M1G and M1EZ8 Controls SHOULD have application firmware ver.
-
Page 2: Table Of Contents
Table of Contents General Installation and Setup ..................... 4 Setting the M1XRF Data Bus Address and the Starting Wireless Zone ID ..........5 Data Bus Enrollment:: ..........................6 Data Bus Address Switches........................6 Operation ............................7 Handling Received Transmissions: ......................7 Diagnostic LEDs: ............................. - Page 3 OVERVIEW The "EG" model of the ELK-M1XRF Wireless RF Receiver (full part # ELKM1XRFEG) allows the ELK-M1 and ELK-M1EZ8 Controls to accept GE 319.5MHz format Wireless Transmitters, including other brand sensors that are compatible with the GE protocol. Refer to the list of compatible transmitters elsewhere in the manual. Regardless of model, an M1XRF receiver attaches to the four (4) wire (keypad) data bus and integrates in much the same way as a hardwired zone expander, with the exception that a single M1XRF can handle up to 144 wireless zones (e.g.
-
Page 4: General Installation And Setup
General Installation and Setup INSTALL UNIT * SET ADDRESS AND OPTION JUMPERS * ACTIVATE M1 BUS ENROLLMENT PROCESS Dual Antennas Antenna 1 Antenna 2 ELK-M1XRFEG JP1 Bus Terminating Jumper RS-485 ELK-M1XRFEG Data Bus Connections Data Bus Address Switches NOTE: Jumper JP1makes it convenient to terminate the RS-485 Data Bus if this is the last installed device. -
Page 5: Setting The M1Xrf Data Bus Address And The Starting Wireless Zone Id
Setting the M1XRF Data Bus Address and the Starting Wireless Zone ID Devices that communicate on the RS-485 4-wire data bus must each have a valid address setting (from 1 to 15) within their device type. Keypads are TYPE 1, Hardwire and Wireless Input expanders are TYPE 2, Output expanders TYPE 3, Serial expanders TYPE 4. -
Page 6: Data Bus Enrollment
M1XIN Zone Expanders M1XRF Wireless Receivers Switch Settings Switch Settings Data Bus Data Bus Suggested Wireless Starting and Ending Address Address "Starting Point" Zone Numbers Other Jumper On Off On Off Zone 17 Zones 17 - 32 Settings: On On Off On On Off Zones 33 - 48 Zone 33... -
Page 7: Operation
Operation Handling Received Transmissions: Operationally when a transmitter signal is received by the M1XRF it quickly scans through a filter of valid transmitter sensors to determine if it that sensor has been enrolled into the M1 or EZ8 control. If that transmitter is valid then its data will be sent to the M1 Controller for additional processing. -
Page 8: List Of Supported Transmitters - Ge "Utc" Format (319.5Mhz) & Brand
List of supported Transmitters - GE "UTC" Format (319.5MHz) & Brand The below listed Transmitters have been tested and found to be compatible with the ELK-M1XRFEG Receiver. Elk makes no guarantee for any other transmitter model(s). All information shown below is based on the best available data provided by the transmitter manufacturer. Information subject to change without notice. -
Page 9: List Of Compatible Transmitters (319.5Mhz) Made By Resolution Products
List of compatible Transmitters (319.5MHz) made by Resolution Products Device Part Number(s) & Description Four Button Keyfob Transmitter - Resolution Products Part # RE100 Enroll Process - Press and hold the Lock and Unlock Buttons (buttons 1 & 2) together at the same time. >OPTIONS –... -
Page 10: Programming Via Keypad
Programming via Keypad From the keypad enter the Installer Level Programming mode. Press ELK, 9 > (enter installer code). Navigate to the Wireless Setup - Menu 14 and press the RIGHT arrow key to select. 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 There are four (4) wireless setup submenus: 1-Receiver Options, 2-Xmitter Options, 3-Xmitter 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 1 4 - W i r e l e s s... - Page 11 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 This submenu is used for manually enrolling transmitters. To select this menu press the 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 3:Learn Sel...
-
Page 12: Appendix A - Data Bus Selection Tables
Appendix A - Data Bus Selection Tables These tables are intended to help visualize how the Wireless Zones and Hardwired Zones share the data bus address assignments. They should help with the setting of a starting zone ID and data bus address(s) to obtain the total and best mix of wireless and hardwired zones. - Page 13 Appendix A - Data Bus Selection Tables (cont'd) No RF Zones Here Starting Total Data Bus Data Bus Data Bus Data Bus Data Bus Data Bus Data Bus Data Bus Data Bus Data Bus Data Bus Zn ID #65 Wireless Addr 2 Addr 3 Addr 4...
-
Page 14: Appendix B - Examples Of Zone Configurations
Appendix B - Examples of Zone Configurations Example C Example A Example B 48 Hardwired Zones 16 Hardwired Zones 112 Wireless Zones All 208 Zones as Hardwired 144 Wireless Zones PLUS 2 Redundant Receivers Zones Inputs on Zones Inputs on Zones Inputs on 1-16... -
Page 15: Appendix C - Installing Multiple Redundant Receivers
Appendix C - Installing Multiple Redundant Receivers After the first M1XRF Receiver has been installed, additional receivers can be installed for redundancy or improved coverage and range. Each addtional M1XRF will require its own data bus address and must be enrolled into the control. The data bus address setting of any additional "redundant"... - Page 16 Page 16 M1XRFEG Installation Manual...
