P - 475
P - 475/1 - 5 units
P - 475/2 - 3-sectional with rollers
OWNER'S MANUAL
WARRANTY CARD
SPARE PARTS CATALOGUE
MOUNTED RIDGER
Norma
- 3 units
PRIOR TO STARTING WORK, PLEASE READ
THE OPERATING INSTRUCTIONS
Spółka z ograniczoną odpowiedzialnością
07-100 Węgrów, ul. B. Joselewicza 2
Węgrów 2017, Edition 6, Eng
BOMET
Spółka Komandytowa
tel. (0 prefix 25) 691 78 06
-------------
Original manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Norna P-475 and is the answer not in the manual?

Questions and answers

Related Manuals for Bomet Norna P-475

Summary of Contents for Bomet Norna P-475

  • Page 1 P - 475/1 - 5 units P - 475/2 - 3-sectional with rollers PRIOR TO STARTING WORK, PLEASE READ THE OPERATING INSTRUCTIONS BOMET Spółka z ograniczoną odpowiedzialnością Spółka Komandytowa 07-100 Węgrów, ul. B. Joselewicza 2 tel. (0 prefix 25) 691 78 06 Węgrów 2017, Edition 6, Eng...
  • Page 3 Spółka Komandytowa 07-100 Węgrów, ul. B. Joselewicza 2 tel. (0 prefix 25) 691 78 06 http:www.bomet.pl; e-mail: bomet@bomet.pl DECLARATION OF CONFORMITY for a machine According to the Ordinance of Minister of Economy of 21 October 2008 (Journal of Laws “Dziennik Ustaw” No 199, item 1228) and European Union Directive 2006/42/WE of 17 May 2006 (Official Journal of the European Union L.
  • Page 4 - 2 -...
  • Page 5 Spółka Komandytowa 07-100 Węgrów, ul. B. Joselewicza 2 tel. (0 prefix 25) 691 78 06 http:www.bomet.pl; e-mail: bomet@bomet.pl DECLARATION OF CONFORMITY for a machine According to the Ordinance of Minister of Economy of 21 October 2008 (Journal of Laws “Dziennik Ustaw” No 199, item 1228) and European Union Directive 2006/42/WE of 17 May 2006 (Official Journal of the European Union L.

  • Page 6: Warranty Card

    WARRANTY CARD P 475 Mounted ridger type Serial number…………………………. 202 ..Production date Inspector signature…………………… Date of sale…………………………… ……………………………. Seller signature…………………………. Seller stamp CAUTION: It is seller’s obligation to fill in the warranty card and complaint forms carefully (legibly). Lack of e.g. date of sale or stamp of sales point will put the user at risk of not acknowledging possible complaints.
  • Page 7 ------------------------------------------------------------------------------------------------------------- Complaint form no 1 P 475 Mounted ridger Serial number…………… Date of purchase……………... Seller’s signature and stamp Complaint protocol number………………….. Complaint form no 2 P 475 Mounted ridger Serial number…………… Date of purchase……………... Seller’s signature and stamp Complaint protocol number………………….. Complaint form no 3 P 475 Mounted ridger...
  • Page 8 After repair I received technically efficient machine on……………………… (date) ………………………. User’s signature Notices: ………………………………………………………………………………………………………… ………………………………………………………………………………………………………… …………………………………………………………………………………. After repair I received technically efficient machine on……………………… (date) ………………………. User’s signature Notices: ………………………………………………………………………………………………………… ………………………………………………………………………………………………………… …………………………………………………………………………………. After repair I received technically efficient machine on……………………… (date) ……………………….
  • Page 9 IDENTIFICATION MOUNTED RIDGER Mounted ridger of series P475 has a rating plate, fitted in the front part of the frame of the ridger frame. Basic data which serves for identification of the machine: manufacturer’s name, machine symbol, serial number, year of production, is put there. Data placed on the rating plate serves for identification of the ridger and ought to correspond to the following data, filled in during the sales.

  • Page 10: Table Of Contents

    TABLE OF CONTENTS WARRANTY CARD ..........................4 INTRODUCTION ..........................9 INTENDED USE OF THE RIDGER ....................9 SAFETY PRECAUTIONS AND WARNINGS ................10 3.1. S ................... 10 YMBOLS MEANING AND APPLICATION 3.2. E ..........................10 XPECTED USE 3.3. D ....................10 ESCRIPTION OF RESIDUAL RISK 3.4.

  • Page 11: Introduction

    INTRODUCTION This manual is attached to each machine to make a user acquainted with construction, operation and adjustment of the mounted ridger. Its aim is also warning about existing or possible threats. The manual also contains information on preparation of the ridger for operation and for transportation on public roads.

  • Page 12: Safety Precautions And Warnings

    SAFETY PRECAUTIONS AND WARNINGS 3.1. Symbols: meaning and application In the present manual symbols are used in order to draw the reader’s attention and stress certain particularly important aspects requiring discussion. DANGER This indicates danger, with a possible serious accident risk. Not obeying recommendations marked with this sign may cause a situation of a serious risk of sustaining an injury by the operator and/or people nearby! Obey strictly these recommendations!

  • Page 13: Estimation Of Residual Risk

    ® Although BOMET company takes responsibility for pattern-designing and construction in order to eliminate danger, however certain risk elements during mounted ridger operation are unavoidable.
  • Page 14 General regulations  Apart from this manual, one shall also follow traffic regulations and occupational safety and health regulations.  Warnings (pictograms) placed on the ridger give advice concerning safety of the user and other people, and avoiding accidents.  When driving on public roads, it is obligatory to follow regulations included in Highway Code.
  • Page 15  Removing clogs can be performed after lowering the tool onto the ground and turning off the tractor engine.  Work with a ridger on slopes with gradient exceeding 8.5° is not allowed.  It is not allowed to use tractor reverse gear during work, when the tool is in the working position.

