Broan 112 Specification Sheet

Broan kickspace heaters 112 & 114 specification sheet
Hide thumbs

Advertisement

Quick Links

KICKSPACE HEATERS
MODELS 112 & 114
Low-profile design provides floor-level heat from
out-of-the-way locations.
FEATURES
Attractive white finish
Vertical louvers – disperse heat evenly
Front-mounted, snap action, bimetallic thermostat (Model
112 only)
Heavy-duty, steel sheathed, plate-finned element
Factory-wired for 240 VAC, 1500W
Field-convertible to operate on 120 VAC, 750 or 1500W
Mounts into standard kickspaces beneath cabinets, vanities,
counters, stairways, etc.
ACCESSORIES (purchase separately)
Model 86W Line-Voltage Thermostat
Model 59W / 59V 60 Minute Timer
Model 61W / 61V 15-Minute Timer
Model 90 Built-in Thermostat Kit (Model 114 only)
SPECIFICATIONS
VOLTS
WATTS AMPS BTU/HR
240
1500
6.2
120
750
6.2
208
1125
5.4
120
1500
12.5
BOLD ratings are factory-wired.
Broan-NuTone LLC, 926 West State Street, Hartford, WI 53027 (1-800-637-1453)
REFERENCE
QTY.
SHIPPING
WEIGHT
5120
2560
12 lbs.
3840
5120
REMARKS
SPECIFICATION SHEET
Model 112
TYPICAL SPECIFICATION
The heater shall be Broan Model 112 (Model 114).
Unit shall have heavy-gauge steel housing and grille with
white finish.
Heater will have heavy-duty, steel-sheathed, plate-finned
element. Heater will have front-mounted thermostat (Model
112 only).
Heater to deliver 1500 watts of fan-forced heat from 240 VAC
circuit. It must be convertible to operate on 120 VAC, full or
half-wattage.
Heater shall be U.L. Listed.
Project
Location
Architect
Engineer
Contractor
Submitted by
01C
Date
99041277E
