Environics 6202-1 Operator's Manual

Reduced oxygen breathing device 2
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Model 6202-1
Reduced Oxygen Breathing
Device 2
Operator's Guide
Revision 8
September 2nd 2016
Software Rev. 6202-2.00-XX
Environics Inc.
69 Industrial Park Road East
Tolland, CT 06084-2805 USA
Phone (860) 872-1111
Fax (860) 870-9333
E-mail:
INFO@ENVIRONICS.COM
Web:
HTTP://WWW.ENVIRONICS.COM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 6202-1 and is the answer not in the manual?

Questions and answers

Related Manuals for Environics 6202-1

Summary of Contents for Environics 6202-1

  • Page 1 Model 6202-1 Reduced Oxygen Breathing Device 2 Operator’s Guide Revision 8 September 2nd 2016 Software Rev. 6202-2.00-XX Environics Inc. 69 Industrial Park Road East Tolland, CT 06084-2805 USA Phone (860) 872-1111 Fax (860) 870-9333 E-mail: INFO@ENVIRONICS.COM Web: HTTP://WWW.ENVIRONICS.COM...
  • Page 2 Environics Inc. warrants this product to be free from defects in material and workmanship for a period of one year from the date of shipment. Environics warrants the following expendable items for 30 days from the date of shipment: fuses, lamps, batteries.
  • Page 3 Added O2 DUMP PRESSURE setting to OPTION menu Modified O2 Dump and O2 Pressure safety feature section Corrected Patent information 2.00-XX 7/30/2016 Updated manual to include modifications made for new model 6202-1 2.00-XX 9/2/2016 Added information about the vent plug in the vent port...

  • Page 4: Table Of Contents

    TABLE OF CONTENTS LIST OF FIGURES   LIST OF ABBREVIATIONS / ACRONYMS   OVERVIEW   SYSTEM LAYOUT   Front Panel Layout   Rear Panel Layout   UNPACKING AND INSTALLATION   Standard packaging and unpacking   Transport case option and unpacking  ...

  • Page 5: List Of Figures

    LIST OF FIGURES FIGURE 1 - FRONT PANEL LAYOUT ..............2   FIGURE 2 - REAR PANEL LAYOUT ..............4   FIGURE 3 - P&ID ....................34  ...

  • Page 6: List Of Abbreviations / Acronyms

    LIST OF ABBREVIATIONS / ACRONYMS Alternating Current Electromagnetic Interference Hertz Liquid Crystal Display Liters Per Minute Mass Flow Controller Nitrogen and Air Generator P&ID Piping and Instrument Diagram PSIG Pounds Per Square Inch Gauge Radio Frequency Interference Subject Under Test Volts, Alternating Current Volts, Direct Current...

  • Page 7: Overview

    OVERVIEW OVERVIEW The second generation Reduced Oxygen Breathing Device (ROBD2) is a computerized gas-blending instrument. The system uses Thermal Mass Flow Controllers (MFC) to mix breathing air and nitrogen to produce the sea level equivalent atmospheric oxygen contents for altitudes up to 40,000 feet. The MFCs are calibrated on primary flow standards traceable to the National Institute of Standards and Technology (NIST).

  • Page 8: System Layout

    SYSTEM LAYOUT SYSTEM LAYOUT Front Panel Layout Figure 1 - Front panel layout ROBD2 USER’S GUIDE SEPTEMBER 2016...
  • Page 9 This female connection port (MS 22058-1), with spring-loaded cover, is for the pilot’s breathing mask connection. Pulse oximeter The new 6202-1 pulse oximeter has a color touch screen. The details of the pulse oximeter are covered in the pulse oximeter section of this manual ROBD2 USER’S GUIDE...

  • Page 10: Rear Panel Layout

    SYSTEM LAYOUT Rear Panel Layout Figure 2 - Rear panel layout ROBD2 USER’S GUIDE SEPTEMBER 2016...
  • Page 11 SYSTEM LAYOUT Power Input The power entry module supplies AC power to the internal power supplies. The internal power supplies convert and regulate the AC signal to the five DC voltages required by the system electronics. The power entry module has integrated EMI/RFI filtration and switch one or both hot lines dependent upon 110 or 220 VAC operation.
  • Page 12 SYSTEM LAYOUT Vent port This port vents the excess flow of gas not used during inhalation and exhalation and also limits the pilot mask pressure. Important: A filtered vent plug has been installed into the vent port. This vent plug will provide a slight positive pressure to the breathing mask. If the absence of positive pressure is desired, remove the threaded plug.

