- Page 1 USER’S GUIDE DESIGN CATEGORY: According to European directive 2013/53/UE DY CAT 48...
- Page 2 This page is intentionally left blank. This page is intentionally left blank. This page is intentionally left blank. DY CAT 48...
-
Page 3: Table Of Contents
Index GENERAL SPECIFICATIONS ......................6 Design Category ............................. 6 Certification ..............................7 Hull Identification ............................7 Building Plate ..............................7 Degree of Danger............................8 TECHNICAL SPECIFICATIONS ...................... 9 Technical data ..............................9 Stability ................................ 10 ELECTRICAL SYSTEM ........................ 11 III. Safety and use instructions for the electrical system .................. - Page 4 Manouver Bar .............................. 35 Emergency Tiller ............................35 NAVIGATION .......................... 36 Before leaving the dock ..........................36 XII. PREVENTION OF FALLS AND MEANS OF REBOARDING ............. 39 XIII. ENVIRONMENTAL PROTECTION AND SECURITY ............... 40 XIV. SECURITY WEAPONS ....................... 40 XV. HANDLING, TRANSPORTATION, DRY SETTING ................41 XVI.
- Page 5 INTRODUCTION DUFOUR CATAMARANS is pleased to present this manual that will allow you to learn more about your boat. This manual has been developed to help you use your boat safely and with pleasure. It contains details about the boat, the equipment supplied or installed and its systems, as well as the information about their use.
-
Page 6: General Specifications
This ability to navigate also depends on the crew's skills, physical abilities, boat maintenance and armament. So be very careful before going to sea. DUFOUR CATAMARANS can not guarantee the perfect working of the ship in exceptional sea conditions (violent storm, hurricane, cyclone, whirlwind, ...) REMINDER OF DESIGN CATEGORY... -
Page 7: Certification
Certification DUFOUR CATAMARANS has chosen the Institute for the Certification and Standardization in the Nautisme as notified body to check the conformity of your boat with the ENAVE – Ente Navale Europeo S.r.l., according to the module B. Hull Identification... -
Page 8: Degree Of Danger
Max Load Reccomended : recommended by the manufacturer including the mass of all persons on board, provisions and personal effects, all equipment not included in the light weight of the boat excluding the contents of the tanks. WARNING When loading the boat, never exceed the maximum recommended load. Always load the boat carefully and distribute the loads appropriately to maintain the theoretical attitude (approximately horizontal). -
Page 9: Technical Specifications
TECHNICAL SPECIFICATIONS Technical data DUFOUR CATAMARAN 48’ Model: Builder JJL CATAMARANS, via monda 128 Forlì (FC), Italy Architecture: Umberto Felci Interior Design DUFOUR Design Design Category Register Number CE/2406 CIN Number IT-JJL_________ Primary means of propulsion Sails Length overall* with bowsprit 14.70 m... -
Page 10: Stability
Lmax: maximum length of the boat including normally fixed parts such as davits, balconies, etc… : maximum length of the vessel including the structural parts and integral part of the boat and excluding the removable parts. Bmax: width of the boat measured between the outermost parts and which may include removable parts such as strakes, railings, etc ... -
Page 11: Electrical System
III. ELECTRICAL SYSTEM Safety and use instructions for the electrical system WARNING • Risk of fire or explosion can result from improper use of DC and / or AC systems. Always: • Check the condition of the batteries (charge and electrolyte level) and the charging system before going to sea. -
Page 12: Batteries
Batteries The battery bank consists of a 420 Ah service battery as standard (there are 3 batteries of 140 Ah each in portside engine room) and a 105 Ah battery for starting the engine (one in each after cabin, under the bed). The bank of batteries is located on the left after opening the engine room hatch. As a option, instead of AGM batteries is possible to have two GEL batteries for services of the boat. -
Page 13: Fans
ATTENTION ! • When installing new electrical appliances, make sure that the overall consumption of these appliances is in keeping with the capacity of your batteries. • Always disconnect the - terminal of the battery before the + terminal. • Never put the two terminals of a battery into contact with conductive objects (tools, etc ...) •... - Page 14 Use electrical appliances with double insulation or grounding. A differential circuit breaker (DDR) test should be performed monthly if possible. DANGER ! Your boat is delivered without a boat/dock power cable and without a plug on the dock terminal. The cable should be provided for outdoor use. Its section must be adapted according to its length and the power of the main circuit breaker (see electrical diagram).
