Operation & Maintenance Manual
FRED ECO
READ AND SAVE THESE INSTRUCTIONS
Visit our Website for more information on this product
www.diversitech.ca
1200 55
th
Avenue, Montreal, Quebec H8T 3J8
Tel: 1.800.361.3733 | Fax: 1.514.631.9480 | info@diversitech.ca

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FRED ECO and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for DIVERSITECH FRED ECO

  • Page 1 Operation & Maintenance Manual FRED ECO READ AND SAVE THESE INSTRUCTIONS Visit our Website for more information on this product www.diversitech.ca 1200 55 Avenue, Montreal, Quebec H8T 3J8 Tel: 1.800.361.3733 | Fax: 1.514.631.9480 | info@diversitech.ca...
  • Page 2: Table Of Contents

    Table of Contents SECTION 1 – SAFETY PRECAUTIONS OF FUME & DUST EXTRACTION/COLLECTION ...............................3 1.1 Symbols ..........................................................3 1.2 User Responsibility ....................................................3 1.3 Fume Extraction Hazards ..................................................3 1.4 Dust Collection Hazards ..................................................4 1.5 Safety Stickers ......................................................4 1.6 Sound Levels .......................................................4 SECTION 2 – SPECIFICATIONS ........................................................4 2.1 Diagram &...
  • Page 3: Section 1 - Safety Precautions Of Fume & Dust Extraction/Collection

    SECTION 1 - SAFETY PRECAUTIONS OF FUME & DUST EXTRACTION/COLLECTION This manual contains specific cautionary statements related to worker safety. To protect yourself and READ others, read this manual thoroughly and follow as directed BEFORE before use. Not all hazards of fume & dust control are listed in this manual, and no hazards related to welding, cutting, grinding, painting, deburring or other applications are listed.
  • Page 4: Dust Collection Hazards

    Never use or install equipment where the potential for combustible fumes or dusts are present without a fire/explosion protection system. • If you are unsure if the product you purchased is correct for your application, call Diversitech at 1-800-361-3733. 1.5 Safety Stickers •...
  • Page 5: Dimensions

    2.4 Filter Specifications Filter Description Stage Part # Filter Area (sq. ft.) Reusable Efficiency Nanofiber Filter Primary S-ECO2-26NF MERV 15 Spunbond Poly Filter Primary S-ECO2-26PT MERV 11 For information on inspecting and cleaning filter, or purchasing replacement filters, contact Diversitech at 1-800-361-3733.
  • Page 6: Section 3 - Pre-Installation

    SECTION 3 - PRE-INSTALLATION 3.1 To Setup or Install Safely • Do not place unit near flammables or combustible surface. • Refer to SECTION 2: Specifications, to know the electrical requirements of the unit you are installing and ensure adequate input power that is properly sized, rated, and protected. •...
  • Page 7: Section 4 - Operation

    • Do not use product without first confirming if a Spark Arrestor is required and installed for the type of dust, or fumes you are extracting and/or collection. If you are unsure, call a Diversitech representative at 1-800-361-3733. 4.2 Controls •...
  • Page 8: Principles Of Operation

    4.4 Principles of Operation This product is designed to capture and clean smoke and dust from medium & heavy duty welding, soldering, and grinding applications. When operating, air is drawn in to the nozzle, passes through the 6” diameter hose, then through the air cleaner’s filtration system, and is exhausted. This product consists of four basic components: Capture Arm(s) A blower...
  • Page 9: Section 5 - Maintenance & Troubleshooting

    SECTION 5 - MAINTENANCE & TROUBLESHOOTING 5.1 To Maintain this Product Safely Read and understand SECTION 1: Safety Precautions and SECTION 4: Operation before maintenance. • • Do not breathe the dust collected from product while changing/cleaning filters or performing maintenance on this product.
  • Page 10: Routine Maintenance Schedule

    5.3 Routine Maintenance Schedule The manufacturer recommends the following routine maintenance based on light-duty use in normal operating conditions. Service more frequently if the unit is used in severe conditions. Frecuency Manual Reference Pre-Use • Perform pre-use inspection to ensure operating correctly. As Required Replace Filter Every (12) months Inspect Basic Components...
  • Page 11: Troubleshooting Procedure

    5.5 Troubleshooting Procedure Turn Unit Call for Service Check Leads at Motor 1(800)361-3733 INTERMITTENTLY Input Power Operating support@diversitech.ca Source Motor Air Flow Operating Restricted Check/clean Hood inlet & Capture tubes Check Leads at Replace Air Flow Unit Filter Restricted Air Flow...
  • Page 12: Appendix 1A - Electrical Diagram Manual [120 Vac] Single Phase Power

    APPENDIX 1A - ELECTRICAL DIAGRAM MANUAL [120 VAC] Single-Phase Power ELECTRIC Disconnect power before performing any maintenance on unit, including filter inspection. The input power to this unit is high voltage, and touching any live SHOCK electrical parts can cause fatal shocks or severe burns. Do not touch live electrical HAZARD parts.
  • Page 13: Appendix 1B - Electrical Diagram Manual [230/460/575V] 3-Phase Power

