- Page 1 AHF/SVG-PRO-Panel 7” touch display User manual and technical data Janitza electronics GmbH Vor dem Polstück 6 D-35633 Lahnau Support tel. +49 6441 9642-22 Email: info@janitza.de www.janitza.de...
- Page 2 Nonetheless, we wish to point out that updates of this document are not always possible at the same time as technical refinements are implemented in our products. Please see our website under www.janitza.de for the current version. Please see our website under www.janitza.de for the current version.
-
Page 3: Table Of Contents
7” Touch Display TABLE OF CONTENTS 1. Product notes and user manual 1. 1 Disclaimer 1. 2 Copyright notice 1. 3 Technical changes 1. 4 About this user manual 1. 5 Defective products/disposal 2. Safety 2. 1 Display of warning notices and safety information 2. -
Page 4: Product Notes And User Manual
(AKM) is also applicable. Please pay attention via email at: info@janitza.de. to it! Copyright notice © 2020 - Janitza electronics GmbH - Lahnau. All rights reserved. INFORMATION Any reproduction, processing, distribution or other This user manual describes the 7” touch display and use of this usage information, in whole or in part, is provides information on the operation of the product. -
Page 5: Defective Products/Disposal
INFORMATION Please return defective or damaged products, de- vices, modules or components to Janitza electronics GmbH in accordance with the shipping instructions for air or road freight (complete with accessories). Observe special regulations for devices with built-in... -
Page 6: Safety
7” Touch Display www.janitza.de Safety Hazard levels The chapter on Safety contains information which must be observed to ensure your personal safety Warning and safety information is marked by a and avoid material damage. warning symbol, and the hazard levels are shown... -
Page 7: Product Safety
7” Touch Display Product safety WARNING The product reflects current engineering practice Risk of injury due to electrical voltage! and accepted safety standards, but hazards can Severe bodily injury or death can result! Therefore arise nonetheless. please abide by the following: ·... -
Page 8: Electrically Qualified Personnel
7” Touch Display www.janitza.de Electrically qualified personnel To avoid bodily injury and material damage, only electrically qualified personnel are permitted to work on the devices, components, assemblies, systems and current circuits who have knowledge · the national and international accident prevention regulations, ·... -
Page 9: Product Description
7” Touch Display Product description Product description · Has visible damage. · No longer functions despite an intact power This product is part of a customer-specific com- supply. plete solution. It serves as a user interface and · Was subjected to extended periods of unfavor- operator interface for the configuration and param- able conditions (e.g. -
Page 10: Performance Characteristics
7” Touch Display www.janitza.de Performance characteristics · Touch display for status indicators and parameter settings · Suitable for mounting in the front panel · LED backlight · High resolution TFT color display (1080P resolution) · 1 GHz CPU · 512 MB memory ·... -
Page 11: Mounting
7” Touch Display Mounting Installation location Install the monitor system using the following steps: DANGER · Remove the product from the outer packaging Danger of electric shock! · Separate the monitor unit from the door plate by Electric shocks lead to serious injuries, including loosening the 4 screws death. -
Page 12: Switchboard Cabinet Door Drilling Pattern
7” Touch Display www.janitza.de Switchboard cabinet door drilling pattern To install the monitor system, drill four holes (4 x ø5): Monitor system: Inside of door Faceplate Door plate (all dimensions in mm) The indicator lights and the emergency stop button are... -
Page 13: Wiring Diagram For Connections
7” Touch Display Wiring diagram for connections Port Designation Ethernet communication interface CAN protocol interface RS-485 communication interface, 2-pin connector, left A, right B USB interface Connection to module-monitoring interface (including 485, emergency output, 24 V power supply) via W6... -
Page 14: Technical Data
7” Touch Display www.janitza.de Technical data Technical data and specifications General Display type 7” TFT LCD, color display Resolution 800 x 400 px Dimensions W x D x H: approx. 197 x 134.7 x 19.5 mm Weight approx. 1 kg... - Page 15 7” Touch Display...
- Page 16 Vor dem Polstück 6 D-35633 Lahnau Support tel. +49 6441 9642-22 Email: info@janitza.de info@janitza.de | www.janitza.de Doc. no. 2.100.061.0.c | Date 04/2021 | Subject to technical changes. The current version of the document can be found in the download area at www.janitza.de.
