Sony XS-V6945X Instructions (primary manual) Specifications

Design and Specifications subject to change without notice.
2004 SONY MOBILE
PRODUCT GUIDE
XS-V6945X
4-Way Speaker
Specifications
Speaker
Peak Power
Rated Power
Impedance
Sensitivity
Frequency response
Mass
Dimensions
194 mm (7 3/4")
Design and Specifications subject to change without notice.
Coaxial 4-way
Woofer 16 x 24 cm (6 3/8 x 9 1/2 in.) cone type
Midrange 6.6 cm (2 5/8 in.) cone type
Tweeter 2.5 cm (1 in.) balance dome type
Super tweeter 2.5 cm (1 in.) balance dome type
400 watts
100 watts
4 ohms
93 dB/W/m
25 - 32,000 Hz
Approx. 1,630 g (3 lb 10 oz) per speaker
32 mm (1 5/16")
• 6 x 9" HOP woofer cone
• 2-9/16" Nano-fine mid
• 1" balanced dome tweeter
• 1" balanced dome super tweeter
• 400W peak power (100W RMS)
• Flexible mounting options
4.5 x 5.5 mm (3/16 x 7/32")
117 mm (4 5/8")
148 mm (5 7/8")
168 mm (6 5/8")
21 mm (27/32")
80 mm
(3 1/4")
