Variquest Trifecta 800 Quick Start Quide

STARTING A PRINT

MAIN
MENU
Print Temp
Control Wizard Status
Insert your SD card into the slot to the left of the
1
screen. Use the dial to select Print on the main menu.
Whenever you begin a print, always check that the rst layer of the print is properly stuck onto the blue painter's tape. A
properly leveled bed should have the extruded lament a bit squished and shouldn't pop off the bed easily. While the
printer is performing the skirt nozzle purge, observe the deposited lament and make micro-adjustments with the thumb-
screws if necessary.
TOO CLOSE
Bed Leveling Tip! The on-screen instructions will guide you through leveling your bed at three different points. For
proper calibration, slide a piece of construction paper under the hotend at each of the three points. Tighten/loosen
the leveling screws to ensure a slight drag on the construction paper. Turn the screws clockwise to raise the bed
and counterclockwise to lower the bed.

TECHNICAL SUPPORT

For technical assistance, please contact your authorized VariQuest dealer or the VariQuest Technical Support team:
• Email: techsupport@variquest.com
• Phone: 1-800-328-0585
© 2016 Varitronics®, LLC. All Rights Reserved.
MAIN
TEST_PRINT.G
VASE.G
BRACELET.G
YOUR_PRINT.G
Scroll down to the le you want to print and push the
2
dial in to start the print.
LEVELED TOO FAR
R2900224 6/2016
Trifecta 800 3D Printer
™
Blue Tape
2
Remove printer accessories from the compartment.
4
Remove the printer and lament from the box.
Filament Spool
Trifecta™ 800 Printer
The Trifecta™ 800 3D
Use a box cutter to
Printer can be too heavy
trim along the taped
to lift out of the box by
edges and peel back
yourself. Ask for help to
36.4
the outer box aps.
prevent injury or damages
lbs
to the printer.
1
Open shipping box and remove the compartment lid.
USB Cable
Power Cable
Glass Print Bed Print Bed Clips x4
3
Remove foam bracket and take out the printer and lament.
5
Place the printer on a rm at surface.
Make sure the printer is located
near an accessible power outlet.
Place the Trifecta™ 800 3D Printer and PLA Filament
in a moisture-free and low dust environment.
Store opened spools of lament in a sealed bag with
a desiccant packet.
Hex Wrench
SD Card
