Summary of Contents for UniFi Cloud key Gen2 Plus
- Page 1 UniFi Cloud Key Gen2 Plus...
- Page 2 Removable hard drive tray for 2.5" SATA drive. The Cloud Key G2 Plus only supports hard drives that can operate on 5V power. Hard drives that require additional power are not supported. LCD Screen Device Status display. Automatically rotates status screens for enabled controllers. UniFi Network Display...
- Page 3 UniFi Protect Controller name and bandwidth Total camera(s) recording bitrate Status of Protect Cloud Access Number of active cameras registered in UniFi Protect Time of last motion detected by UniFi Protect Power Button Press to turn the Cloud Key Gen 2 Plus on or off.
- Page 4 Used for power if PoE is not available. Quick Charge 2.0 or Quick Charge 3.0-compliant USB power adapter is required. Ethernet Port Connects to a gigabit switch port on your LAN. Power can be provided by an 802.3af PoE switch, such as the UniFi PoE Switch.
- Page 6 When used, it also prevents removal of the HDD while the device is in use. Rack-Mount Notch Secures the Cloud Key Gen2 Plus into the docking bay of the optional Rackmount Accessory, model CKG2-RM (sold separately). The Rackmount Accessory allows you to install the Cloud Key Gen2 Plus in a standard 19"...
- Page 7 13-Pin Connector Connects the Cloud Key Gen2 Plus to the optional Rackmount Accessory, model CKG2- RM (sold separately). The CKG2-RM has a docking bay for the Cloud Key Gen2 Plus and allows you to install it in a standard 19" rack.
- Page 12 Warning: To prevent creating a loop or other unfavorable behavior on the network, only one Ethernet connection should be used. Do not use the Ethernet port on the Cloud Key Gen2 Plus and the Rackmount Accessory simultaneously.
- Page 13 Note: Ensure that Bluetooth is enabled on your mobile device. You will need to set up the Cloud Key Gen2 Plus with your mobile device and be within 1.5 m (5') from where it is installed.
- Page 19 Note: You can run the UniFi Network Controller or UniFi Protect software individually, or you can run both applications simultaneously.
- Page 25 • • •...
- Page 30 Google Maps™) for a visual representation of your Network network and also view your system topology. The Devices screen displays a list of UniFi devices managed by your Network controller. The Clients screen displays a list of clients connected to UniFi devices managed by your Network controller.
- Page 35 Description The Cameras screen lists all cameras currently managed by UniFi Protect. The Live View screen lists all live view layouts for UniFi Protect. Click Add Live View to create a new live view. Review events recorded by UniFi Protect. Customize your events by selecting a camera from the drop-down list and creating a specific date range of recordings to view.
- Page 37 Note: The Cloud Key G2 Plus only supports hard drives that can operate on 5V power. Hard drives that require additional power are not supported. WARNING: Do not release or operate the HDD Latch while the Cloud Key Gen2 Plus is in use or powered on.
- Page 42 1 TB 2.5" SATA HDD (user-upgradeable*) Device Capacity UniFi Protect Mode UniFi Network + Protect Up to 20 UniFi Cameras Up to 15 UniFi Cameras and 50 UniFi Devices eMMC Memory 32 GB Networking Interface (1) 10/100/1000 Ethernet Port Buttons...
- Page 43 UCK-G2-PLUS LEDs (1) Power, White/Blue Power Method Standard 802.3af PoE; Quick Charge 2.0/3.0 power adapter (9VDC, 2A) Supported Voltage Range Standard 802.3af PoE or 9VDC, 2A Max. Power Consumption 12.95W (PoE) USB-C Power Operating Temperature 0 to 35° C (32 to 104° F) Operating Humidity 20 to 80% Noncondensing Certifications...
- Page 44 • • • •...
- Page 45 • • Warning: This equipment is compliant with Class A of CISPR 32. In a residential environment this equipment may cause radio interference. Nota: Este equipamento não tem direito à proteção contra interferência prejudicial e não pode causar interferência em sistemas devidamente autorizados. Country List AT BE BG CY CZ DE DK...
