- Page 1 World Leader in Modular Torque Limiters Installation and Maintenance Instructions JSE1-0129MAEAD Extruder Clutch 1304 Twin Oaks Street · Wichita Falls, Texas 76302 · (940) 723-7800 · Fax: (940) 723-7888 E-mail: sales@brunelcorp.com · www.brunelcorp.com...
-
Page 2: Installation
Installation and Maintenance Instructions JSE1-0129MAEAD Extruder Clutch 1. INSTALLATION a. Coupling should be installed with pins/buffers removed. b. Apply an anti-seize compound to the gearbox input shaft. c. Slide gearbox coupling half (1-23) onto gearbox shaft. d. Slide motor hub onto shaft. -
Page 3: Torque Adjustment
Installation and Maintenance Instructions JSE1-0129MAEAD Extruder Clutch 5. TORQUE ADJUSTMENT 2) Release Set Screw (2-15) in housing (2-11) using special tool. 3) Turn housing nut (2-7) counter-clockwise using socket until a. To adjust torque at the job site: Prior to setting Safety Elements... - Page 4 Screws (2-20) using special tool provided. If so clean & file burrs until usable or replace defective parts. 9. JSE1-0129MEAD SETTING CURVE JSE1-0129MAEAD Setting Curve RELEASE TORQUE vs. SETTING Set each Module to Mark which corresponds to Required Release Torque...
- Page 5 TABLE 1 Operational Max. Eflex Coupling Rigid Hub Brunel Part No. Coupling Alignment Limit Tightening Torque Tightening Torque Size or O.D.
- Page 7 Publication: JSE1-0129MAEAD 6-10 Phone: 940.723.7800 Fax: 940.723.7888 www.brunelcorp.com 1304 Twin Oaks Street Wichita Falls, TX 76302...
