Installation, Operation and
Conforto Boiler
B*C - 3 to 9 sections boiler
*Designates Brand Name
INSTALLATIONS MUST MEET ALL LOCAL AND FEDERAL
CODES THAT MAY DIFFER FROM THIS MANUAL
Please read the manual in its entirety before beginning installation.
This manual must be kept with the boiler for future reference.
Manufactured by:
GRANBY FURNACES INC.
PO Box 637
12118 Hwy 209
Parrsboro Nova Scotia Canada, B0M 1S0
Distributed by:
GRANBY HEATING PRODUCTS, LLC.
67 Target Industrial Circle
Bangor, ME 04401
www.granbyindustries.com
Service Manual
SERIES
2021-3-1
Three section boiler shown
G2020-E6 - Rev. C
Advertisement
Table of Contents
Related Manuals for Granby Conforto Series
Summary of Contents for Granby Conforto Series
- Page 1 This manual must be kept with the boiler for future reference. Manufactured by: GRANBY FURNACES INC. PO Box 637 12118 Hwy 209 Parrsboro Nova Scotia Canada, B0M 1S0 Distributed by: GRANBY HEATING PRODUCTS, LLC. 67 Target Industrial Circle Bangor, ME 04401 www.granbyindustries.com 2021-3-1 G2020-E6 - Rev. C...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Boiler – Oil IMPORTANT SAFETY ADVICE ............3 PRODUCT INFORMATION .............4 UNIT INSTALLATION ..............5 3.1 PLACEMENT & LEVELING OF THE UNIT ......................5 3.2 TRIM KIT COMPONENT INSTALLATION ......................5 3.3 JACKET ASSEMBLY AND CONTROL INSTALLATION ..................7 PIPING ..................11 ELECTRICAL WIRING ..............16 CHIMNEY INFORMATION ............19... -
Page 3: Important Safety Advice
1.0 IMPORTANT SAFETY ADVICE Please read and understand this manual before installing, operating or servicing the boiler. To ensure you have a clear understanding of the operating procedures of the appliance please take the time to read the section IMPORTANT SAFETY ADVICE in this manual. -
Page 4: Product Information
2.0 PRODUCT INFORMATION PHYSICAL DIMENSIONS Shipping Weight Length Weight Water Content Flue Size No. of Sections (pounds) (inches) (pounds) (us gal) (inches) 18.5 23.0 27.5 31.75 10.5 36.25 40.5 13.5 45.0 CLEARANCES Proper clearances must be maintained not only from combustible materials but also to provide adequate access for servicing. -
Page 5: Unit Installation
TEMPERATURE DELTA : 20°F FLUE PIPE CONNECTION CHIMNEY or Granby Direct Vent System (3, 4 & 5 section boiler only) CLEANOUTS Rear removable smoke hood & front combustion chamber swing door FUEL Not heavier than No.2 fuel oil CAUTION: Do not use gasoline, crankcase drainings, or any oil containing gasoline. - Page 6 STEP 1: VERIFY CONTENTS OF TRIM KIT The boiler trim kit package includes: Knockdown Boiler Trim Kit Components Hydrolevel Kit Honeywell Kit CBT-KD-3250-00 CBT-KD-7248-00 Item Part no. Description CBF-BN-1025-00 1" x 2 1/2" Nipp CBF-BT-1010-07 1" x 1" x 3/4" Tee CBF-BP-0010-00 1"...
-
Page 7: Jacket Assembly And Control Installation
3.3 JACKET ASSEMBLY AND CONTROL INSTALLATION The boiler jacket has been designed for ease of assembly and removal. The following are step by step instructions. A philips screwdriver, 17mm socket and ratchet, 17mm wrench or adjustable wrench are needed. STEP 1: VERIFY CONTENTS OF JACKET ASSEMBLY PACKAGE. Your jacket assembly will contain boiler block insulation, rear of block insulation, front panel insulation, two (2) side panels, rear panel, top panel, front panel and a fastening package with screws and foil tape for fastening insulation. - Page 8 STEP 2: INSULATION INSTALLATION Drape the large piece of boiler block insulation directly over the block taking care to provide equal coverage on both sides. If installing a 7,8, or 9 section boiler, the extension insulation should be draped over the rear 3 sections of the boiler. Install the rear insulation piece by sliding it over the upper tie rods and around the flue collar as shown.