-
Page 15: Generator
Generator As an option, on the boat can be installed a Generator of 12 kW of power. The generator is located in the starboard engine room. Its function is to re-supply the batteries via the chargers and supply 220 V electricity on board. STARTING OPERATION After having turned ON the cut-outs located in the starboard engine room, the generator can be turned on either on the generator itself or using its control located in dinette near the charter table. - Page 16 2. State of cooling water. The external expansion tank should be filled up to 1/3 of the maximum in a cold state. It is very important that a large expansion area remains above the cooling water level. 3. Check if sea cock for cooling water intake is open.For safety reasons, the sea cock must be closed after the generator has been switched off.
-
Page 17: Gas System
GAS SYSTEM The hatch on deck leftside of sliding door has been designed to store two gas tanks (see gas plan). The circuits opening / closing valves are located in the forniture under the stove unit. Gas tank isn’t supplied with the boat Generalities Operating pressure: 30 mbar (see indication on gas box label and regulator valve) A gas-powered appliance uses the oxygen and releases combustion products. -
Page 18: Operation Of Gas System
Valves attached to empty bottles must be closed and disconnected. Protective caps, covers or caps must be kept in place. The reserve gas tanks shall be in lodgings or boxes for LPG cylinders with an outward ventilation circuit or stored outside the vessel, protected from inclement weather and mechanical damage and from escaping gases to evacuate only towards the outside of the boat LPG bottle chests must not be used for the storage of any other material... -
Page 19: System Check
System Check The LPG system should be leak tested before each use as follows: Close the valve of the device, open the valve of the LPG cylinder, let the gauge pressure stabilize, close the valve of the LPG cylinder, observe the pressure indicated by the manometer located near the bottle for three minutes. -
Page 20: Security Warnings
Security Warnings WARNING • Never leave the vessel unattended when open-flame appliances are operating • Do not smoke or use a naked flame while replacing LPG cylinders. Close the empty bottle valve before disconnecting to replace it. Ventilate the compartment housing the bottle when replacing it. -
Page 21: Liquid Systems
LIQUID SYSTEMS Bilge System Two electric pumps are under the floorboard of each hull, in the portside hull under the stairs and in the starboard hull under the floor of pulman cabin. Other two electric pumps are provided in the two engine rooms near the bulkhead (see bilge plan). -
Page 22: Fresh Water System
Fresh Water System The boat standard features include three 230 l tanks. To prevent any handling mistake, never fill the water and fuel tanks at the same time. One front filling cap allows the tanks to be filled up (see deck plan). - Page 23 How manage the valves: ATTENTION ! Before using fresh water terminal sas sinks, shower mixers, shower deck or washdown system make sure all the valve of the line till terminal are open All the valves are ball valve type - OPEN position: lever in the direction of the valve body, - CLOSED position: lever perpendicular to the valve body.
-
Page 24: Operating Wc
Operating WC The electric toilets are rinsed with sea water. The sea water electric pump, its filter and the supply valve are located as shown in black water plan. To operate the toilet: One of the switches next to the toilets makes possible a water intake cycle and a water outlet cycle. The second switch makes possible to carry out a rinse cycle. - Page 25 The discharge valve can be sealed in the closed position by means of a padlock. Provide a tank cleaning with a disinfectant and biodegradable product once a season. Leave the system empty if the ship is parked in negative temperatures WARNING Use the suction systems in marinas to empty your holding tank.