    APPENDIX 1B - ELECTRICAL DIAGRAM MANUAL [230/460/575V] 3-Phase Power Disconnect power before performing any maintenance on unit, including filter ELECTRIC inspection. The input power to this unit is high voltage, and touching any live SHOCK electrical parts can cause fatal shocks or severe burns. Do not touch live electrical HAZARD parts.
  • Page 14: Appendix 2 - Maintenance Record

    APPENDIX 2 - MAINTENANCE RECORD Diversitech Inc. authorizes this page to be photocopied or otherwise reproduced as needed for management of maintenance records. MANUFACTURER: DIVERSITECH INC. MODEL N° FRED-ECO II SERIAL N° SERVICE LOCATION: CONTROL N° Date Description of Service...
  • Page 15: Appendix 3 - Arm-To-Blower Direct Installation

    APPENDIX 3 - ARM-TO-BLOWER DIRECT INSTALLATION 3.1 Selecting a Location STEP 1. Selecting a Location. • Read and understand SECTION 1: Safety Precautions. Mount sufficiently close to an appropriate power source as outlined in Section 3.5: Electrical Options • • Near the operator, and within the operating range of the unit.
  • Page 16 3.2 Attach Swivel Base to Blower Assembly STEP 2. Attach capture arm to swivel base. • Mount Swivel Base to Motor Blower Assembly. • Tighten all Bolts (8) with Washers (8) • Toque each bolt to 23 N m Hardware Quantity Motor Blower Assembly Swivel Base...
  • Page 17 3.5 Attach Filter to Blower Assembly STEP 5. Attach Filter to Blower Assembly Quantity Hardware • Place Filter in final location. Motor Blower Assembly 3/8” Threaded Rod, 91 cm Length • Install the Connecting Rods, ensuring the Filter is not damaged during installation. 3/8”...
  • Page 18: Appendix 4 - Arm-To-Wall Direct Installation

    3.7 Install Flex Hose STEP 7. Install Flex Hose. • Mount Flex Hose to Swivel Base and capture Arm. • Tighten Both Hose Clamps. Hardware Quantity Fred-Eco Assembly Hose Clamps Flex Hose APPENDIX 4 - ARM-TO-WALL DIRECT INSTALLATION 4.1 Selecting a Location STEP 1.
  • Page 19 4.2 Attach Swivel Base to Blower Assembly STEP 2. Attach capture arm to swivel base. • Mount Swivel Base to Motor Blower Assembly. • Tighten all Bolts (8) with Washers (8) • Toque each bolt to 23 N m Hardware Quantity Motor Blower Assembly Swivel Base...
  • Page 20 4.4 Attach Filter to Blower Assembly STEP 4. Attach Filter to Blower Assembly Quantity Hardware • Place Filter in final location. Motor Blower Assembly 3/8” Threaded Rod, 91 cm Length • Install the Connecting Rods, ensuring the Filter is not damaged during installation. 3/8”...
  • Page 21 4.6 Install Flex Hose STEP 6. Attach capture arm to swivel base. • Mount Flex Hose to Swivel Base and Capture Arm. • Tighten Both Hose Clamps. Hardware Quantity Fred-Eco Assembly Remote Mount Bracket Flex Hose Hose Clamps 4.7 Attach swivel base to remote mount bracket STEP 7.
  • Page 22 4.9 Attach Capture Arm to Swivel Base (J-Bracket) STEP 9. Attach Capture Arm to Swivel Base. (J-Bracket) Quantity Hardware Swivel Base with J-Bracket • Insert J-Bracket between Capture Arm Mounting Bracket. Capture Arm Assembly • Thread Bolts (3) with Washers (3) through Mounting Bracket and J-Bracket. 3/8’’...
  • Page 23: Appendix 5 - Appendix 5 - Parts

    APPENDIX 5 - PARTS LIST DESCRIPTION ITEM NUMBER QUANTITY Body, Central BTO-ECO2-06 Blower Assembly S-ECO2-1004 standard Body Mounting Bracket S-ECO2-0007 optional Filter, Nano-Fiber, 99.99% efficient @ 0.5 microns S-ECO2-26NF standard Filter Compression Kit, Blower Side Bracket S-XA-FCB-01 Filter Compression Kit, Blower Side Knob S-XA-FCB-02 Filter Compression Kit, Connecting Rod S-XA-FCB-04...
  • Page 24: Appendix 6 - Sample Safety Stickers

    APPENDIX 6 - SAMPLE SAFETY STICKERS The machine is marked with a wet filtration safety sticker to remind the operator of safe working practices: The machine is marked with safety stickers in appropriate places to remind the operator of safe working practices.
  • Page 25: Notes

    NOTES...
  • Page 26 NOTES...
  • Page 27 NOTES...
  • Page 28: Limited Equipment Warranty

    Diversitech Inc. will repair or replace, at our option, any defective parts which fail during the warranty period. This warranty is limited to replacement parts ONLY, and does not cover personal liability, property loss, normal wear;...