- Page 9 STEP 4: SIDE PANEL ATTACHMENT CONTINUED Align the left and right panel so the knock out on the side of each panel is located toward the upper front corner of the boiler. Install each side panel by sliding the front mounting holes over the front tie rods.
- Page 10 STEP 6: TOP PANEL ATTACHMENT Affix the top panel by placing the holes located on the underside of the panel over the jacket affixing pins. Press down on the top panel and it will snap in place. Secure the top panel to the back of the side panels with 2 sheet metal screws provided in the hardware packet.
-
Page 11: Piping
STEP 8: CONTROL MOUNTING Upon completion of the jacket assembly the operating control can be mounted on the side of the boiler where the sensor wire was installed. The jacket side panels have been pre- drilled holes for mounting the control. Follow the mounting instructions and use the hardware provided with the control. - Page 12 Circulation Pump A calculation for proper pump selection must be performed for all installations. The pump(s) should not be operated at maximum working pressures above 30 psi or maximum working temperatures above 200°F and within limits advised by the manufacturer. The pump must not be operated unless the system has been flushed, bled of all air and completely filled with water.
- Page 13 Figure 2: A typical installation with no domestic hot water and with a by-pass loop installed. By-pass MUST be same size as supply / return pipes. Figure 3: A typical installation with domestic hot water supplied by an indirect heater and with no by-pass loop installed.
- Page 14 Figure 4: A typical installation with domestic hot water supplied by an indirect heater connected to boiler accessory tappings. Figure 5: A typical installation with domestic hot water supplied by an indirect heater connected to boiler accessory tappings and a by-pass on the heating circuit.
- Page 15 Figure 6: Primary / Secondary piping with domestic hot water supplied by an indirect heater connected to boiler accessory tappings. Figure 7: Alternative Primary / Secondary piping with domestic hot water supplied by an indirect heater connected to boiler accessory tappings.
-
Page 16: Electrical Wiring
5.0 ELECTRICAL WIRING All external wiring must be performed in compliance with existing electrical codes within the local jurisdiction. In Canada, in compliance with the requirements of CSA STANDARD C22.1 and the Canadian Electrical Code. In the USA, in compliance with the requirements of NFPA 70, National Electrical Code. - Page 17 HEATING and Indirect Water Heater IMPORTANT: When installing with an indirect water heater, the Zone/Indirect Switch must be set in the I position. When set in the I position, calls to ZC-ZR will bypass the Thermal Targeting feature and allow the boiler to fire to the high limit setting to heat the indirect tank. The indirect signal must be separate from all heating zone signals.
- Page 18 Typical wiring for line voltage oil burner with Honeywell L7248 and one heating zone. Make sure sensor is inserted ALL THE WAY into the immersion well on top of the boiler. Route sensor wire through clearance hole A and connect it to the L7248 control.
-
Page 19: Chimney Information
If the masonry, brick, block chimney or tile chimney liner is in poor condition a new chimney liner rated for oil may have to be installed. In the event the condition still exists after installation of a new liner consult Granby. -
Page 20: Fuel System
7.0 FUEL SYSTEM The fuel system piping must comply with the fuel pump manufacturers’ specifications which are included with the burner. In addition, all fuel system piping must comply with local codes and ordinances. • The quality of your fuel oil is of great importance. For most instances your burner is designed to burn clean, water free, #2 fuel oil. -
Page 21: Burner Installation And Setting
COMBUSTION & VENTILATION AIR Install openings and ductwork to the boiler room providing fresh outside combustion and circulating air, as required by installation code CSA B139, NFPA31, NFPA211 and local codes. If the boiler is installed in a confined room and all air is taken from an adjacent, unconfined, indoor space, provide 2 openings of not less than 1 sq in. - Page 22 SET BURNER FOR EFFICIENT OPERATION BURNER SETTING Use burner settings in the table on page 25, or operating decal, as a guide to set the burner, particularly for nozzle changes. These settings are only starting points for the adjustments and are not meant as final settings.