-
Page 26: Sea Water System
Sea Water System The smaller sink in galley works only with sea water. To use it, open the ball valve operated manually (see thru-hull fitting plan) and activate the Sea Water Pump on control panel. DY CAT 48... -
Page 27: Prevent Flooding
PREVENT FLOODING To avoid the risk of flooding of the boat: Check the closing of the portholes and deck hatches or any other openings allowing flooding before each departure in navigation When navigating, close all valves when not in use, with the exception of engine water intakes. ◼... -
Page 28: Fire Fighting System
VII. FIRE FIGHTING SYSTEM Fire extinguishers are subject to national regulations and are not supplied with the boat (except in the engine rooms). However, when in service, this boat shall be equipped with portable extinguishers with the following extinguishing capabilities and installed at the following locations (see fire fighting plan): N °... -
Page 29: Safety Advices
Safety Advices ATTENTION ! It is the responsibility of the owner/chief of the Board: • Check the fire fighting equipment according to the manufacturer's requirements and the regulations of your country. • Replace the fire fighting equipment if it is outdated or unloaded, by extinguishing devices of equal or greater capacity. -
Page 30: Engine Propulsion
VIII. ENGINE PROPULSION You have access to the engines through the after cockpit hatches. ATTENTION ! Stop the engines before opening the hatches. In case you have to intervene when the engines are running: • Stay away from belts and mobile parts. •... -
Page 31: Starting The Engine
Starting the engine Put the handle in neutral before starting the engine to prevent movement of the vessel and/or the rotation of the propeller. A brief inspection of the propeller attachment during subsequent watering can be carried out. A malfunction of the propeller generates vibrations. If using the anodes, they must be made of zinc. - Page 32 The following actions must be taken before the system is started: 1 Complete calibration 2 Start the MDI display(s) 3 Fault code checks Carry out the following before start: 1 Open the fuel tap 2 Open the seawater valve 3 Turn the main switches on IMPORTANT! Never switch off the current at the main switch when the engine is running.
-
Page 33: Wintering
Wintering Carefully read the operating instructions for the engine that accompanies the boat and the wintering instruction. In the absence of details, proceed as follows: -Close the motor water inlet valve, -Unplug the hose from the engine inlet valve, -Drain the sea water circuit, -Immerse the hose in a permanent liquid -25 °, -Turn the engine until the liquid is released by the exhaust, -Reconnect the hose to the valve at the end of the operation,... -
Page 34: Fuel System
FUEL SYSTEM The boat is fitted with two tanks. Each of them is filled separately. Check the fuel gauge of each tank board. To switch from one tank to the other, press the "Port Fuel" button or “Stbd on the electrical Fuel”... -
Page 35: Steering System
STEERING SYSTEM The steering system is an essential element for the safety and comfort of your ship. Manouver Bar The DY CAT 48 is equipped with a wheel with wires system and chains as well as a spare bar. The main component of the systems is located in the starboard engine room. -
Page 36: Navigation
NAVIGATION Before leaving the dock Close all the hull portholes (safety hatches included), covers, deck hatches and windscreen panels. Unlock all the doors and chests, then check that the bilges are empty of water. Check that the hatch of the raft is unlocked. Open the diesel valves and the seawater plugs Fill: •... - Page 37 WARNING In all situations, adjust the speed of your boat to the surrounding conditions and keep a safe margin. Pay special attention: ● To the state of the sea, to the currents, to the force of the wind. ● To traffic ●...
- Page 38 Two stairs, one on the starboard and the other on the port side, lead you from the cockpit to the steering wheel on the flying bridge. While sailing, pay attention to the possible movements of the boat when using the stairs. WARNING Some area of deck and fly are inaccessible during navigation.
