- Page 1 Quick guide Technical parameters multisys D2-1DI2DO-1 Pulse doubler You can find the instructions for your KBR System English device at our download center. https://www.kbr.de/de/dienstleistungen/ download-center...
- Page 2 Wiring diagram ......................6 Technical data ......................7 KBR Kompensationsanlagenbau GmbH does not accept any liability for any loss or damage resulting from printing errors in or changes to this manual. In addition, KBR Kompensationsanlagenbau GmbH does not accept any liability for any loss or damage caused by defective devices or devices manipulated by the user.
- Page 3 Introduction Introduction Thank you for choosing this KBR quality product. To become familiar with the operation and programming of the device and to use the full range of functions of this high-quality product at all times, you should read this user manual carefully.
- Page 4 Introduction Safety Keys This manual contains instructions that you must follow for your personal safety and to avoid material damage. These instructions are identified by a warning sign or information symbol, depending on the degree of hazard they warn about. DANGEROUS VOLTAGE “Warning”...
- Page 5 Introduction DANGEROUS VOLTAGE The applicable DIN/VDE regulations must be observed during installation! Connection to the mains, commissioning and operation of the device may only be carried out by qualified personnel. Qualified personnel within the meaning of the safety instruc- tions in this manual are persons with electrical engineering training and knowledge of national accident prevention regulations, safety engineering standards and the installa- tion, commissioning and operation of the device.
- Page 6 - Switching repeater for pulse doubling - Integrated power supply - One input - Two outputs - Top-hat rail housing Wiring diagram Pulse generator (EVU meter or KBR-multimess D6-xxx-5 etc.) LED Pulse Pulse output 1 Pulse input Pulse output 2...
- Page 7 Introduction Technical data Input data: Input voltage power supply 100 – 240 V +/- 10% ,DC/50/60 Hz, max. 3,5 VA Power optocoupler Switching level 1-Signal („H“) >10mA to <27mA Switching level 0-Signal („L“) < 2mA Transmission frequency f (ohmic load) 10 Hz grenz Input circuit...
- Page 8 KBR Kompensationsanlagenbau GmbH Am Kiefernschlag 7 T +49 (0) 9122 6373 - 0 www.kbr.de D-91126 Schwabach F +49 (0) 9122 6373 - 83 Germany E info @ kbr.de...