  • Page 16: Standard Conformity

    ® In relation to described in this manual types of machines, company does not BOMET acknowledge any civil responsibility towards: improper or inconsistent with the manufacturer’s recommendations using the machine, using the machine in a way breaking domestic law concerning safety and preventing...
  • Page 17 the ridger, there are warning signs – pictograms which indicate for possibility of danger and present manners of avoiding it. In table 1 pictograms placed on the machine and their meaning have been specified. Safety pictograms should be protected against being lost and against loss of legibility. Lost or illegible signs and captions should be replaced with new ones.

  • Page 18: Usage Regulations

    USAGE REGULATIONS 4.1. General information The P475 series mounted ridgers are manufactured in two working versions as a 3- section machine for 3 rows or 5-section machine for 5 rows. Mounted ridgers of P475 series are suitable for operation on slopes not exceeding 8.5 and cooperate with tractor classes 0.6 and 0.9 (see technical characteristics - table 4) equipped with standard wheel ballasts.

  • Page 19: Equipment And Fittings

    Figure 2. Ridger with rollers - general construction: 1 - frame, 2 - articulated parallelogram, 3 - spring tine set, 4 copying wheel, 5 - roller arm, 6 - string rollers, 7 - ripper, 8 - cultivator point The ridger can be additionally equipped with a section of a hoe and string rollers. The section of the hoe works using a parallelogram (2).

  • Page 20: Assembly Of The Ridger

    Before suspension of the machine, lower rods of the tractor’s suspension system shall be in lower position at the same height (distance between joints and ground is minimum 200 mm). Rods set at the equal height from the ground facilitate mounting the ridger on the tractor.

  • Page 21: Mounting The Ridger On The Tractor

    4.7. Mounting the ridger on the tractor When mounting the ridger on the tractor, perform following activities: disassemble a tool drawbar from lower rods of the tractor three-point suspension system, drive to the machine frame close enough with the tractor, turn off the tractor engine, remove the key from the ignition switch and pull handbrake, install tractor lower rods onto the tool studs and secure with typical cotter pins,...

  • Page 22: Technical Operation

    CAUTION It is not allowed to use the reverse gear of the tractor during work, when the tool is in the working position. The ridger shall be raised easily, without jerks or vibrations. WARNING. All clogging made during operation of the ridger requiring interference in the operation, shall be removed after stopping the tractor, leaving the ridger, turning off the tractor engine and pulling the handbrake.

  • Page 23: Working Parts Exchange

    triangular sign for low-speed vehicles should be uninstalled from the ridger and placed in a dry room, to be protected from being damaged. 5.4. Working parts exchange In the ridger there can happen necessity of exchange of ridges, duckfoot shares, ploughshares or wings of the ridger.

  • Page 24: Lubrication Instruction

    REMEMBER! Work with an inefficient tool, improperly adjusted may lead to serious threats to the operator and other people. Inefficiencies and damages noticed shall be removed without delay. 5.6. Lubrication instruction Basic maintenance activities are keeping lubrication periods and using proper types of grease.

  • Page 25: Disassembly

    CAUTION! When turning, pay attention to “overlapping” of the machine. DISASSEMBLY CAUTION Before starting to disassembly, the ridger shall be disconnected from the tractor. Disassembly of the machine should be performed by people, equipped with protective gloves and previously acquainted with its construction after disconnecting the machine from the tractor and setting on the flat and tough ground.

  • Page 26: Technical Characteristics

    TECHNICAL CHARACTERISTICS Technical data of ridgers of P475 series is listed below. Table 4. Technical characteristics of a mounted ridger Unit of Specification Manufacturer data measure Symbol P 475 P 475/1 P 475/1 Machine type mounted Working width 1.87 3.10 1.87 Working depth 70-100...

  • Page 27: Spare Parts Catalogue

    SPARE PARTS CATALOGUE How to use the catalogue. Spare parts catalogue includes other assemblies of the ridger marked with proper numbers of tables. The catalogue should be used as follows: determine the proper assembly the exchanged part belongs to according to the tables, find the needed part on the assembly table following the reference number from the assembly drawing.
  • Page 28 Table 1. Ridger main frame Position Items quantity in the ridger Catalogue number Figure Part name P 475 / P 475/2 P 475/1 or norm number 8234-475-002-001 Main frame A type Main frame B type 8234-475-002-002 Frame A type Frame B type - 26 -...
  • Page 29 Table 2. Ridger working section Number of pieces in the Pos. KTM symbol or ridger Part name Fig. standard number P 475 P 475/1 Supporting frame of the section welded 8234-475-001-001 Yoke welded 8234-475-001-002 Lever with pivots welded 8234-475-001-003 Lever 8234-475-001-004 Overlay 8234-475-001-005...
  • Page 30 Table 3. Ridger working section with rollers Ilość sztuk w Poz. Symbol KTM lub nr Nazwa części obsypniku Rys. normy P 475/2 Supporting frame of the section 8234-475-003-001 welded Support wheel arm welded 8234-475-003-002 Support wheel welded 8234-475-003-003 Axle of the support wheel 8234-475-003-004 Plastic sleeve 8234-475-001-007...