-
Page 39: Prevention Of Falls And Means Of Reboarding
XII. PREVENTION OF FALLS AND MEANS OF REBOARDING When navigating, it is recommended to move only to areas of the bridge provided for this purpose. These areas (sidedecks, cockpit, roof, side seats...) are equipped with anti-skid or teak flooring as per option, allowing safe travel. -
Page 40: Environmental Protection And Security
XIII. ENVIRONMENTAL PROTECTION AND SECURITY We invite you to keep abreast of local environmental regulations, and to comply with international regulations against pollution in the marine Environment (MARPOL) and codes of good practice. Do not unload the toilets or the contents of the retention tanks near the coasts or in prohibited areas and use the port or marina pumping systems to empty the retention vessels before leaving the port. -
Page 41: Handling, Transportation, Dry Setting
HANDLING, TRANSPORTATION, DRY SETTING When haulage the boat, make sure that the belts are correctly positioned and that they are not worn on the propeller, the sail-drive or a fragile probe. The gantry cranes will be wide enough or equipped with spacers so as not to exert on the strake of excessive transverse efforts. -
Page 42: Anchoring
Anchoring ATTENTION ! • Before you anchor, check the type of the sea bed, the depth of water and the strength of the stream, the space you have from other boats already anchored • During anchoring, when the chain is lowered, it is advisable to move back slowly to help the chain lay out on the sea bed with the bow head towards the wind direction •... -
Page 43: Lifting The Anchor
Lifting the anchor Raise the anchoring slowly, checking that the anchor is placed correctly in its davit. When the anchor is close to the davit, check that the tip moves into the davit entry roller in the right direction. Lock the chain with the hoist provided. The circuit breaker is triggered if there is too much effort applied to the windlass;... - Page 44 This page is intentionally left blank. This page is intentionally left blank. This page is intentionally left blank. DY CAT 48...
-
Page 45: General Plan
1. General plan DY CAT 48... - Page 46 DY CAT 48...
-
Page 47: Deck Plan
2. Deck Plan Ref. Description Fuel Cap DN 50 Fresh Water Cap DN 38 Black Water Dock DN 50 (1 each Black Water Tank) Anchor ** Bollard Life Raft ** Fuel Manual Stop Handle Fire Manual Handle for activating fire-estinguisher Manual Pump Windows imperatively Closed in NAVIGATION Emergency ladder **... - Page 48 DY CAT 48...
-
Page 49: Fly Plan
3. Fly Plan Ref. Description Quantity MAIN TRACK Standard Track 31 x 21 4 m End fitting with double sheave and becket Car L 190, stand up joint for 90 mm block, 2 double sheave OPF foot block 50 Clutch CAM611 MAIN CAR CONTROL WINCH Winch ST –... - Page 50 DY CAT 48...
- Page 51 DY CAT 48...
-
Page 52: Sail Plan
4. Sail Plan DY CAT 48... - Page 53 Sail Area Upwind 120 m² Main Sail Area 72 m² Furling Jib 48 m² Code 0 * 90 m² Gennaker * 110 m² Optional DY CAT 48...
-
Page 54: Plan Of Halyards And Tapping
5. Plan of halyards and tapping MAIN SAIL CLEW MAIN SAIL SHEET GENNAKER HALYARD REEF1 REEF2 JIB HALYARD JIB SHEET TACK MAIN SAIL HALYARD FURLING DY CAT 48... -
Page 55: Plan 220 V
6. Plan 220 V DY CAT 48... - Page 56 DY CAT 48...
- Page 57 DY CAT 48...
- Page 58 DY CAT 48...
- Page 59 DY CAT 48...
-
Page 60: Plan Of Electrical Loads And Power
7. Plan of electrical loads and power DY CAT 48... - Page 61 DY CAT 48...
- Page 62 DY CAT 48...
-
Page 63: Electric Panel 12 V
8. Electric panel 12 V DY CAT 48... -
Page 64: Plan Of Plugs 12 V
9. Plan of plugs 12 V The components marked with * are options DY CAT 48... -
Page 65: Electric Plan 12 V
10. Electric plan 12 V DY CAT 48... - Page 66 DY CAT 48...
- Page 67 DY CAT 48...
