- Page 1 ZENSOL AUTOMATION INC. COMPUTERIZED TEST EQUIPMENT ZENSOL CIRCUIT BREAKER PERFORMANCE ANALYZER CBA-32P CBA-32D Micro CBA MANUAL 11W E SIM-CB6 User Manual Version 3 May 3rd 2010...
- Page 2 SIM-CB6 User Manual Tél : +1 (514) 333-3488 www.zensol.com...
- Page 3 2. Connect the actuator extension cable between the three pin connector in the center of the front panel (fig 1) and the connector at the end of the actuator. Actuator connector. Fig. 1 Fig. 1a Tél : +1 (514) 333-3488 www.zensol.com...
- Page 4 SIM-CB6 User Manual 3. Connect the simulated breaker contacts to the timing device. For simulated SF6 or air blast breakers, use terminals A1, A2, B1, B2, C1, C2 as shown in fig. 2. Figure 2 Tél : +1 (514) 333-3488 www.zensol.com...
- Page 5 The resistive states of the closing and opening contacts are independent, which makes for great flexibility in configuring tests. Fig. 4 – Insertion resistor switch. Fig 4 – b : Insertion resistor value selection fig 4 – a : Insertion resistor Tél : +1 (514) 333-3488 www.zensol.com...
- Page 6 SIM-CB6 User Manual Configuration example using closing and opening resistors (fig. 5 and 6). Fig. 5 Fig. 6 Configuration example without closing resistors (fig. 7 and 8). Fig. 7 Fig. 8 Tél : +1 (514) 333-3488 www.zensol.com...
- Page 7 SIM-CB6 User Manual 5. Connect the close and open coils as well as the 24 VDC power supply (actually around 28 VDC) to the timing device. Fig. 9 – Command cable connections on the simulator. Tél : +1 (514) 333-3488 www.zensol.com...
- Page 8 Ground Fig. 10 Fig. 11 Pin 2 Pin 3 Pin 1 10 V Pin 1 Pin 2 +10 V Signal Pin 4 Fig. 12 Pin 2 Pin 3 Signal Ground Pin 1 +10 V Tél : +1 (514) 333-3488 www.zensol.com...
- Page 9 SIM-CB6 User Manual 7. Manual close and open tests. To close, press the Close button (fig. 13). The actuator produces a physical displacement, and the contact state indicator becomes red (fig. 14). Fig. 13 Fig. 14 Tél : +1 (514) 333-3488 www.zensol.com...
- Page 10 SIM-CB6 User Manual To open, press the Open button (fig. 15 The actuator produces a physical displacement, and the contact state indicator becomes green. Fig. 15. Tél : +1 (514) 333-3488 www.zensol.com...
- Page 11 Note 1: The simulator’s front panel fuse is a 3 amp fuse that protects the command logic (fig. 16). Fig. 16 Note 2 : The rear panel fuse is a 20 amp fuse that protects the magnetic driver coils in the actuator unit (fig. 17). Fig. 17 Tél : +1 (514) 333-3488 www.zensol.com...