  • Page 13: Unpacking And Installation

    UNPACKING AND INSTALLATION UNPACKING AND INSTALLATION Standard packaging and unpacking 1. Remove the system from the cardboard box in which it was delivered from the factory. 2. Remove and read any important instructions or notes found within the box. 3. Save and store the box and foam inserts in the event the system needs to be returned to the factory or delivered to another site for operation.

  • Page 14: Power And Gas Connections

    POWER AND GAS CONNECTIONS After the RODB2 is unpacked, the system should be connected to power and the appropriate gas sources to the gas inlet ports on the rear panel. Environics recommends the use of a power conditioner, as recommended for computers, to eliminate power problems from affecting system operation.

  • Page 15: Gas Connection

    POWER AND GAS CONNECTIONS Gas Connection Input Gas Connections Input Gas connections are keyed and colored quick connect fittings. 1. On the rear of the ROBD2, connect the air (yellow) and nitrogen (black), at a pressure of 40 to 50 PSIG, to the respective ports. Connect the 100% oxygen (green) source at a pressure of 20 PSIG.

  • Page 16: Quick Start Procedure

    QUICK START PROCEDURE QUICK START PROCEDURE 1. Before Powering on the system make sure to perform the steps outlined in the section titled Power and gas connection. 2. Connect the pulse oximeter probe any time before or after powering on the instrument.

  • Page 17: Power Up And Self-Tests

    POWER UP AND SELF-TESTS POWER UP AND SELF-TESTS Power up The system power switch is on the rear panel power entry module. It is important that all gas connections are made before self-tests. Refer to the section titled Gas connection. Warmup The system requires a 10 minute warmup period after it is powered up.

  • Page 18: Self-Test Operations

    POWER UP AND SELF-TESTS Self-test Operations Oxygen sensor test The oxygen sensor test will check the on-board oxygen sensor accuracy. The system will provide air to the sensor for 20 seconds and report the 02 content as read by the un-calibrated 02 sensor. If the 02 content falls outside the limits set by the test, the test will fail.

  • Page 19: Self Calibration Operations

    POWER UP AND SELF-TESTS Self-Calibration Operations Before running programs, the system must run through its self-calibration routine at the start of each operating day, and every time the system is powered on. These tests will run automatically after the system has warmed up for 10 minutes. If this process is not run, the system will not allow the operator to enter the START mode.
  • Page 20 POWER UP AND SELF-TESTS Once the system has calibrated the sensor for air, it will proceed to supplying 100% 02 to the sensor. The following will be displayed: ANALYZING 100% 02 ACTUAL 02 PERCENT 02 SENSOR CAL REMAINING TIME AS READ BY 02 MEASURING 02 100% SENSOR 02= 99.5%...

  • Page 21: System Operation

    SYSTEM OPERATION SYSTEM OPERATION Entering data At various times during system operation the operator is required to enter data into the system. Entry of numeric data is performed by using the numeric keypad. Press the number key(s) representing the desired data values and press ENTER to record the data in the appropriate field.

  • Page 22: Main Screen - Ready Mode

    The system’s menu-driven software guides the operator through all operating routines. The following menu items are available to the user. (DAY) (DATE) (TIME) ENVIRONICS ROBD2 READY START SELFTST OPTION START The START key is used to enter the Pilot Test mode. The Pilot Test mode is where all pilot testing takes place.

  • Page 23: Start - Pilot Test Mode

    SYSTEM OPERATION START – Pilot Test mode PILOT TEST MENU RUNPRG EXIT Standby status in Pilot Test mode Once in this menu, the operator can select to run a program. RUNPRG – Running a flight profile The RUNPRG mode is used to conveniently recall one of 20 saved programs with up to 99 steps of altitude changes.
  • Page 24 SYSTEM OPERATION RUNPRG SCREEN 1 PROGRAM STEP INFO 34000 30000 F/M ELAPSED TIME CURRENT ALTITUDE ALT = 25000 = 30 S REMAINING TIME = 7.11% Rmn = 38 S ACTUAL 02 PERCENT BLP = 1.30 AS READ BY 02 SENSOR BREATHING LOOP PRESSURE “H2O RUNPRG SCREEN 2...
  • Page 25 SYSTEM OPERATION RUNPRG EXAMPLE STEP 1: HOLD AT 34000 FEET FOR 2 MINUTES STEP 2: CHANGE TO 0 FEET AT 18000 FT/MIN STEP 3: HOLD AT 0 FEET FOR 1 MINUTE STEP 4: CHANGE TO 20000 FEET AT 30000 FT/MIN STEP 5: END OF PROGRAM STEP 1: SCREEN 2...
  • Page 26 SYSTEM OPERATION While in the RUNPRG mode, pressing the STOP key will abort the program. Pressing the ADVANCE key while in the run mode will advance the program to the next step, regardless of how much time remains in the current step. Pressing the 02 DUMP switch will cause the program to shut down and the system will supply 100% 02 to the SUT.

