REPAIR & REBUILD
BAYCO 'DBA' SERIES DRY
DISCONNECT ADAPTERS
DBAK1-150 .......... Repair kit for 1.5" Buna Dry Disconnect Adapter
DBAK1-200 .......... Repair kit for 2" Buna Dry Disconnect Adapter
DBAK1-300 .......... Repair kit for 3" Buna Dry Disconnect Adapter
DBAK2-150 .......... Repair kit for 1.5" Viton Dry Disconnect Adapter
DBAK2-200 .......... Repair kit for 2" Viton Dry Disconnect Adapter
DBAK2-300 .......... Repair kit for 3" Viton Dry Disconnect Adapter
DBAK3-150 .......... Repair kit for 1.5" PTFE/Silicone Core Dry Disconnect Adapter
DBAK3-200 .......... Repair kit for 2" PTFE/Silicone Core Dry Disconnect Adapter
DBAK4-150 .......... Repair kit for 1.5" EPDM Dry Disconnect Adapter
DBAK4-200 .......... Repair kit for 2" EPDM Dry Disconnect Adapter
DBAK6-150 .......... Repair kit for 1.5" Chemraz/PTFE Dry Disconnect Adapter
DBAK6-200 .......... Repair kit for 2" Chemraz/PTFE Dry Disconnect Adapter
DBAK7-150 .......... Repair kit for 1.5" PTFE/Viton Core Dry Disconnect Adapter
DBAK7-200 .......... Repair kit for 2" PTFE/Viton Core Dry Disconnect Adapter
U S A:
Dixon Bayco USA
Chestertown, Maryland
Phone: 410-778-2000
Fax: 410-778-4702
Toll Free: 800-355-1991
INSTRUCTIONS
Repair kit numbers
For Sales & Service Contact
Dixon Bayco
A DIXON COMPANY
CANADA:
Dixon Bayco Limited
Barrie, Ontario
Phone: 705-436-1125
Fax: 705-436-6251
Toll Free: 800-355-1991
1
40112PA Rev JANUARY 2012
Advertisement
Table of Contents
Related Manuals for Dixon BAYCO DBA Series
Summary of Contents for Dixon BAYCO DBA Series
- Page 1 DBAK7-150 ..Repair kit for 1.5” PTFE/Viton Core Dry Disconnect Adapter DBAK7-200 ..Repair kit for 2” PTFE/Viton Core Dry Disconnect Adapter For Sales & Service Contact Dixon Bayco A DIXON COMPANY U S A: CANADA: Dixon Bayco USA Dixon Bayco Limited...
- Page 2 Tools required for installation and part replacement Vise Large Wrench INSTALLATION CAUTION! SAFETY GLASSES MUST BE WORN DURING REPAIR AND TESTING. CAUTION! ADAPTER END AND PIPE END ARE RESTRAINING A COMPRESSION SPRING. ENSURE THAT YOU HAVE A FIRM GRIP ON THE ADAPTER END BEFORE REMOVING 40112PA Rev JANUARY 2012...
- Page 3 REBUILDING 1. Hold the PIPE END in a vise and use a wrench to loosen the ADAPTER END by griping on the cast lugs. 2. Make sure you have a firm grip on the ADAPTER END and unthread from the PIPE END. 3.
- Page 4 MAKING SURE ALL AIR PRESSURE IS RELEASED MAY RESULT IN SERIOUS INJURY. 8. Remove test plug from the PIPE END. DIXON BAYCO WARRANTY For Warranty Information, please refer to the inside back cover of the latest Dixon Catalogue. 40112PA Rev JANUARY 2012...
- Page 5 Téléphone +44 (0)1772 323529 Fax: 01-81-8354-8197 Fax: +44 (0)1772 314664 E-mail :contactenos@dixonvalve.com.mx E-mail: enquiries@dixoneurope.co.uk www.dixonvalve.com www.dixoneurope.co.uk Asie et Pacifique: Dixon (Asia Pacific) Pty Ltd Wingfield, South Australia Téléphone +61 8 8202 6000 Fax: +61 8 8202 6099 E-mail:enquiries@dixonvalve.com.au www.dixonvalve.com.au 40112PA Rev JANVIER 2012...
- Page 6 Outils demandés pour l’installation et le remplacement des pièces Étau Clé à molette INSTALLATION ATTENTION! DES LUNETTES DE SÉCURITÉS DOIVENT ÊTRE PORTÉES DURANT LES RÉPARATIONS ET LES ESSAIS. ATTENTION! L’EXTRÉMITÉ DE L’ADAPTATEUR ET DU TUYAU RETIENT RESSORT COMPRESSION. ASSUREZ-VOUS RETENIR L’EXTRÉMITÉ DE L’ADAPTATEUR FERMEMENT AVANT DE LE RETIRER.
- Page 7 RECONSTRUCTION 1. Retenez l’extrémité du tuyau dans un étau et utilisez une clé à molette pour desserrer l’extrémité de l’adaptateur en agrippant les oreilles de fixation. 2. Assurez vous de retenir l’extrémité de l’adaptateur fermement et dévissez à partir l’extrémité du tuyau.
- Page 8 CAUSER DE SÉRIEUX ACCIDENTS. 8. Retirez le bouchon d’essai de l’extrémité du tuyau. GARANTIE DIXON Pour plus d’informations complètes sur la garantie, s’il vous plait se référer à la couverture intérieure de la dernière page du dernier catalogue Dixon. 40112PA(fr) Rev JANVIER 2012...
