LED’s light OUTDOOR SERIES GB Table of contents Package contents 01 Manual identification General 03 Unique identification of the product Security related information Conformity of the product with legislation Storage of the Manual Use of the product / Installation Operating the product Product maintenance Accessories, consumables, spare parts Informatie over speciaal gereedschap, apparaten Information about repair, replacement of parts Information for disposal...
LED’s light OUTDOOR SERIES Security related information When using the product, make sure the unit is sufficiently ventilated, never cover the unit during operation and keep it out of reach of children or animals. This product is not a toy, LED lights are extremely bright and looking directly at the light source during operation can lead to serious eye damage.
LED’s light OUTDOOR SERIES Accessories, consumables, spare parts For this product there are no accessories or replacement parts available. Informatie over speciaal gereedschap, apparaten depending on the Mounting-surface, you will need a pencil, waterlevel, powerdrill, screws, wall plugs and a screwdriver. For the electrical installation, you will need wire cutters, wire stripper and a slot-head elctronics-screwdriver.
LED’s light OUTDOOR SERIES Instructions for wall-mounting Attention! [01]x1 When mounting on hollow walls, make sure you use correct hollow-wall-plugs to assure a secure fixation of the device to the wall. When mounting on paneling, make sure that thare are no cavities behind the paneling, to prevent damaging the paneling when tighten- ing the screws during mounting of the device.
Page 8
LED’s light OUTDOOR SERIES [01]x1 4. Drill the mounting holes, using wall-plugs as needed to assure a secure fixation to the [A]x2 underground. [A]x2 90° φ6mm 60mm φ6mm 60mm 90° 90° 90° [A]x2 5. Route the cables through the silicone sealing flange and screw the wall fixture to the wall.
LED’s light OUTDOOR SERIES Settings (Button A) 1. Press 1 time (the indicator-light will blink once) when it is dark, the floodlight will turn on (3min.), on detec- tion of movement, and follow the moving object. 2. Press 2 times (the indicator-light will blink twice) the floodlight will turn on (3min.), on detection of movement, and follow the moving object.
Page 10
LED’s light OUTDOOR SERIES D Inhaltsverzeichnis Lieferumfang 01 Identifikation der Bedienungsanleitung Allgemeines 03 Eindeutige Identifikation des Produktes 04 Modifikation der Produktes Sicherheitsbezogene Informationen Konformität des Produkts Aufbewahrung der Bedienungsanleitung Gebrauch des Produktes / Installation Betrieb des Produktes Instandhaltung des Produktes Zubehörteile, Verbrauchsmaterialien, Ersatzteile Informationen zu speziellen Werkzeugen, Geräten Information zur Reparatur, Austausch von Teilen Hinweise für die Entsorgung Dokumentation...
Page 11
LED’s light OUTDOOR SERIES 05 Sicherheitsbezogene Informationen Bei der Wahl der Betriebsstätte sollten Sie auf ausreichende Belüftung des Gerätes achten. Decken Sie das Gerät niemals während des Betriebs ab. Betreiben Sie das Gerät nicht in Reichweite von Kindern oder Tieren. Diese Produkt ist kein Spielzeug. LED Leuchten sind extrem hell.
Page 12
LED’s light OUTDOOR SERIES Instandhaltung des Produktes Das Produkt kann mit einem feuchten, weichen Tuch gereinigt werden. Bitte benutzen Sie keine chemischen oder abrasiven Reinigungsmittel (wie beispielsweise Scheuermilch, Stahlwolle etc.). Zubehörteile, Verbrauchsmaterialien, Ersatzteile Für dieses Produkt sind keine Zubehör- oder Ersatzteile verfügbar. Informationen zu speziellen Werkzeugen, Geräten Je nach Montagefläche benötigen Sie einen Bleistift, Wasserwaage, Bohrer, Schrauben, Dübel und einen Schraubendreher.
Page 13
LED’s light OUTDOOR SERIES 18. Anleitung zur Wandmontage Achtung! [01]x1 Bei der Montage an Leichtbauwänden, Styropor oder ähnlichem ist darauf zu achten, dass Sie die richtigen Dübel verwenden, um eine sichere Befestigung des Gerätes an der Wand zu gewährleisten. Bei der Montage auf Verkleidungen ist darauf zu achten, dass sich hinter der Verkleidung keine Hohlräume befinden, um eine Beschädigung der Verkleidung beim Anziehen der Schrauben während der Montage des Gerätes zu vermeiden.
