- Page 1 ZENSOL AUTOMATION INC. COMPUTERIZED TEST EQUIPMENT ZENSOL ON LOAD TAP CHANGER ANALYZER TROUBLE SHOOTING GUIDE TAP-4 August 20th, 2012...
-
Page 2: Table Of Contents
HOW TO UNINSTALL THE USB DRIVER? (UNDER WINDOWS XP) ..............3 HOW TO UNINSTALL THE USB DRIVER? (UNDER WINDOWS 7) ..............7 HOW TO USE THE CHECK FUNCTIONS ON THE FRONT PANEL? ..............10 HOW TO TEST AN ACCELEROMETER USING A SCOPE? ..................11 ZENSOL AUTOMATION INC. www.zensol.com... -
Page 3: How To Uninstall The Usb Driver? (Under Windows Xp)
You can now run the executable “CDMuninstallerGUI.exe” as follow: The following window will open: Click on “Add” and check “Generate uninstall log file” if you want a short report of the uninstallation. Finally, you can remove the device. ZENSOL AUTOMATION INC. www.zensol.com... - Page 4 After having done this little procedure, you can re-install the driver as following: this window, select Then, connect your TAP-4 to a Plug the TAP-4 into a free "Install from a list or specific power outlet and start it. USB port.
- Page 5 Choose to Update Driver, and then Search for a driver on my computer and then click Browse. In the OpenZEN folder, go into the USB folder and go into the folder CDM 2.08.02… finally click OK. ZENSOL AUTOMATION INC. www.zensol.com...
- Page 6 Click on the button “Device manager”. Now find the USB device under “USB bus controller”. Then, all you have to do is right click on the new device and choose uninstall. Now you can repeat the installation one more time. ZENSOL AUTOMATION INC. www.zensol.com...
-
Page 7: How To Uninstall The Usb Driver? (Under Windows 7)
ZENSOL AUTOMATION INC. How to uninstall the USB driver? (under windows 7) 1) Go into the control panel of Windows. 2) Double-click on the icon “System”. ZENSOL AUTOMATION INC. www.zensol.com... - Page 8 Now find the USB device under “USB bus controller”. Then, all you have to do is right click on the new device and choose uninstall or update driver. After having done this little procedure, you can re-install the driver as following: ZENSOL AUTOMATION INC. www.zensol.com...
- Page 9 ZENSOL AUTOMATION INC. this window, select Then, connect your TAP-4 to a Plug the TAP-4 into a free "Install from a list or specific power outlet and start it. USB port. location" and click Next. Windows should recognize the unit and display a window about it.
-
Page 10: How To Use The Check Functions On The Front Panel
Test 2, 3 and 4 – Accelerometer Tests. To make the second, third and fourth test, screw an accelerometer to the chassis of the TAP-4 to the designated area. Then, plug the accelerometer cable into the corresponding input you want to test and execute the test. -
Page 11: How To Test An Accelerometer Using A Scope
Figure 1 : Connect the accelerometer in Ch1 Hitting the accelerometer against the table, the trig level is at 50%, use the single shot to see the signal on the screen. Figure 2: Configure ch1 for 20mV and 4ms for the time base ZENSOL AUTOMATION INC. www.zensol.com... - Page 12 ZENSOL AUTOMATION INC. This is the result: ZENSOL AUTOMATION INC. www.zensol.com...