- Page 23 All your tests must be done with the burner cover on COMBUSTION After 10 minutes of normal operation, take a smoke test and adjust SETTING/ the burner to obtain a reading of “1” on the smoke scale. EFFICIENCY To reach the maximum smoke test value, a 10 full slow steady pump action is required.
-
Page 24: Technical Information
9.0 TECHNICAL INFORMATION B*C Cast Iron Boiler specifications Riello Oil Burner 40 F3 40 F5 40 F10 Unit Model B*C-01-0080-** B*C-01-0118-** B*C-01-0147-** B*C-01-0185-** B*C-01-0228-** B*C-01-0270-** B*C-01-0300-** Number of sections Firing Rate (USGPH) 0.67 0.98 1,23 1.54 1.89 2.25 2.50 Input (BTU/h) 93,398 136,612 171,462... -
Page 25: Boiler Start Up And Operation
10.0 BOILER START UP AND OPERATION CAUTION: DO NOT ATTEMPT TO START THE BURNER WHEN EXCESS OIL HAS ACCUMULATED, WHEN THE UNIT IS FULL OF VAPOR OR WHEN THE COMBUSTION CHAMBER IS VERY HOT 10.1 START UP PROCEDURE • Prior to start up make sure the service switch is in the OFF position. •... -
Page 26: Hydrostat 3250 Control
10.3 HYDROSTAT 3250 CONTROL Setting the control... -
Page 28: Maintenance / Service
11.0 MAINTENANCE / SERVICE CAUTION: CONTACT SERVICE PERSONNEL BEFORE REMODELING (MODIFYING THE SYSTEM), FOR ANNUAL SERVICING/MAINTENANCE, BEFORE EXTENDED PERIODS OF SHUTDOWN, AND BEFORE START-UP. Your heating appliance is designed to be maintained and serviced only by your heating professional. The following sections provide information on maintenance and service- related activities. -
Page 29: Cleaning The Boiler
11.1 CLEANING THE BOILER Boiler cleaning should only be performed by a qualified service technician and must only be performed when the boiler is out of service. The following steps should be followed: • Shut off electrical power to the boiler •... -
Page 30: Exploded Parts View
12.0 EXPLODED PARTS VIEW... - Page 31 Part List ITEM DESCRIPTION ITEM DESCRIPTION Front Section M10 Nut Anti Tamper Intermediate Section Turbulator Upper Hinge Eye Bolt Turbulator Lower Rear Section Boiler Block Insulation 6" Flue Collar (6,7,8,9 Section) Jacket Side Panel - Left 5" Flue Collar (3,4,5 Section) Jacket Side Panel - Right Tie Rod M10 Jacket Panel - Top...
-
Page 32: Start-Up Test Results
13.0 START-UP TEST RESULTS Model: Serial Number: Boiler, # sections Date of installation: Installer (name & address): TEST RESULTS Size of unit (Btu/h): Nozzle: Oil Pressure (psi): Chimney size ____________ Direct vent system (DVS) _________ Burner adjustments: RIELLO F3___ BF3___ RIELLO F5___ BF5___ RIELLO F10____ Turbulator:... - Page 33 DELTA TEMPERATURE TEST PROCEDURE Delta Temp = Supply Temp – Return Temp This is an example only for a Delta temperature test procedure comprehension...
- Page 34 Granby Industries L.P. manufactures a full line of oil and gas-fired boilers. Granby products are sold across Canada and the United States through a distribution network. Our team of engineers, designers and technicians continually research and develop products to go beyond the demanding specifications of today’s certifications.