Page 14
LED’s light OUTDOOR SERIES [01]x1 4. Bohren Sie die Befestigungslöcher und verwenden Sie bei Bedarf passende Dübel, um [A]x2 eine sichere Befestigung am Untergrund zu gewährleisten. [A]x2 90° φ6mm 60mm φ6mm 60mm 90° 90° 90° [A]x2 5. Führen Sie die Kabel durch den Silikondichtungsflansch und schrauben Sie die Halte- rung an die Wand.
Page 15
LED’s light OUTDOOR SERIES ACHTUNG! Drehen Sie die Leuchte nicht, wenn Sie Widerstand spüren, da dies den Verfolgungs -mechanismus beschädigen kann! 12. Schalten Sie die Netzspannung wieder ein und stellen Sie sicher, dass das Produkt funktioniert. 19. Einstellungen (Knopf A) 1.
Page 16
LED’s light OUTDOOR SERIES NL Inhoudsopgave Verpakkingsinhoud 01 Identificatie van de bedieningsinstructies 02 Algemeen 03 Unieke identificatie van het product 04 Aanpassing van het product 05 Veiligheidsgerelateerde informatie 06 Conformiteit van het product met wetgeving 07 Opslag van de bedieningsinstructies 08 Gebruik van het product / Installatie 09 Werking van het product 10 Onderhoud van het product 11 Accessoires, verbruiksgoederen, reserveonderdelen...
Page 17
LED’s light OUTDOOR SERIES speelgoed. LED-lampen zijn extreem helder en het direct kijken in de lichtbron kan ernstig oogletsel veroorzaken. Elk ander gebruik van het apparaat dan beschreven in de gebruiksaanwijzing kan het product beschadigen of gevaar voor de gebruiker veroorzaken, bijv.
Page 18
LED’s light OUTDOOR SERIES 12 Informatie over speciaal gereedschap, apparaten Afhankelijk van het montageoppervlak hebt u een potlood, waterpas, boormachine, schroeven, pluggen en een schroevendraaier nodig. Om de floodlight aan te sluiten heeft u een kniptang, een striptang en een sleufkop elektronica schroevendraaier nodig. 13 Informatie over reparatie, vervanging van onderdelen Het product niet demonteren! Het product kan niet worden gerepareerd.
Page 19
LED’s light OUTDOOR SERIES 18. Handleiding voor muurbevestiging [01]x1 LET OP. Gebruik bij holle wanden altijd de juiste pluggen om onnodig bewegen van de lamp en/ of eventueel beschadigen van de muur en/of de lamp te voorkomen. Zorg bij lambrisering er altijd voor dat de ondergrond opgevuld is zodat, men de schroeven en pluggen door de lambrisering niet in de harde wand monteert.
Page 20
LED’s light [01]x1 OUTDOOR SERIES [A]x2 4. Boor de gaten op de juiste locatie en plaats waar nodig de juiste pluggen voor de [A]x2 ondergrond in de muur. φ6mm 60mm 90° 90° [A]x2 φ6mm 60mm 90° 90° 5. Trek de kabels door de siliconen afdichtingsflens en schroef de muurplaat aan de muur. 6.
Page 21
LED’s light OUTDOOR SERIES 19. INSTELLEN FUNCTIES (knop A) 1. Druk één keer (de indicator zal één keer knipperen): Als het donker is, zal de floodlight, zodra beweging wordt gedetecteerd, aanspringen (3min.) en een bewegend object volgen. 2. Druk voor de tweede keer (de indicator zal twee keer knipperen): De floodlight zal zodra beweging wordt gedetecteerd, aanspringen (3min.) en een bewegend object volgen.
Page 22
LED’s light OUTDOOR SERIES F Table des matières Contenu de l‘emballage 01 Identification unique du produit Général 03 Identification unique du produit 04 Modification du produit Informations relatives à la sécurité Conformité du produit à la législation Stockage des instructions d‘utilisation Utilisation du produit / Installation Fonction du produit Entretien du produit Accessoires, consommables, pièces de rechange Outils nécessaires au montage...
LED’s light OUTDOOR SERIES Informations relatives à la sécurité Assurez-vous que le produit est bien ventilé. Ne pas couvrir le produit en cours d’utilisa- tion, garder le produit hors de la portée des enfants et/ou des animaux. Ce produit n’est pas un jouet, les lampes LED sont particulièrement lumineuse et regarder directement le faisceau lumineux peut causer des lésions oculaires graves.
