FullHD Binocular with Display TX-142

Introduction

The Declaration of Conformity for this device is under the Internet link:
www.technaxx.de/ (in bottom bar "Konformitätserklärung"). Before using the
device the first time, please read the user manual carefully.
Service phone No. for technical support: 01805 012643 (14 cent/minute from
German fixed-line and 42 cent/minute from mobile networks).
The support hotline is available Mon-Fri from 9 am to 1 pm & 2 pm to 5 pm
This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capacities, or by persons lacking in
experience or knowledge, unless they are supervised or instructed on the use
of this device by a person responsible for their safety. Children should be
supervised to ensure they do not play with this device.
Do not use the binocular to watch the sun, or your eyes can be hurt. Be
Keep this user manual for future reference or product sharing carefully. Do
the same with the original accessories for this product. In case of warranty,
please contact the dealer or the store where you bought this product.
Enjoy your product * Share your experience and opinion on one of the
Please read this instruction manual carefully before using the
instrument.
®
Technaxx
Free Email: support@technaxx.de
sure to keep it in mind!
well-known internet portals.
Hints for Environment Protection: Packages materials are
raw materials and can be recycled. Do not disposal old
devices or batteries into the domestic waste. Cleaning:
Protect the device from contamination and pollution (use a
clean drapery). Avoid using rough, coarse-grained materials or
solvents/aggressive
accurately. Distributor: Technaxx Deutschland GmbH &
Co.KG, Kruppstr. 105, 60388 Frankfurt a.M., Germany
* User Manual
cleaner.
Wipe
Warranty 2 years
the
cleaned
device
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TX-142 and is the answer not in the manual?

Questions and answers

Neil Hadfield
February 2, 2025

Can I change the battery

1 comments:
Mr. Anderson
February 10, 2025

No, the Technaxx TX-142 has an internal, rechargeable battery that is not mentioned as being replaceable.

This answer is automatically generated

Subscribe to Our Youtube Channel

Summary of Contents for Technaxx TX-142

  • Page 1: Introduction

    Introduction The Declaration of Conformity for this device is under the Internet link: www.technaxx.de/ (in bottom bar “Konformitätserklärung”). Before using the device the first time, please read the user manual carefully. Service phone No. for technical support: 01805 012643 (14 cent/minute from German fixed-line and 42 cent/minute from mobile networks).
  • Page 2: Table Of Contents

    Contents Introduction ..................1 Features .................... 2 Product overview ................3 Before first use (charging) ..............4 First use .................... 4 Using in classic mode (magnification 12x) ........4 Using in digital mode (photo and video) ........4 1. Insert SD card ................ 4 2.
  • Page 3: Product Overview

    Product overview Reset Display Menu Mode Down Focus Wheel OK / (Video/Photo) On/Off button (Power) MiniUSB connector Red LED (Charging) Blue LED (Working) MicroSD card slot Diopter Adjustment...
  • Page 4: Before First Use (Charging)

    Please charge the binocular by using a common USB power adapter* (DC 5V/1A) (*not included). After plugging in the USB cable, the TX-142 powers On. For charging you can turn it Off. While charging the charging indicator LED (6) left to the MiniUSB port will turn RED.
  • Page 5: Turn On The Binocular

    2. Turn on the Binocular Press and hold the Power button (5) until the display shows: Welcome, the binoculars are ready to take photos or videos. Important: Setting language and time! After turning on the binocular for the first time you should change the language (default is English) and time.
  • Page 6: Video Settings

    Video settings Turn on the binoculars, and select the video mode. Press the Menu button (2) and then use the Up (9) or Down (10) buttons to navigate the menu. Press the OK button (11) to enter the submenus and confirm your choices. To exit settings, press the Menu button (2) once or twice until you return to the normal screen: 1080FHD P30 Resolution...
  • Page 7: Photo Settings

    Photo settings Turn on the binoculars, and select the photo mode. Press the Menu button (2) and then use the "Up" (9) or "Down" (10) buttons to navigate the menu. Press the OK button (11) to enter the submenus and confirm your choices. To exit settings, press the Menu button (2) once or twice until you return to the normal screen: Photo Menu Sub Menu Photo Menu...
  • Page 8: Replay Settings

    Language English, French, Spanish, Portuguese, German, Italian, Chinese, Russian, Norwegian, Czech, Dutch, Polish Frequency 50Hz 60Hz Screensavers Off; 1 Minute; 3 Minutes; 5 Minutes; 10 Minutes Format (MicroSD card) Cancel Default Setting (Device) Cancel Version TX-142 Digital Binocular Camera -Vx.x...
  • Page 9: Low Light Amplification (Night Vision)

    Low light amplification (night vision) This function of the TX-142 is no real night vision, because the device has no infrared LED. Which makes a light source (at least 0.01 lux) necessary. The device uses the sensor and chipset to the improve the photo image by setting ISO and the exposure value.
  • Page 10: Reset

    Chinese, Russian, Norwegian, Czech, Dutch, Polish Material Aluminum alloy+ ABS, PVC –7°C up to +40°C Working temperature Weight & Dimensions / (L) 14.5 x (W) 11.5 x (H) 5.5cm FullHD Binocular with Display TX-142, 1x Mini USB Package contents cable,1x Neckstrap, 1x Cloth, User manual...
  • Page 11: Care And Maintenance

    Care and maintenance ● ● Clean the product only with a dry or slightly damp, lint-free cloth. Do not ● use abrasive cleaners to clean the unit. Digital binocular is a high-precision optical instrument, so in order to avoid damage, please avoid the following practice: ●...
