COVE
by
COPY THE MODEL NUMBER FOR YOU RECORDS HERE #
Please visit us on YouTube and view our shower door installation videos.
One may be available for your installation. www.youtube.com/foremostgroups.
Toll Free Customer Assistance
Monday-Friday, 9:00 a.m. To 5:30 p.m. EST
6241 Northwind Parkway, Hobart, IN USA 46342
www.ForemostBath.com
2021 Foremost® Groups, Inc.
C
SLIDING
SHOWER & TUB DOOR
READ THE INSTRUCTIONS CAREFULLY
Familiarize yourself with all the parts as shown in the exploded
view. The exploded view will also provide a helpful reference
when relating to the location of the various parts and how
they are mounted.
1-888-620-3667
1-888-256-7551
5970 Chedworth Way, Unit B, Mississauga, Ontario, Canada L5R 4G5
www.ForemostCanada.com
US Customers
Canada Customers
Advertisement
Related Manuals for Foremost COVE
Summary of Contents for Foremost COVE
- Page 1 1-888-620-3667 Toll Free Customer Assistance US Customers 1-888-256-7551 Monday-Friday, 9:00 a.m. To 5:30 p.m. EST Canada Customers 6241 Northwind Parkway, Hobart, IN USA 46342 5970 Chedworth Way, Unit B, Mississauga, Ontario, Canada L5R 4G5 www.ForemostBath.com www.ForemostCanada.com 2021 Foremost® Groups, Inc.
- Page 2 1 1/2” Pan Head Screw 1 1/2” Pan Head Screw 3/8” Pan Head Screw - 1 -...
-
Page 3: Part List
PART LIST 1 1/2” PAN HEAD SCREW (6pcs) 3/8” PAN HEAD SCREW (2pcs) WARNING: Safety glass should alway be worn when working with tempered glass. RECOMMENDED TOOLS 1/8" (3mm) 1/4" (6mm) - 2 -... - Page 4 INSTALLATION PROCEDURE / STEP 1 Attach rollers to hanger clips on both panels. Rollers should be mounted so that the head of the mounting screw is on the same side of the panel as the screw head set into the hanger clip (see inset drawing).
- Page 5 INSTALLATION PROCEDURE / STEP 2 Measure opening on bottom and cut bottom track (2) 1/8" shorter than opening. INSTALLATION PROCEDURE / STEP 3 & STEP 4 Place wall jamb down over bottom track so that the back of the jamb is between the bottom track and the wall.
- Page 6 INSTALLATION PROCEDURE / STEP 5 Run a thin bead of silicone caulk down the entire length of both bottom ledges on the bottom track. Place the bottom track into position and press down firmly along the length of the track. 1 1/2"...
- Page 7 INSTALLATION PROCEDURE / STEP 8 / STEP 9 / STEP 10 Use 1 1/2" pan head screws to anchor wall bumper and bumper guide into center hole on each side. 1 1/2" PAN HEAD SCREW Measure opening at top of wall jamb, cut top track (1) 1/16"...
- Page 8 INSTALLATION PROCEDURE / STEP 12 Install inner door panel by lifting up & into top track (Do not lift by towel bar). - 7 -...
- Page 9 INSTALLATION PROCEDURE / STEP 13 / STEP 14 Install towel bars (5). Position panel guide in center of bottom track. Drill two 1/8" holes through screw holes in guide and into bottom track. Position panels in guide as shown in inset drawing and attach guide to bottom track using 3/8"...
- Page 10 INSTALLATION PROCEDURE / STEP 15 Install safe slider clip (9). To install safe slide clip, put install bar into clip and lift onto clip hanger pull down leaving clip in place. FINAL STEP: Caulk both sides of the shower door frame to seal. Keep the entire area dry for a minimum of 24 hours.
- Page 11 WARRANTY INFORMATION PLEASE DO NOT DISCARD Thank you for your purchase of a shower door from Foremost® Groups, Inc. In order to be eligible for product warranty, please register your door on our website within two (2) weeks of installation.