  • Page 27: Option Menu

    SYSTEM OPERATION Option menu The OPTION menu is used to run self-test and self-calibration functions, and to change various system settings. Pressing the OPTION key will bring up the following display. > TEST RESULTS SELF TEST SELF CALIBRATE EXIT The OPTION menu contains a menu with the following items: TEST RESULTS SELF-TEST SELF CALIBRATE...
  • Page 28 SYSTEM OPERATION TEST RESULTS The Test Results function displays the results of all Self-test and Self Calibrate functions. The test item is listed on the left, with the result shown on the right. Below is a sample test result display: TEST RESULTS PULSE OXIM O2 DUMP VALVE -...
  • Page 29 YES to rerun the test, otherwise press NO. ROBD FLOW RATE The flow rate of the 6202-1 is adjustable from 40 LPM to 80 LPM. The nominal setting is 50 LPM to provide enough gas flow to the subject under test while preserving valuable gas.
  • Page 30 SYSTEM OPERATION ADMIN MODE The ADMINinstrator MODE allows access to Administrator level functions, which include programming of test routines (PROG mode) and system functions (SYSTEM mode) such as MFC calibration. To enter ADMIN mode, select ADMIN MODE from the menu and press ENTER. If there is an Administrator password, you will be prompted to enter it.
  • Page 31 SYSTEM OPERATION ADJUST CONTRAST The contrast of the LCD display is affected somewhat by the angle at which the display is viewed as well as the ambient temperature. To adjust the contrast for optimum results: 1. Using the up and down arrow keys, move the pointer cursor down to the line that reads ADJUST CONTRAST and press the ENTER key.

  • Page 32: Safety Features

    SAFETY FEATURES SAFETY FEATURES There are a number of built-in safety features to either alert the operator or stop the operation of the system and go to a “safe” mode of operation. Oxygen dump switch An emergency Oxygen Dump switch has been provided to supply 100% oxygen on demand as the subject under test (SUT) becomes hypoxic.
  • Page 33 SAFETY FEATURES If Low O2 Pressure is detected in the Ready mode, the system will display LOW O2 instead of READY, on the screen In the Pilot Test Menu, if any of the Pilot Test keys (RUNPRG or PPT) are pressed during a Low O2 Pressure condition, the system will display the following screen and prevent the system from running in the Pilot Test Menu.

  • Page 34: Pulse Oximeter

    PULSE OXIMETER PULSE OXIMETER SpO2 and Pulse Rate Displays Like the 6202 pulse ox, the 6202-1 takes about 10 seconds after placing the probe on the finger to register valid data. This is inherent to the pulse oximeter electronics/firmware. The measured SpO2 and pulse rate are displayed side by side as shown in the diagram below.

  • Page 35: Spo2 And Pulse Rate Alarms

    PULSE OXIMETER Pulse Activity Bar The signal bar or pulse activity bar, on the left side, is derived from the pulsatile signal that is measured by the monitor. The height of the bar, with each pulse beat, is proportional to the strength of the signal. This pulse activity bar represents the subject’s pulse and should show regular rhythmic movement.
  • Page 36 PULSE OXIMETER Setting SpO and pulse rate alarm limits To access the alarm setting screen, press the pulse or SpO2 display windows shown below. For touchscreen variables either a finger or stylus can be used. ROBD2 USER’S GUIDE SEPTEMBER 2016...
  • Page 37 PULSE OXIMETER Press on one of the four blue limit buttons and a virtual numeric keypad, shown below, will appear. Enter the new value and press the enter key. This will accept the new value back into the screen below and save it indefinitely. If an alarm becomes active, access to the alarm setting screen is denied until the alarm condition clears.
  • Page 38 PULSE OXIMETER Adjusting the alarm and pulse bar volume To change the pulse bar, pulse alarm, and SpO2 alarm volumes, press Set Volume. Each time that field is pressed, the new variable to adjust will appear. Once on the desired variable, press the up or down arrow key. The value setting will flash on the screen and the beeper will beep to the new volume level.
  • Page 39 PULSE OXIMETER Pulse oximeter self-test When the 6202-1 is powered on, the classic tone sequence of the 6202 pulse oximeter will be heard. After the initial sound sequence, there will be a single tone, within about 8 seconds, and the screen will flash pass in the lower right hand corner.
  • Page 40 PULSE OXIMETER Figure 3 - P&ID ROBD2 USER’S GUIDE SEPTEMBER 2016...