-
Page 68: Electric Plan 220 V
11. Electric plan 220 V DY CAT 48... -
Page 69: Fuse Location Plan
12. Fuse location plan There are three blocs of fuses in the boat that control three different areas: one just right side to stairs near the flames for utilities in portside hull, one near the chart table for dinette/fly utilities, and one in the forniture of starboard forward cabin for utilities of starboard hull. - Page 70 Ref. Description Fuse DY CAT 48...
-
Page 71: Steering System Plan
13. Steering system plan Steering pump on wheel DY CAT 48... - Page 72 Actuator and autopilot pump with by-pass Steering by-pass for automatic pilot DY CAT 48...
-
Page 73: Gas Plan & Sea Water System
14. Gas plan & Sea water system Ref. Description Gas Tank 3 kg (NOT SUPPLY WITH THE BOAT) Hand operated valve (NOT SUPPLY WITH THE BOAT) Seacock Filter Sea Water pump Barbeque Green Sea water line Brown Copper line Orange Flexible Gas line DY CAT 48... - Page 74 DY CAT 48...
-
Page 75: Evacuation Plan
15. Evacuation plan Symbol Description Fire estinguisher for engine room 6 kg Fire estinguisher movable for cabins 1 kg ** Manual cable to deck for activation Escape exit Not supply with boat DY CAT 48... - Page 76 DY CAT 48...
-
Page 77: Fresh Water System Plan
16. Fresh water system plan Symbol Description Washdown system Ball valve hand operated Open Vent Double stack Pump Tee Raccord Non return Valve Cross Raccord Filter Collector DY CAT 48... - Page 78 DY CAT 48...
-
Page 79: Bilge System Plan
17. Bilge system plan Symbol Description Non return valve 1” on thru-hull fittings Sump for Manual Pump Electric bilge pump Manual Pump Movable hose for connection between manual pump and sumps Floating DY CAT 48... - Page 80 DY CAT 48...
-
Page 81: Thru-Hull Fittings Plan
18. Thru-hull fittings plan Ref. Description Engine Exhaust exit DN 60 Automatic Bilge exit 1” Manual Bilge exit 1” Grey Water Exit 1” Black Water Exit 1”1/2 Sea Water In ¾” Grey Water Exit 1”1/4 DY CAT 48... - Page 82 DY CAT 48...
-
Page 83: Mechanical Plan
19. Mechanical plan Ref. Description Main Engine Volvo D2-60 Engine Bed Sail Drive Anode Propeller Isolation Foam Anti-siphon elbow Waterlock Exhaust Exit Ventilation grids IN Ventilation grids OUT Starter Battery Circuit breaker Load Distributor Engine Handle Engine instruments DY CAT 48... - Page 84 DY CAT 48...
- Page 85 DY CAT 48...
-
Page 86: Fuel Plan
20. Fuel plan Ref. Description Fuel Cap DN 50 Fuel Tank 450 lt Hand Operated Valve to Stop Fuel Supply Fuel Stop on vent line Fuel Filter Vent Fuel Box Stop Handle to Stop Fuel Supply (For Emergency) DY CAT 48... -
Page 87: Black Water Plan
21. Black water plan Symbol Description Black water exit 1”1/2 with hand operated valve Sea water inlet ¾” with hand operated valve Sea water filter Siphon break Sea water pump Black water pump Non return valve Black water tank 50 lt Active carbon filter Vent Black water dock cap on deck... - Page 88 DY CAT 48...
-
Page 89: Navigation Lights
22. Navigation lights Option A When Sailing under sails When sailing with engine When boat is anchored DY CAT 48... - Page 90 Option B When Sailing under sails When sailing with engine When boat is anchored DY CAT 48...
- Page 91 NOTES ………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………… ………………………………………………………………………………………………………………… …………………………………………………………………………………………………………………...