LED’s light OUTDOOR SERIES Accessoires, consommables, pièces de rechange Aucunes pièces de remplacement ou accessoires ne sont disponibles pour ce produit. Outils nécessaires au montage En fonction de la surface de montage, vous aurez besoin d’un crayon, d’un niveau à bulle, d’une perceuse, de vis, de chevilles et d’un tournevis.
LED’s light OUTDOOR SERIES 18. Manuel pour montage mural [01]x1 Attention! Utilisez toujours les bons bouchons pour les murs creux afin d’éviter tout mouvement inutile de la lampe et / ou tout dommage éventuel du mur et / ou de la lampe. Avec les panneaux, assurez-vous toujours que le substrat est rempli afin que les vis et les chevilles ne soient pas montés dans le mur dur par les panneaux.
Page 26
LED’s light OUTDOOR SERIES [01]x1 4. Les trous de forage dans le bon endroit et le cas échéant les fiches appropriées pour la surface de la paroi. Route the cables through the silicone sealing flange and screw the [A]x2 wall fixture to the wall. [A]x2 90°...
LED’s light OUTDOOR SERIES 19. Fonctions de reglage (bouton A) 1. Appuyez une fois sur (l’indicateur clignotera une fois): lorsqu’il fait sombre, dès qu’un mouvement est détecté, le projecteur s’allume (3min.) et suit un objet en mouvement. 2. Appuyez une seconde fois (le témoin clignotera deux fois): le projecteur s’allumera (3min.) et suivra un objet en mouvement dès qu’un mouvement est détecté.
Page 28
LED’s light OUTDOOR SERIES ES Tabla de contenido Contenido de la caja 01 Identificación del manual General 03 Identificación única del producto. 05 Información de seguridad 06 Conformidad del producto con legislación. 07 Conservación del manual 08 Uso del producto / Instalación 09 Operación del producto Mantenimiento del producto Accesorios, consumibles, recambios 12 Información sobre herramientas especiales, dispositivos 13 Información sobre reparación, reemplazo de piezas. 14 Descripción de símbolos 15 Documentación 16 Declaración CE 17 Explicación de los símbolos, conceptos y particularidades del producto.
LED’s light OUTDOOR SERIES Información de seguridad Cuando utilice el producto, asegúrese de que la unidad esté suficientemente ventilada, nunca la cubra durante el funcionamiento y manténgala fuera del alcance de niños o animales. Este producto no es un juguete, las luces LED son extremadamente brillantes y mirar directamente a la fuente de luz durante el funcionamiento puede provocar lesiones oculares graves.
LED’s light OUTDOOR SERIES Accesorios, consumibles, recambios Para este producto no existen accesorios o piezas de recambio. Información sobre herramientas especiales, dispositivos Dependiendo de la superficie de montaje, necesitará un lápiz, nivel, taladro eléctrico, tornillos, tacos y un destornillador. Para la instalación eléctrica, necesitará cortadores de alambre, pelacables y un destornilla- dor de cabeza plana.
LED’s light OUTDOOR SERIES Instrucciones para montaje en pared ¡Atención! [01]x1 Cuando realice el montaje en paredes huecas, asegúrese de usar los tacos de pared hue- ca correctos para asegurar una fijación segura del dispositivo a la pared. Al montar en paneles, asegúrese de que no haya cavidades detrás de los paneles, para evitar dañar los paneles al apretar los tornillos durante el montaje del dispositivo.
Page 32
LED’s light OUTDOOR SERIES [01]x1 4. Taladre los orificios de montaje, utilizando tacos de pared según sea necesario para [A]x2 asegurar una fijación segura a la pared. [A]x2 90° φ6mm 60mm φ6mm 60mm 90° 90° 90° [A]x2 5. Pase los cables a través de la brida de sellado de silicona y atornille el accesorio de pared a la pared.
LED’s light OUTDOOR SERIES 10. Apriete también el pequeño tornillo de bloqueo debajo del pie de la unidad de la lám- para 11. Determine la dirección del haz inicial y el ángulo de proyección de la unidad de lámpara moviendo suavemente la cabeza hacia arriba o hacia abajo. Escuchará clics suaves cuando haga esto, esto es normal) ¡ATENCIÓN! ¡No gire la unidad de lámpara si nota resistencia, ya que esto puede dañar el mecanismo de seguimiento!
